Alpha Image AMD2x-E Series Installation Manual

Specifications

AMD2x-E(*)
Model
Pick up Element 1/3" Sony 1,3 Megapixel CMOS Exmor sensor
Effective Picture Elements
PAL: 1305 (H) x 1049 (V)
(H×V)
Horizontal Resolution 1000 TV Lines
Minimum Illumination 0.01 Lux (F1.2) - 0 lux with IR on
> 50 dB
S/N Ratio
Scanning System 2:1 interface
Internal, Negative sync.
Synchronous System
Auto Electronic Shutter PAL: 1/50 sec ~ 1/100,000 sec
0.45
Gama Characteristic
IR Distance
25 Meters (with￠5 x 36 pcs Infrared LED—850 nm)
Video Output 1,0 Vpp, 75 Ω
Auto
Auto Gain Control
Power/ / / / Current 12 VDC (+/-10%)/ 450mA
Lens 2.8—12 mm Manual Zoom Lens
Dimensions & Weight ￠131 x 93 (H) mm - 800 gr.
x = G (Grey), x = B (Black), x = W (White)
(*) Housing color
Storage Temperature -30 ~ +60 ℃ RH95% MAX
Operating Temperature -10 ~ +50℃ RH95% MAX

Packing List

No
Name
1.
Vandalproof IR Dome Camera AMD2x-E
2. AMD2x-E
User Guide
Franchiser：
Put your information and notes here:
Model Number
1
1
AMD2x-E Series IR Dome camera
"Alpha Image" Metal Dome 2x-E
2 = Series "2" for 1000 TV lines
x = color of the camera housing:
x = G (Grey) - x = B (Black) - x = W (White)
Notes: : : :
Before providing power to the
camera, please read this User Guide in
detail !
Do not attempt to disassemble the camera.
If the camera does not work, please contact
your local supplier.
