Please find the description of each interface in the following table:
Panel Label
Top RST
Top Power
Top IN1
IN2
Top OUT1
OUT2
Bottom ETH
Bottom COM
Bottom SIM 1
Right ANT
User Manual NetBox Wireless Router
4-Jan-10
manual_netbox_e
Component Description
Restart: press this button when the status LED is on
Factory reset: press and hold this button for at least 5 seconds.
Voltage feed connector (9-28 VDC)
Digital inputs
2 optoisolated digital inputs. Please consider the polarity.
Digital outputs
2 relay outputs
Ethernet port
The default IP address is set to 192.168.1.1.
RS232, Sub-D 9 port
The factory default is 115200 Baud, 8 Data Bits, no parity, 1 Stop Bit.
SIM socket
GSM antenna connector
Impedance: 50 Ohm
Connector: SMA female
Table 4: NB2210 Physical interfaces
