  • Page 1 Bandit 240 PB Installation and User Guide ©2006 All rights reserved Bandit Solutions, Inc. Distributed by: Detection Dynamics, Inc. 6606 N. Lamar Blvd., Suite 300 Austin, Texas 78752 (512) 453-1133 • www.cctvpros.com...
  • Page 2: Safety Symbols

    Caution—Failure to observe the caution notice may cause injury or significantly disrupt or impair operation of Bandit 240 PB. Unpacking instructions Before installing Bandit 240 PB, open the shipping box and verify you have received the following items: • Bandit 240 PB •...
  • Page 3: Installation

    • Mount on a wall, shelf, or floor that can support 62 lbs. Site Selection • Position Bandit 240 PB such that the ejection nozzle points in the direction where intruders may enter, or in the area storing the objects you want to protect.
  • Page 4: Site Preparation

    Site Preparation • Heat from Bandit’s fog ejection may trigger PIRs. Replace PIRs with combination PIR-radar sensors that are triggered by both heat and movement; this reduces the chances of a false alarm during fog ejection.
  • Page 5 1. Select a mounting location. Be sure the location you select complies with the requirements listed in the section “Site selection” on page 3. 2. If you ordered the optional Handy-Boy jig, place Bandit 240 PB on the jig. 3. Connect power wires to Bandit.
  • Page 6: Electrical Connection

    Bandit 240 PB Installation and User Guide 7. Attach the mounting plate using screws 8. Position and secure Bandit on the mounting plate. 9. If you ordered the optional extended ejection nozzle, attach it to Bandit through the 2" hole. Proceed to “Electrical Connection.”...
  • Page 7: Connecting Accessories

    8. With a volt meter, test power at N and L terminals. Verify power is 110 VAC. 9. Replace the real jumper. Connecting Accessories You can install accessories to Bandit 240 PB that require 12 VDC power. Examples of accessories include the Jumbo LED or an external siren. 1. Mount the accessory.
  • Page 8: Maintenance

    Bandit 240 PB Installation and User Guide Indication Power Blinking red Power supply disconnected or main fuse blown and Bandit not in guard mode. The following table lists the conditions of the green LED on the HY-3 Pak sleeve. Solid green Canister installed properly and armed.
  • Page 9: Periodic Maintenance

    4. Unscrew the red Allen bolts on the canister assembly and remove the old canister. 5. Insert the new canister into the canister assembly and tighten Allen bolts. 6. Insert canister assembly into Bandit 240 PB and tighten Allen bolts. 7. Replace side hatch.
  • Page 10: Troubleshooting And Technical Support

    Bandit 240 PB Installation and User Guide Troubleshooting and Technical Support Leave all repairs to authorized persons and/or the manufacturer. For technical support, contact your distributor: Detection Dynamics, Inc. 6606 N. Lamar Blvd., Suite 300 Austin, Texas 78752 (512) 453-1133...
