- Page 1 IM2029 11/2009 Rev. 0 ® INVERTEC V270-T AC/DC ИНСТРУКЦИЯ ПО ЭКСПЛУАТАЦИИ (MANUAL IN ENGLISH) LINCOLN ELECTRIC ITALIA S.r.l Via Fratelli Canepa 8, 16010 Serrà Riccò (GE), Italia www.lincolnelectric.eu...
- Page 2 Déclare que le poste de soudage: Bekrefter at denne sveisemaskin: Verklaart dat de volgende lasmachine: ® INVERTEC V270-T AC/DC conforms to the following directives: överensstämmer med följande direktiv: è conforme alle seguenti direttive: spełnia następujące wytyczne: den folgenden Bestimmungen entspricht: täyttää...
- Page 3 07/06 Do not dispose of electrical equipment together with normal waste! In observance of European Directive 2002/96/EC on Waste Electrical and Electronic Equipment (WEEE) and its implementation in accordance with national law, electrical equipment that has reached the end of its life must be collected separately and returned to an environmentally compatible recycling facility.
- Page 4 12/05 THANKS! For having choosen the QUALITY of the Lincoln Electric products. • Please Examine Package and Equipment for Damage. Claims for material damaged in shipment must be notified immediately to the dealer. • For future reference record in the table below your equipment identification information. Model Name, Code & Serial Number can be found on the machine rating plate.
- Page 5 ENGLISH INDEX Safety ..........................................A-1 Installation and Operator Instructions................................A-2 Electromagnetic Compatibility (EMC) ................................A-9 Technical Specifications ....................................A-10 INDICE ITALIANO Sicurezza........................................... B-1 Installazione e Istruzioni Operative..................................B-2 Compatibilità Elettromagnetica (EMC) ................................B-9 Specifiche Tecniche ......................................B-10 INHALTSVERZEICHNIS DEUTSCH Sicherheitsmaßnahmen / Unfallschutz ................................C-1 Installation und Bedienungshinweise ................................
-
Page 6: Safety
Safety 11/04 WARNING This equipment must be used by qualified personnel. Be sure that all installation, operation, maintenance and repair procedures are performed only by qualified person. Read and understand this manual before operating this equipment. Failure to follow the instructions in this manual could cause serious personal injury, loss of life, or damage to this equipment. -
Page 7: Installation And Operator Instructions
¼ turn clockwise. Do not over The V270-T AC/DC is machine is designed to operate tighten. on engine driven generators as long as the Vac auxiliary... - Page 8 VRD threshold limit. If the VRD is disabled or the unit is When the V270-T AC/DC is powered ON the water welding, it will not illuminate. cooler Cool-Arc 34 will automatically power ON as well.
- Page 9 The Weld Sequence Diagram shows the various The Parameter Display Section shows the parameters that can be selected and adjusted and selected parameter its display icon and preset their preset values. As the push button/rotary value. To change the value, rotate the push encoder is pressed a triangular shaped flashing button/rotary encoder.
- Page 10 Press and hold the TIG torch trigger to start the sequence. The machine will open the gas valve to start the flow of the shielding gas. After the preflow time, to purge air from the torch hose, the output of the machine is turned ON.
- Page 11 Local/Remote Operation setting. The machine will follow the functionality of two-step in that start current, The V270-T AC/DC, when in TIG mode, will automatically sense when the machine has a remote up-slope, down-slope and finish current can all be adjusted.
-
Page 12: Welding Parameters
Welding Parameters The following parameters are adjustable on the V270-T AC/DC. (See Table B.3) Parameter Parameter Parameter Range Symbol Name Unit Pre-Flow Start Current Peak Finish Current Peak Min. Current Peak Figure B.7 Upslope Rotating the encoder knob will scroll through the setup parameters shown in Table B.4. - Page 13 Setup Menu Parameters Parameter Symbol Selection / * Default Value Parameter Number Description See Figure B.7 Set Up menu Exit • N.A. Reset All Parameters • Start Current Set Unit • • Bi-Level Current 2 • Set Unit • Pulse Background •...
-
Page 14: Electromagnetic Compatibility (Emc)
Maintenance WARNING For any maintenance or repair operations it is recommended to contact the nearest technical service center or Lincoln Electric. Maintenance or repairs performed by unauthorized service centers or personnel will null and void the manufacturers warranty. The frequency of the maintenance operations may vary in accordance with the working environment. Any noticeable damage should be reported immediately. -
Page 15: Technical Specifications
Technical Specifications V270-T AC/DC: INPUT Voltage Phase Frequency 230/400 Vac 3 ph 50-60 Hz RATED INPUT and OUTPUT @ 40°C Input Rated Output Current / Voltage / Duty Cycle Input Current @ Rated Output Phase Voltage (Duty Cycle: Based on a 10 min. period) 210 A / 18.4 V / 100%... -
Page 16: Accessories, Accessori, Zubehör, Accesorios, Accessoires, Tilleggsutstyr, Accessores, Tillbehör, Akcesoria, Varusteet, Accessórios
® Cool-Arc 34 kylaggregat. ® Chłodnica wodna Cool-Arc ® Cool-Arc 34 vesijäähdytin. ® Cool-Arc 34 Refrigerador de Água. Inverter Cart. Carrello. Fahrwagen. Carro para Inverter. Chariot. K2694-1 Tralle. Onderwagen. Vagn för Invertec. Karta inwertora. Kärry. Carro de Transporte de Inverter.
