Security Wireless MMS-DLUX User Manual

Gsmigprs remote camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
MMS-DLUX
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MMS-DLUX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Security Wireless MMS-DLUX

Summary of Contents for Security Wireless MMS-DLUX

  • Page 1 User Manual MMS-DLUX...

  • Page 2: Table Of Contents

    CONTENTS 1. Thank you……………………………………………………………………………….. 2. For Your Safety………………………………………………………………………..  Declaration……………………………………………………….…………………….. 3. Product Feature…………………………………………………………………..….  Product Accessories……………………………………………...………………… 4. Host Instruction……………………………………………...………………………. 5. Host Instruction……………………………………………...……………………….  SIM Card Installation……………………………...…...………………………….  Remote Control and Receiver Instructions……………………………… 6. Quick Start……………………………………………………...……………………….  About the SMS Command……………………………….………………………. ...

  • Page 3: Thank You

    Thank you for purchasing the MMS-DLUX. MMS-DLUX is a smart GSMIGPRS remote camera. It helps you achieve remote monitor, alarm and shooting, and thus provides a safe solution for protecting your privacy. The built-in 300000 pixels camera allows you to freely ask the device to take photos and send it to either your mobile phone or mailbox.

  • Page 4: Product Feature

    1. All GSM SIM cards can be used, capable of sending photos taken to MMS service enabled mobile phone or mailbox. 2. Integrated PIR sensor to provide a precise and timely alarm. 3. Built-in CMOS camera and IR lights: it can take clear images at night. 4.

  • Page 5: Host Instruction

    Power Switch Camera Infrared Light Reset Button PIR Sensor Speaker Bracket Connection Diagram...

  • Page 6: Host Instruction

    Indicator Status Instructions Color Indicator Status Flash slowly Searching the network Flash quickly Detection activated when power on. PIR Sensor alarm or move- ment detection alarm activated when in working status Constant Light No SIM card or malfunction Constant Light Arming status Flash slowly Disarming status...

  • Page 7: Remote Control And Receiver Instructions

    Remote Control and Receiver Operation Instructions Connect the mini USB plug of the sensor receiver to the USB interface of the mobile guarder. Connect the power adapter to the sensor receiver, and open the sensor switch. Press the arming button to the arming status. The Mini guarder will trigger an alarm and send out SMS via the wire- less sensor, motion detection or infrared detectors.

  • Page 8: Quick Start

    Method 1: Make a call with your mobile phone and you will hear it hang up. Method 2: Send the SMS command to start up: #00#. After starting up you will receive the following SMS reply: “Welcome! Congratulations on your purchase of MMS-DLUX! You are authorized to use this device. Password: 1234.”...

  • Page 9: Quick Start

    Power On/Off Power on: Keep pressing the power switch when power supply (external power supply or battery) is on. During this period of time, you will hear power on music, then the indicator turns red and then off. After a while it turns red again and flashes slowly till off, and then turns green (constantly green when armed, slowly flashes green when disarmed) and sounds “DU---“, then it turns to normal working status.

  • Page 10: Quick Start

    Arming / Disarming To arm the device is to activate the alarm function, thus the PIR sensor or movement detection turns to working state (Product is set default to Arming status). To disarm the device is to deactivate the alarm function, the PIR sensor or movement detection.

  • Page 11: Quick Start

    Alarm With the built-in PIR sensor, the device can alarm once triggered, default to SMS and MMS. If the alarm SMS, MMS and call options are activated at the same time, it will send alarm SMS and MMS orderly and then make phone calls, once for each.

  • Page 12: Quick Start

    To ask the device for help, send an SMS command as follows and you will receive a reply with command list or user manual: For SMS commands: Master or family users: #09# Guest: #09# password# For User Manual: Master or family users: #09#1# Guest: #09# password#1# Reset factory settings When the status of the settings is wrong, it cannot recover even when the power is off.

  • Page 14: Troubleshooting

    Problem Possible Reason Solution Indicator light does not The indicator Press the RESET button for 10 seconds or send work light’s disabled SMS command Start up failure (but Indi- Master already set Restore to factory settings cator works normally) Caller ID presenta- Functions failure (but Indi- tion or MMS ser- Please contact the operator...
  • Page 15 SMS Command User Function #00# Master Start the device Refer to Chapter 5. Quick start, 1. start up #01# Master/family Arm the device Refer to Chapter 5. Quick start, 4. Arming #02# Master/family Disarm the device Refer to Chapter 5. Quick start, 5. Disarming #03#[password#]image number# Master/family/ Capture MMS image...
  • Page 16 User Function SMS Command #22#value# Switch of mobile Master/family Value = 1: mobile detection open detection 0: mobile detection closed (default) #36#grade# Sensitivity of mobile Master/family Grade 1,2,3,4,5 optional, from 1 to 5 stands for the sensitivity from detection low to high, default 4. #201#times# Master/family Set of mobile times...
  • Page 17 SMS Command User Function #119#grade# Master/family Image quality Grade can be optional from 1 to 4, (1 is lowest, 4 is highest, default is #108#EMAIL# Add or modify Master/family Email address Everyone can set one mail, and can be modified #109# Master/family Delete Email...
  • Page 18 SMS Command User Function #124#MMS center# Master/family Set MMS center Users need to reset MMS center depending on different networks, such as Vodacom Mobile (default): #124#http://mmsc.vodacom4me.co.za# #125#ip#wapport#httpport#apn#user#pwd# Set MMS pa- Users need to reset MMS parameter depending on different countries, Master/family rameter such as Vodacom Mobile (default):...
  • Page 19 SMS Command User Function #152#number# Regulate device time The number is the device SIM card number. Master/family Activate Speaker Please regulate again when the battery is replaced or re-installed. #164#1# Activate Speaker Master/family Deactivate #164#0# (Default) Speaker #222#timedelay# Delayed range can be from 1 to 30 Min. Default to 1 Min., i.e. it will not make an alarm within 1 min when the power is on, even if it detects Master/family Time Delay...
