prevent water leakage.
11. Install the Upper Access Panel and lightly tighten the ¼" bolts. Allow Silicone to
cure for several hours and then torque all bolts to 125 In.-Lbs. (10 Ft.-Lbs.)

SPECIAL TOOLS TO SERVICE SURFACE DRIVES

PART # DESCRIPTION
PW2-3BL PROP WRENCH
SHBUPU PULLER FOR
SHAFT & BUSHINGS
(SLIDE HAMMER)
SHAD SHAFT ADAPTER
BUPU BUSHING PULLER
BUIN BUSHING INSTALLER
T1
R78 7/8" REAMER
These tools can be rented for $20.00 plus shipping with a $255.00 deposit.
OTHER TOOLS NEEDED TO SERVICE SURFACE
T-BAR TO REMOVE PROP
USED WITH:
SHAFT ADAPTER TO REMOVE SHAFT
BUSHING PULLER- TO REMOVE BUSHING-
(MUST USE 1" TAP TO THREAD INNER
BUSHING FOR BUSHING PULLER INSERTION.)
USED WITH PULLER TO REMOVE SHAFT
USED WITH PULLER TO REMOVE BUSHING
TO INSTALL BUSHINGS
1" TAP USED TO THREAD INNER BUSHING FOR
INSERTION OF BUSHING PULLER FOR
REMOVAL OF BUSHING.
AFTER BUSHING INSTALLATION, USED TO
REAM THE BUSHING FOR PROPER SHAFT
PLACEMENT/FIT.
18" PIPE WRENCH
1/2" DRILL
8" OR 10" CRESCENT WRENCH
1 1/16" SOCKET OR COMBINATION WRENCH
1 1/8" DEEP SOCKET OR COMBINATION WRENCH
PAIR OF CHANNEL LOCK PLIERS
4 TO 5 LB HAMMER
5/16" DRILL BIT
7/8-9 10 TPI DIE NUT
7/8-9 10 TPI TAP
TOOLS
USED FOR
DRIVES
PRICE
$50
$50
$15
$20
$10
$40
$70
TOTAL $255.00
16
