INTRODUCTION
Energy Sistem thanks you for buying Inngenio™ 3000 DUO HDP. We wish you
enjoy using it.
This compact multimedia player, with HDP technology (1,8"/4,6cm TFT display
with 65.000 colours, frontal speaker and high fidelity processor) and DUO
technology (2 stereo outputs without power loss) allows you to enjoy videos,
music and pictures every time and everywhere. Also has an integrated FM tuner
module.
We recommend to read this user manual in order to enjoy the product in a safe
way and with the best features.
Page 1 of 33

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Inngenio 3000 DUO HDP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ENERGY SISTEM Inngenio 3000 DUO HDP

Summary of Contents for ENERGY SISTEM Inngenio 3000 DUO HDP

  • Page 1 INTRODUCTION Energy Sistem thanks you for buying Inngenio™ 3000 DUO HDP. We wish you enjoy using it. This compact multimedia player, with HDP technology (1,8”/4,6cm TFT display with 65.000 colours, frontal speaker and high fidelity processor) and DUO technology (2 stereo outputs without power loss) allows you to enjoy videos, music and pictures every time and everywhere.

  • Page 2: Care And Maintenance

    - Keep the device clean and without dust with a soft and dry cloth. - Recharge the battery when the low battery icon appears on screen. - Do not disassemble the device. Any repair work must be performed by qualified Energy Sistem Soyntec’s personnel. Page 2 of 33...

  • Page 3: Main Features

    MAIN FEATURES - HDP: 1,8”/4,6cm TFT display with 65.000 colours, frontal speaker and high fidelity processor. - DUO: 2 stereo outputs without power loss. - Plays MP4 (SMV) videos. Includes SMV file creator. - Plays MP3/WMA/WAV music. - Shows JPG/BMP pictures. - Integrated FM Radio with 20 presets and direct recording.
  • Page 4 MAIN FEATURES - Upgradeable firmware. - No drivers needed (except W98). - 5 equalization modes. - 5 play modes. Page 4 of 33...

  • Page 5: Product Content

    PRODUCT CONTENT - Energy Sistem® MP4/ MP3/WMA/FM Player Inngenio™ 3000 DUO HDP. - Two high-fidelity in-ear earphones. - User manual. - Driver CD. - USB retractable cable for battery charging and data transfer. - Neck strap. - Carrying case. Page 5 of 33...

  • Page 6: General Overview

    GENERAL OVERVIEW 1. Neck strap hole. 2. Earphones output. 3. PLAY: Play/Pause/Stop/ Power On/Power Off. 4. REC: Start voice or FM radio recording / Delete file / A-B repeat. 5. Power switch. 6. USB connector. 7. Frontal speaker. 8. PREVIOUS: Volume + / Previous / Rewind.

  • Page 7: Battery Power

    BATTERY POWER - Your Inngenio™ 3000 DUO HDP has an integrated rechargeable Li-Ion battery. It comes recharged from factory, but it is recommended to perform a full recharge before the first usage. Recharge the battery connecting the player to a computer using the included retractable USB cable (any USB type mini-B with 5-pins will also work).
  • Page 8 BATTERY POWER working. To keep the battery in good conditions, we recommend not to use the player while charging, with the power switch in “OFF” position and do not charge for more than 8 hours. - For battery saving, your Inngenio™ 3000 DUO HDP has two systems: it will power off the display after 5 seconds of inactivity and it will power off completely after 60 seconds of inactivity.

