Summary of Contents for SnowBlaster 56663
- Page 2 Refer to name plate on your Snow Thrower for the Serial Number. Record your Snow Thrower's information below. DATE OF PURCHASE: __________________________________________ PURCHASED FROM: __________________________________________ SNOW THROWER ITEM #: __________________________________________ SNOW THROWER SERIAL NUMBER: _________________________________________ #56663 SNOW THROWER OPERATOR’S MANUAL...
-
Page 3: Table Of Contents
Parts List ………………………………………………………………. Warranty ………………………………………………………………. SPECIFICATIONS 13 Amp 18" Electric Snow Thrower Item #: 56663 Motor: 120V, 60Hz, 13Amp Speed: 2200 rpm (no load) Clearing Width: 18" Clearing Height: 10" Wheel Size: 5" Weight: 40 lbs. #56663 SNOW THROWER OPERATOR’S MANUAL... -
Page 4: Important Safety Instructions
The smaller the gauge number, the heavier the cord. Minimum gauge for Extension Cords (AWG) (When using 120V only) Ampere Rating Total Length of Cord in feet More Than Not More Than Not Recommended #56663 SNOW THROWER OPERATOR’S MANUAL... - Page 5 Thrown snow and foreign objects accidentally picked up by the snow thrower can cause serious damage and personal injury. Do not use your hands to unclog the discharge chute. Stop the motor before removing debris. #56663 SNOW THROWER OPERATOR’S MANUAL...
- Page 6 WARNING: The following warning symbol is to remind you of the safety precautions you should take when operating the Snow Thrower. Keep hands away from the moving parts of the Snow Thrower. The rotating parts could cause bodily injury. #56663 SNOW THROWER OPERATOR’S MANUAL...
-
Page 7: Know Your Snow Thrower's Components
KNOW YOUR SNOW THROWER’S COMPONTENTS LOWER FRAME UPPER CHUTE CRANK MIDDLE FRAME POLARIZED PLUG CARRYING HANDLE CABLE CLIP UPPER FRAME CHUTE DEFLECTOR HANDLE BAR CHUTE SWITCH #56663 SNOW THROWER OPERATOR’S MANUAL... -
Page 8: Assembly Instructions
Repeat this step on the other side of the handle. The bolts should be inserted from the inside of the frame of the unit so that the washers and knobs are fastened to the outside of the frame. Note: Do not over-tighten the knobs. #56663 SNOW THROWER OPERATOR’S MANUAL... -
Page 9: Upper Frame Assembly
Repeat this step on the other side of the handle. Locate the three Cable Clips in the parts bag. Secure the power cord to the frame of the unit by clipping them onto the frame at evenly spaced intervals. (Fig. 5) #56663 SNOW THROWER OPERATOR’S MANUAL... -
Page 10: Discharge Chute Assembly
Tighten the nut with a wrench. Note: If the center hole is not lining up correctly, you have the middle frame on backwards. The hole and grommet of the eye bolt should face up. #56663 SNOW THROWER OPERATOR’S MANUAL 10... -
Page 11: Operation
The extension cord female end should be likewise polarized, so that the extension cord fits snugly into the switch housing socket. #56663 SNOW THROWER OPERATOR’S MANUAL 11... -
Page 12: Powering On And Off
When the motor is on, release the switch button, and keep hold the handle bar. Note: Reverse operation cannot start the machine. To power off, release your grip on the handle bar. #56663 SNOW THROWER OPERATOR’S MANUAL 12... -
Page 13: Plowing The Snow
WORKING ON PEBBLES, GRAVEL, OR UNPAVED SURFACES. To avoid throwing loose surface material along with the snow, push down on the handle to raise the scraper at the base of the unit above the pebbles or gravel. #56663 SNOW THROWER OPERATOR’S MANUAL 13... -
Page 14: Changing Snow Discharge Chute's Direction
Do not advance the chute deflector too far forward causing an opening to appear between the deflector and discharge chute. Do not over tighten the knobs on the chute deflector. #56663 SNOW THROWER OPERATOR’S MANUAL 14... -
Page 15: Maintenance
5. Store the unit, along with the disconnected extension cord, in a locked, dry place out of the reach of children to prevent unauthorized use or damage. Cover loosely with a tarp for added protection. #56663 SNOW THROWER OPERATOR’S MANUAL 15... -
Page 16: Exploded View
EXPLODED VIEW #56663 SNOW THROWER OPERATOR’S MANUAL 16... -
Page 17: Parts List
Shaft 56663-041 Semicircular Key 56663-086 Cotton Pin 2x14 56663-042 Big Gear 56663-087 Rivet 4x20 56663-043 Snap Ring 10 56663-088 Lower Chute Crank 56663-044 Oil Seal 56663-089 Locknut M4 56663-045 Nut M8 56663-090 Screw M4x20 #56663 SNOW THROWER OPERATOR’S MANUAL 17... - Page 18 Switch Housing L 56663-109 Starter Button 56663-110 Spring 56663-111 Small Cable Keeper 56663-112 Switch Housing R 56663-113 Screw ST4.2x25 56663-114 Switch Seat R 56663-115 Switch Seat L 56663-116 Switch Actuator 56663-117 Spring 56663-118 Handle Bar #56663 SNOW THROWER OPERATOR’S MANUAL 18...
-
Page 19: Warranty
THIS LIMITED WARRANTY APPLIES ONLY TO PORTABLE ELECTRIC TOOLS, BENCH POWER TOOLS, OUTDOOR POWER EQUIPMENT AND PNEUMATIC TOOLS SOLD WITHIN THE UNITED STATES OF AMERICA, CANADA AND THE COMMONWEALTH OF PUERTO RICO. FOR WARRANTY COVERAGE WITHIN OTHER COUNTRIES, CONTACT SNOW BLASTER™ CUSTOMER SUPPORT. #56663 SNOW THROWER OPERATOR’S MANUAL 19...
