1.7 Multiple Zones/Areas
As mentioned earlier, your home may require more than one zone to be set up in order for the Robomow
to work in all of your lawn effectively. Having two or even three zones does not affect the efficiency of the
Robomow and in many circumstances is more desirable than one large zone. It is suggested that each
zone be no larger than what the Robomower can mow in one full Power Pack charge cycle. Where grass
areas are not contiguous, or are separated by fences or other objects, it is also recommended to make
each of these a separate zone. A simple but effective and common way to set the Robomow up is to have
one zone for the front yard and one for the back yard. The side yards can be included with a front or back
section, or even set us a separate zone if desired.
The key is to set up the zones that will allow the Robomow to operate with the greatest efficiency, even if it
is more than one or two zones. You will quickly find that mowing the lawn in these zones is an easy
process that will allow you greater flexibility in your mowing habits. The Robomow gives you the ability to
control the operating time for each zone independently, up to four different zones. In this way, if one zone
needs a shorter operating time than another, it can easily be set for such a process. See Chapter 5,
Operator Settings and Advanced Features for detailed information on how to use this feature. There are
several ways to set up these zones, including the placement of the Perimeter Switch, depending on the
actual layout of the lawn. Examples are given in figures 1.7 and 1.8.
Perimeter Switch Perimeter Switch
location 3 location 3
Zone C Zone C
Side yard Side yard
18
Perimeter Switch Perimeter Switch
location 1 location 1
Driveway Driveway
Figure 1.8 – One Perimeter Switch for Multiple Zones
Zone A Zone A
Back yard Back yard
House and House and
garage garage
Zone B Zone B
Front yard Front yard
Fence Fence
Perimeter Switch Perimeter Switch
location 2 location 2
