Alpha Image AMD1x-E Series User Manual

Specifications

AMD1x-E(*)
Model
Pick up Element 1/3" Sony Effio-E CCD
Effective Picture Elements
PAL: 976 (H) x 582 (V)
(H×V)
Horizontal Resolution 700 TV Lines
Minimum Illumination 0.001 Lux
S/N Ratio > 52dB
Scanning System 2:1 interface
Synchronous System Internal, Negative sync.
PAL: 1/50 sec ~ 1/100,000 sec
Auto Electronic Shutter
Gama Characteristic 0.45
IR Distance 30 Meters (with ￠ 5 x 36 pcs Infrared LED—850 nm)
1,0 Vpp, 75
Video Output
Auto
Auto Gain Control
12 VDC (+/-10%) / 450mA
Power / / / / C urrent
Lens 2.8—12 mm Manual Zoom Lens
Dimensions & Weight ￠ 1 31 x 93 (H) mm - 800 gr.
(*) Housing color x = G (Grey), x = B (Black), x = W (White)
Storage Temperature -30 ~ +60 ℃ RH95% MAX
Operating Temperature -10 ~ +50 ℃ RH95% MAX

Packing List

No Name
1.
Vandalproof IR Dome Camera AMD1x-E
2. AMD1x-E
User Guide
Franchiser：
Put your information and notes here:
Model Number
1
1
AMD1x-E Series IR Dome camera
"Alpha Image" Metal Dome 1x-E
x = color of the camera housing
x = G (Grey)
x = B (Black)
x = W (White)
Notes : : : :
B efore providing power to the
camera, please read this User Guide in
detail !
Do not attempt to disassemble the camera.
If the camera does not work, please contact
your local supplier.
