The elevator actuator must be protected from damage. A wooden block of ap-
propriate height must be laid under the fin-stabilizer attachment area.
WARNING:
After rotating the fuselage back upright remove the tape!
Remove spilled fluid and clean with cleaning spirit. Check
brake fluid level!

Ground Transport

The
wings
may
ribs and wing tips. Remove winglets before!
The tow release fitted at the C.G. is model TOST "Europa G 88" (Data Sheet
No:60.230/2).
Models TOST "Europa G 72 or G 73" may be used as a replacement tow re-
lease.
Depending on the position of its installation, different aerotow release models
may be installed.
In the tip of the fuselage nose, model TOST "E 22" is used (Data Sheet
No:11.402/9 NTS).
Between stick and pedals, models TOST "E 85" or "E 72" or "E 75" are used.
(Data Sheet No:60.230/1).
The replacement of tow release couplings is described in Section 10.4.
Rev.No / Date
TN 11
26.06.07
ASW 27
Maintenance Manual
be
supported
Sig
Author
mg
Juw/GW
at
the
spar
Date
Page No.
20.01.97
stubs,
root
2.23

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ASW 27 and is the answer not in the manual?

Questions and answers

Related Manuals for Schleicher ASW 27

Summary of Contents for Schleicher ASW 27

  • Page 1 ASW 27 Maintenance Manual The elevator actuator must be protected from damage. A wooden block of ap- propriate height must be laid under the fin-stabilizer attachment area. WARNING: After rotating the fuselage back upright remove the tape! Remove spilled fluid and clean with cleaning spirit. Check...
  • Page 2 ASW 27 Maintenance Manual 4.2 Special Servicing Procedures and Equipment subject to Service Life Limitations Special Servicing Procedures At regular intervals of 5 years, the sealing rings and groove sealing rings of the water ballast valves must be checked, and replaced if required (see Fig. 2.4-1).
  • Page 3 ASW 27 Maintenance Manual Fig. 8.0-1 Lubrication Chart Rev.No / Date Author Date Page No. TN 11 26.06.07 Juw/GW 20.01.97...
  • Page 4 ASW 27 Maintenance Manual 10.4 Removing and installing tow releases 10.4.1 Tow release coupling fitted at the c.g. 1. Remove the seat back and the seat pan. 2. Undo the safety springs from the L/G doors. 3. Remove the wheel. First proceed as described in Section 2.3.4 “Exchange of Brake Linings”: dismount the wheel brake cylinder.
  • Page 5 ASW 27 Maintenance Manual 12.4 List of Maintenance Documents for Fitted Equipment a) Operating Manual for Tow Release Coupling Series "Europa G 88" Safety Tow Release, in its valid issue Operating Manual for Tow Release Coupling Series Safety Tow Release "Europa G 72" and "Europa G 73", in its valid issue Operating Manual for Tow Release Coupling Series Nose Tow Release Hook "E 85”, in its valid issue...