  • Page 9: Switching On/Off

    SWITCHING ON / OFF - To power on your Inngenio™ 3000 DUO HDP, place the switch in the “ON” position and press PLAY for 2 seconds. Note: When powering on, the device performs a memory check. The power on time depends on the amount of occupied memory. - Press PLAY for 3 seconds to power off the device.
  • Page 10 MP3/WMA/WAV MUSIC PLAYER - Inngenio™ 3000 DUO HDP allows you to enjoy MP3 / WMA / WAV codified music thanks to its high fidelity sound processor. - Just after the device is powered on, you are on the mode for playing MP3/WMA/WAV files.
  • Page 11 MP3/WMA/WAV MUSIC PLAYER - Press PLAY to pause the music, and hold PLAY for 1 second to stop it. - Press the PREVIOUS/NEXT button to skip to the previous/next track. - To get the volume up/down, hold the PREVIOUS/NEXT button. - You can fast forward or rewind inside the song by pressing MENU, selecting “Setup”, “FF &...
  • Page 12 MP3/WMA/WAV MUSIC PLAYER - Choose the right equalization mode according your preferences by pressing MENU, selecting “Setup”, “EQ” and one of the following modes:“Normal”, “Rock”, “Jazz”, “Classic” or “Pop”. - The playing order of tracks depends on the selected mode. By default, the mode is “Normal”.
  • Page 13 MP3/WMA/WAV MUSIC PLAYER - To know the amount of free memory, press MENU and select “Info.” Page 13 of 33...

  • Page 14: Folder Navigation

    FOLDER NAVIGATION - This practical function allows you to choose the folder and the songs that you want to listen and that you previously organized with you computer. - To navigate through your folders, being at the “Music” mode, press MENU for 2 seconds.
  • Page 15 FM RADIO - Inngenio™ 3000 DUO HDP has an integrated FM radio with 20 presets and direct recording. - To listen the radio, being at the main menu, select “Radio FM”. - While the FM radio has a sensitive tuner, it is possible that some broadcasts with weak signal at your place, will not be well tuned unless you connect the earphones or the USB cable, that work as an antenna.
  • Page 16 FM RADIO - Manual searching: 1) Press MENU until the word “Manual” appears on screen. 2) Press PREVIOUS/NEXT to go back/forward inside the frequency band. Hold PREVIOUS/NEXT to activate the automatic search, that will stop when a broadcast signal is tuned. 3) Once you have tuned a broadcast, store the preset by pressing MENU, the word “Save”...
  • Page 17 FM RADIO - Press the PREVIOUS/NEXT button to skip to the previous/next preset. - To get the volume up/down, hold the PREVIOUS/NEXT button. - With the PLAY button you can change the sound mode to “Stereo” / “Mono”. Sometimes, when listening a broadcast with weak signal, the sound quality improves if you select sound mode “Mono”.
  • Page 18 FM RADIO - The sound files that you recorded are stored inside the “FM” folder. The files are WAV format. You can listen this files while being at the “Music” mode, selecting the “FM” folder using the folder navigation function and pressing PLAY on the WAV file that you want to listen.

  • Page 19: Digital Voice Recording

    DIGITAL VOICE RECORDING - Inngenio™ 3000 DUO HDP is able to perform voice recording with its integrated microphone. There are two ways to start recording: Select the “Record” mode from the main menu. Being at the “Music” mode, hold REC for 1 second. - While recording, you can pause with the PLAY button.

