- Page 1 APOLLO Gate Operators, Inc. Model 1550ETL Single Swing Gate Operator Model 1650ETL Dual Swing Gate Operator INSTALLATION MANUAL 04/07...
-
Page 2: Table Of Contents
Connecting the Actuator Gate Bracket Installation Limit Switch Adjustment Control Board Connections Control Board Adjustments - Learn Mode 1550ETL/1650ETL Actuator Option ………………….. 10 Push to Open Installation ... 11 Programming Instructions ……………………………. 12 Control Board Description ……………………………. 13-17 Siren Connection ………………………………………... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING - To reduce the risk of injury or death: READ AND FOLLOW ALL INSTRUCTIONS. Installation should be performed by a professional installer. Required welding should be performed by a qualified welder. Should electricity be required, use a certified electrician only. Any device that requires 120 Volts AC should be U.L. -
Page 4: Applications
The Apollo Model 1550ETL/1650ETL Swing Gate Operator is approved for Vehicu- lar Class I & II usage under UL 325 Guidelines, and is designed to handle swing gates up to 16 feet in length and 600 pounds each. A professional fence or gate dealer is recommended to assure proper installation. -
Page 5: Pre-Installation Checklist
PRE-INSTALLATION CHECKLIST The following check list should be used before beginning installation: Verify that the proper operator has been selected for this application. Verify proper installation and operation of the gate. 1. Are the hinges servicable? 2. Does the gate swing free and level? 3. -
Page 6: Parts Identification
#11111B Control Box #273G CAUTION Signs (2 each) (4 each with 1650) #201 5 Watt Solar Panel & Bracket (optional) (2 required with 1650) PARTS IDENTIFICATION #10000415 #10025215 Pivot Arm Gate Bracket (2 with 1650) (2 with 1650) OPTIONS #404C Automatic Battery Charger (optional) 816E Actuator with 8’... -
Page 7: Operator Installation
OPERATOR INSTALLATION STEP 1 PIVOT ARM INSTALLATION (standard pull to open) Location of Pivot Point. Notes: PULL TO OPEN pulls gate open (actuator is extended when gate is in the closed position). PUSH TO OPEN pushes the gate open (actuator is retracted when gate is in the closed position). -
Page 8: Actuator Installation
STEP 2 Actuator Installation 1/2” x 3 1/2” Hex Bolt 1/2” Washer 1/2” Lock Nut Do not over tighten nut STEP 3 Control Box Installation Mount the control box within 4 feet of the pivot arm. Do not mount the control box where the person using the push button on side of the box can come in contact with the gate. -
Page 9: Gate Bracket Installation
IMPORTANT Never weld parts to the gate or posts when the operator circuit board is powered. Doing so may damage the board beyond repair. STEP 5 GATE BRACKET INSTALLATION Activate push button on the side of the control box and extend the actuator until it stops (PULL TO OPEN only, leave actuator retracted for PUSH TO OPEN). -
Page 10: 1550Etl/1650Etl Actuator Option
1550ETL / 1650ETL Actuator Option The Apollo 1550ETL and 1650ETL systems – which use the 835/836 boards – come standard with the 816E / 816EX actuators. These actuators have a gray cable restraint and are considered our “smart” or “intelligent” actuator. These actuators utilize all of the features of the 835/836 board. -
Page 11: Push To Open Installation
PUSH TO OPEN INSTALLATION STEP 1 PIVOT ARM (s) INSTALLATION Location of pivot point Hinge post 6” Both measurements are taken from the center of the hinge. Vertical position of pivot arm (s) 1/2” Pivot arm must be level Hinge post Rewiring actuator (s) Must be re-wired for proper operation for push to open... -
Page 12: Programming Instructions
The 835/836 circuit boards incorporate a safety feature that will put the operator into a hard shut- down mode if the circuit board detects a current sense two consecutive times during a cycle. This hard shutdown condition can only be reset by shorting the FIREBOX or UL connectors on the left side of the circuit board to ground. -
Page 13: Control Board Description
835/836 Control Board Parts Identification Program Switches Operate Push Button Optional Device Inputs Stop Circuit Jumper Fire & ETL Inputs Emergency Bypass Timer To Close - Dual Gate Delay - Current Sensitivity - Adjustments Reverse Battery Polarity Actuator Connector Indicators (Slave) GateLink Connector... - Page 14 Board Actuator Pin 1 Pin 2 Pin 3 Pin 4 Pin 5 Pin 6 Pin 7 Pin 8 EMERGENCY BYPASS (open only) Applies battery voltage directly to motor to open gate if control board fails. User must unplug before gate opens to maximum travel or 15 amp fuse will open.
- Page 15 Adjustments TIMER TO CLOSE Adjusts time before gate automatically closes Adjustable 5 to 70 seconds. DUAL GATE DELAY Adjusts delay between master and slave op- eration 0-4 seconds (836 only for use with magnetic, solenoid, and other locking de vices) CURRENT SENSITIVITY Increases or decreases the Auto Reverse sensitivity.
-
Page 16: Program Switches
1 TIMER TO CLOSE Gate does not automatically close. 2 TIMER TO CLOSE OPT. Gate automatically closes from any position after opening. 3 SLAVE DISABLE Enables slave side (dual gate use). 4 SIREN DELAY Siren (optional) active when gate is moving. -
Page 17: Optional Device Inputs
Optional Device Inputs Supplied Battery Ground Activate Gate (Push button activation when momentarily shorted to ground) Supplied Battery Voltage (Protected with 3 Amp fuse) Supplied Battery Ground Activate Gate (Push button activation when momentarily shorted to ground) Supplied Battery Voltage (Protected with 3 Amp fuse) EDGE Reverse edge input. -
Page 18: Siren Connection
APOLLO The 911 Siren is included with all Apollo ETL Gate Operators. Mount siren in an area that will produce maximum performance (additional wire may be required). Connect the red wire to the SIREN connector on the Remote Monitor Output Connector block. -
Page 19: Radio Receiver Options
APOLLO Do not confuse the receiver code switches with the red program switches on the gate control board. Never set all code switches to the same position. Transmitters must match code switches for proper operation. If power is taken directly from battery or connected as shown below, receiver should be configured for 12VDC... -
Page 20: Troubleshooting Guide
TROUBLESHOOTING OPERATOR & ACCESSORIES Some troubleshooting will require a hand held multimeter. An inexpensive digital multimeter may be purchased at Radio Shack or a local electric supply company. Refer to the owners manual for instructions. SYMPTOM Gate opens OK but after closing, opens back up. 1. - Page 21 SYMPTOM Gate will open using push button on side of box, but not with transmitter. 1. Code switches do not match. Check that the code switches in the transmitter and the receiver match. 2. Low or dead battery in transmitter. Replace battery. 3.
- Page 22 SYMPTOM Gate will not open or close. Control board in HARD SHUT DOWN mode. Short the GND and UL connections on the lower left set of connectors and test. Disconnect the solar panel or charger and measure the battery voltage. Battery should read 12 or more volts and never drop below 11 volts when gate is operating.
-
Page 23: Warranty
APOLLO LIMITED TWO-YEAR WARRANTY Apollo Gate Operators are warranted against defects for a period of 24 months from the date of purchase, providing recommended installation procedures are followed. This warranty is in lieu of all other warranties expressed or implied (some states do not allow limitations on how long an...
