Summary of Contents for SnowBlaster 56660
-
Page 3: Table Of Contents
RULES FOR SAFE OPERATION…………………………….. IMPORTANT SAFETY INSTRUCTIONS…………………… UNPACKING………………………………………………….. ASSEMBLY…………………………………………………… OPERATION………………………………………………….. LUBRICATING THE SNOW SHOVEL……………………… EXPLODED VIEW…………………….……………………… PARTS LIST…………………………………………………… WARRANTY STATEMENT…………………………………. SPECIFICATIONS Model: 56660 Motor: 120V, 60Hz, 9A Speed: 2100rpm (no load) 12.5” Clearing width: 6” Clearing height: Weight: 15 lbs... -
Page 4: Rules For Safe Operation
RULES FOR SAFE OPERATION The purpose of safety symbols is to attract your attention to possible dangers. The safety symbols, and the explanations with them, deserve your careful attention and understanding. The safety warnings do not by themselves eliminate any danger. The instructions or warnings they give are not substitutes for proper accident prevention measures. -
Page 5: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS When using an electrical appliance, basic precautions should always be followed, including the following: READ ALL INSTRUCTIONS BEFORE USING YOUR SNOW SHOVEL WARNING- To reduce the risk of fire, electric shock, or injury, follow these safety instructions. Read, understand, and follow all instructions on the machine and in the manual(s) before operating this unit. - Page 6 Don’t abuse cord -Never carry snow shovel by cord or yank it to disconnect from receptacle. Keep cord from heat, oil, and sharp edges. Keep hands away from moving parts. Keep guards in place and in working order. Don’t force snow shovel -It will perform better and safer at the rate for which it was designed. Do not overreach -Keep proper footing and balance at all times.
-
Page 7: Unpacking
UNPACKING WARNING - To prevent accidental starting that could cause possible serious personal injury; assemble all parts to your saw before connecting it to power supply. Snow shovel should never be connected to power supply when you are assembling parts, making adjustments, installing or removing blades, or when not in use. WARNING - If any parts are missing, do not operate this tool until the missing parts are replaced. -
Page 8: Assembly
ASSEMBLY Upper handle assembly 1. Firmly insert the Pipe into the Handle (Figure 1); making sure tab is inserted into locking hole. (Figure 2) 2. Pipe is fully inserted and ready to be tightened using the Handle Knob fastener. (Figure 3) 3. -
Page 9: Operation
OPERATION Note: This Snow Shovel is intended for outdoor, residential use only. Do not use it indoors or for commercial or industrial purposes. Safety precautions 1. Thoroughly inspect the area where the equipment is to be used and remove all doormats, sleds, boards, wires, and other foreign objects. - Page 10 13. Never operate the snow shovel without proper guards and other safety protective devices in place and working. 14. Never direct the discharge toward people or areas where property damage can occur. Keep children and others away. 15. Do not overload the machine capacity by attempting to clear snow at too fast a rate. 16.
- Page 11 2. Insert the loop through the hole in the back of the upper handle, securing the loop around the hook. Note: This helps to prevent you from accidently disconnecting the extension cord from the appliance during operation. 3. Connect the extension cord to the appliance electrical cord. 4.
-
Page 12: Lubricating The Snow Shovel
Operating Tips Start the Snow Shovel and tilt it forward until the scraper blade contacts the ground. Push the Snow Shovel forward at a comfortable rate of speed, slow enough to clear the path completely. The width and depth of the snow determines your forward speed. ... -
Page 13: Exploded View
EXPLODED VIEW... -
Page 14: Parts List
PARTS LIST Item Stock # Description Item Stock # Description 56660-001 Screw 56660-048 Tapping Screw 56660-002 Rubber Plug 56660-049 Tapping Screw 56660-003 Screw 56660-050 Protector 56660-004 Right Handle 56660-051 Brush Holder 56660-005 Switch Trigger 56660-052 Spring Washer 56660-006 Switch Trigger Spring... -
Page 15: Warranty Statement
WARRANTY STATEMENT Limited One Year Warranty WEN Products is committed to build tools that are dependable for years. Our warranties are consistent with this commitment and our dedication to quality LIMITED WARRANTY OF WEN CONSUMER POWER TOOLS PRODUCTS FOR HOME USE GREAT LAKES TECHNOLOGIES, LLC ("Seller") warrants to the original purchaser only, that all WEN consumer power tools will be free from defects in material or workmanship for a period of one (1) year from date of purchase.