  • Page 20: Video Player

    VIDEO PLAYER - With Inngenio™ 3000 DUO HDP the music goes to a new dimension when you enjoy your favourite music videoclips any time anywhere. - You can play AVI/WMV/MPG videos that you previously converted to the SMV format, using the easy software tool included inside the bundled CD. Check the user manual section “CREATING SMV VIDEOS”.
  • Page 21 VIDEO PLAYER - Press the PREVIOUS/NEXT button to skip to the previous/next video. - To get the volume up/down, hold the PREVIOUS/NEXT button. - Choose the right equalization mode according your preferences by pressing MENU, selecting “Setup”, “EQ” and one of the following modes:“Normal”, “Rock”, “Jazz”, “Classic”...
  • Page 22 CREATING SMV VIDEOS - With the Video2SMV software tool you can easily convert your AVI/WMV/MPG videos to the SMV format for enjoying them with your Inngenio™ 3000 DUO HDP. - For installing Video2SMV follow these steps: 1) Insert the bundled Driver CD in a CD/DVD drive of your computer (if you have an Internet connection, it is recommended to download the latest version from our website www.energysistem.com).
  • Page 23 4) Once the installation has finished, run the application though the menu “Start”->”All the programs”->”INNGENIO 3000”->"Video2SMV v.2.2. for Energy Sistem INNGENIO 3000". - For converting a AVI/WMV/MPG video follow these steps: NOTE: If you want to convert special video formats like MPEG4 / DivX / XviD / etc. be sure that you have installed the needed “codecs”.
  • Page 24 CREATING SMV VIDEOS 3) Select the target folder and write the name of the new SMV video file to be created (“Output File"). 4) Choose the speed of frames per second (“Frame Rate”). More frame rate will use more memory and the output file will be bigger.
  • Page 25 CREATING SMV VIDEOS if you want the image to fill the whole screen (“Pan & Scan”), even if some part of the image needs to be removed from the output video. 7) The “Selection” part allows you to delimitate the start and end of the input video.

  • Page 26: Viewing Pictures

    VIEWING PICTURES - View and enjoy your JPG/BMP pictures and photos with the 65.000 colours TFT screen. Just copy the files inside the “IMAGES” folder of your Inngenio™ 3000 DUO HDP (check the section “CONNECTION TO THE COMPUTER”). - For viewing your pictures, select the “Pictures” mode from the main menu. The presentation will start automatically.

  • Page 27: Connection To The Computer

    CONNECTION TO THE COMPUTER - Connect your Inngenio™ 3000 DUO HDP to the computer using the retractable USB cable included. The device will be detected automatically wihout installing any driver (except Windows 98, in which case you have to install the W98 driver from the bundled CD). - Once detected, you can read/write to the device’s memory just like you where using a regular disk drive.

  • Page 28: Firmware Reinstallation

    FIRMWARE REINSTALLATION - Your Inngenio™ 3000 DUO HDP has a operating system installed, usually named firmware, that sometimes needs to be reinstalled. - The process is easy, but must be performed carefully, and only when it is really necessary. - If you see that the player halts, it reboots randomly, or you have problems to access the memory content from your computer, those are signs that the firmware is damaged and needs to be reinstalled.
  • Page 29 FIRMWARE REINSTALLATION Follow these steps to reinstall the firmware: 1) Insert the bundled Driver CD in a CD/DVD drive of your computer (NOTE: if you have Windows Vista, it is very important to download the latest version of the firmware from our website www.energysistem.com). Be sure that the firmware you are installing is for your model, otherwise you will damage the device.
  • Page 30 FIRMWARE REINSTALLATION 5) A window will appear showing a lantern and saying "Searching for devices connected to the system..." 6) In that moment, take your Inngenio™ 3000 DUO HDP, place the switch button in the ON position and, while holding the PLAY button, plug the device to your computer using the USB cable.
  • Page 31 FIRMWARE REINSTALLATION the firmware. Check the option “Format Data Area” (this will delete all the stored data in the memory of the device) and press the “Start” button. Wait until the process ends and press the “Close” button. 8) Disconnect your Inngenio™ 3000 DUO HDP by using the green arrow icon close to the Windows clock (Safe Hardware Removal) and wait until the system...

  • Page 32: Troubleshooting

    TROUBLESHOOTING 1.- Why I cannot play some MP3 files? - The MP3 file has to follow some standards like MPEG1/MPEG2/MPEG 2.5 layer 3. Otherwise, the file must be converted using a software application. 2.- My player doesn’t power on and my computer doesn’t detect it, what can I - It is possible that there is a problem with the firmware.
  • Page 33 SPECIAL GUARANTEE Energy Sistem guarantees that your product does not have any material, design or manufacture defect and provides 36 month guarantee. Guarantee procedure Direct to your vendor and present the purchase invoce or ticket. For more information visit www.energysistem.com.
