Grace SuperPASS 3 User Information

SUPER PASS ® 3
Features and Labeling
Wire
Attachment
Accountability
Clip Storage Key
Side View With
Accountability Key
In Place
Sound Ports
Auto-On Activation
Case Glows when
Accountability
Key Pops Off
Emergency
Alarm
Button
Inside Battery Cover Battery Chamber
Serial
Number
Label
O-ring
Sealing
Surface
Bottom View
SUPER PASS ® 3 with
Accountability Storage Key in Place
1. To , press both side
buttons simultaneously
when Accountability Key
is Off unit.
To turn , replace
Accountability Key
and press both side
buttons simultaneously
Emergency
Alarm
.
.
Reset Button
Label
Compliance
Label
Identification
Window
Tether Attached To
A Fixed Position
Changing identification information
in the Accountability Storage Key window
Push small screwdriver
through slot on outside
I.D. Window
of key. The Plastic I.D.
window will pop out.
Add I.D. information
and Snap window back
in place.
The clear Identification Window located on the front of
the key provides the opportunity for specific identity of
the PASS user through the ability to personalize keys
with pictures, names, numbers, dept. ID, bar-codes, etc.
The clear access window easily snaps into place to pro-
tect enclosed information and provide instant access
for quick ID. Information in the Identification Window can
easily be changed by partially popping the ID window
out with a small, flat blade screwdriver through the ac-
cess slot located on the bottom of the ID window.
Pull Away Tether for Auto-On
Activation from Storage Positions
FIGURE 1
Snap
Hook
Snap hook attached to Transportation or Fixed
Storage Position.
PASS
attached to
turnout gear
Pull turnout gear away. Tether tightens and pulls
Accountability Key off the PASS. This will automatically
activate the PASS into the Sensing Mode.
SuperPASS ® 3 is designed to be automatically acti-
vated into the Sensing Mode or turned ON when re-
moved from the PASS storage position, whether it is a
transportation or a fixed storage position. When removed
from the storage position, the tether will tighten and the
Accountability Storage Key will automatically pop off
putting SuperPASS ® 3 into the Sensing Mode. At this
point, the unit can be reset (from the Alarm Mode to
Sensing Mode) but cannot be turned OFF until the
Accountability Storage Key is replaced and both side
buttons pressed simultaneously.
The Accountability Storage Key has an adjustable
tether for ease of use. The tether can be adjusted from
approx. 3' to 6' in length. This allows for easy utilization
whether you are anchoring the tether to a transporta-
tion position (such as to a seat in a vehicle) or a fixed
storage position (such as in the fire station). Account-
ability Storage Keys are available with various length
tethers to facilitate various operational needs.

Internal Datalogger

The internal data logging function records dates and
times of the last 2,000 events. Recorded PASS events
include: Power On, Pre-Alert and Lack of Motion Alarm,
Manual Alarm, Reset, Power Off and Low Battery Warn-
ings. The datalog information can be downloaded to a
PC using the datalog-transfer software and IR Dongle
available from Grace Industries.
IMPORTANT: To preserve the internal date & time
setting when changing batteries - batteries must
be replaced within 3 minutes of removing the
exhausted set.

Safety Certifications

Certified Intrinsically Safe to ANSI/UL 913: Class
1, Groups C and D; and Class II, Groups E, F, and
G; Division 1 Hazardous Locations.
CAUTION: Changes or modifications not expressly
approved by the party responsible for compliance
could void the user's authority to operate this
equipment.

Warranty Information

Grace Industries, Inc. warrants the Super
PASS ® 3 to be free from defects in workmanship and
materials for a period of one year from the date of
purchase. This warranty is valid only when the re-
turned SuperPASS ® 3 is accompanied by a sales
slip or other proof of purchase that states the date
and location of purchase. Grace Industries, Inc. will
not repair or replace any merchandise under war-
ranty which has been damaged because of acci-
dent, misuse or abuse of the SuperPASS ® 3 while
in possession or control of the consumer. This war-
ranty is void if any attempt to repair or replace parts
was made or attempted by other than qualified
Grace Industries, Inc. personnel. This warranty is
void if any of the sealed compartments are opened
or tampered with. Send all returned merchandise,
prepaid and accompanied by proof of purchase to:
Grace Industries, Inc., Repair Division, 305 Bend
Hill Road, Fredonia, PA 16124. Grace Industries,
Inc. shall not be liable for any direct, incidental or
other consequential loss or damage arising out of
the failure of the device to operate.
The sole and exclusive remedy under all guar-
antees or warranties, expressed or implied, is strictly
limited to repair or replacement as herein provided.
ALL IMPLIED WARRANTIES, INCLUDING BUT
NOT LIMITED TO, WARRANTIES OF FITNESS
AND MERCHANTABILITY, ARE HEREBY LIMITED
IN DURATION TO A PERIOD ENDING ONE (1)
YEAR FROM THE DATE OF PURCHASE. The war-
ranty and liability set forth in the prior paragraphs
are in lieu of all other warranties, expressed or im-
plied, in law or in fact, including implied warranties
of merchantability and fitness for a particular pur-
pose. Some states do not allow limitations on how
long an implied warranty lasts, so the above limita-
tions may not apply to you.
This warranty gives you specific legal rights and
you may also have other rights which may vary from
state to state.
The information contained in this booklet is be-
lieved to be accurate and reliable. Grace
Industries, Inc. provides this information as a guide
only.
®
SuperPASS 3 technical assistance is
available by contacting Grace Industries, Inc.
at 724-962-9231.
For training purposes a copy of this information is
available by contacting Grace Industries, Inc.
SuperPASS ® 3 issues may be reported at any time
to Grace Industries, Inc. at 724-962-9231. After
working with the manufacturer to resolve any issues,
they may be reported to SEI at 703-442-5732.
Solutions for Life Safety
© Grace Industries, Inc. Printed in U.S.A. P/N SUPERPASS3 0510, UI
®
SuperPASS 3
USER'S INFORMATION
Only To Be Removed By End User
Front View
with
Accountability
Key In Place
Grace Industries, Inc.
305 Bend Hill Road, Fredonia, PA 16124
Ph. 724-962-9231 Fax 724-962-3611
Solutions for Life Safety
Front View without Accountability Key
In Place
