Rogers personal TV Easy Installation Manual

Component Connection: This connection uses the Component (RGB) Video and RCA Audio cables, provided by
Rogers.
A
Connect the end of the Coaxial cable coming from your wall to the
CABLE IN port. Connect one end of the Component (RGB) and RCA
Audio cables to the matching coloured ports.
Note: Be sure to securely finger tighten all cable connections.
B
Connect one end of the power cord to the
back of the digital box and the other end to
the wall outlet.
Note: To ensure the digital box remains author-
ized and updated, keep the power cord
and Coaxial cable connected at all times.
Turn your HDTV on and set it to the input used in Step 3.
Most TVs can be connected
to multiple video sources
like DVD players and
VCRs. To view
programming from your
digital box, your HDTV
must be set to the input
selected in Step 3.
Change your HDTV input by
pressing the Input or Source button on the front
of the TV or by using your TV's remote control.
C
In addition to operating the digital box, the Rogers remote is capable of controlling basic commands on your
TV, VCR and other devices. To enable these features, the Rogers remote must be programmed for your
particular home entertainment components.
Program the Rogers remote for your TV.
Since the Rogers remote control is a universal remote, you can program it to control other components by
repeating the steps and substituting the TV button with the respective device button (VCR, DVD, etc.).
1. Turn your TV on.
2. Press the TV button on the Rogers remote.
3. Press and hold SETUP
4. Press 9 - 9 - 1, the TV button flashes twice.
5. Point the remote towards your TV and press PWR.
6. Repeatedly press and release the
cycle through all possible codes until a match is found.
Note: You may need to press the
match.
7. Once the TV turns off, press the
flash twice.
8. Confirm the correct code was locked by pressing the
What if this did not work?
Your remote should have come with a small guide that contains specific codes for programming popular
components. Consult that guide for futher instructions.
High Definition
Easy Installation Guide
Installing your Rogers digital box is as easy as A - B - C.
A

Connect The Digital Box To Your TV

B

Authorize The Digital Box

C

Program Your Rogers Remote And Additional Options

Connect The Digital Box To Your TV
Authorize The Digital Box
With your TV turned off and your Rogers
remote pointing towards the digital box, press
the CBL
Program Your Rogers Remote And Additional Options
until the TV button flashes twice.
CH+ button until your TV turns off. The remote will
CH+ button dozens of times before finding a
SETUP button to lock the code. The TV button will
Connect the other end of the Component (RGB) and RCA Audio cables
to the matching coloured ports on the back of your HDTV.
From Digital Box
Note: Remember the name of the Component port you selected, ex. COMP 1,
RGB 1, etc. You will need this for Step 7.
then PWR buttons on the remote.
Note:
Your Rogers remote can-
not be used to change
the HDTV input until it
has been programmed to
control your TV.
PWR button to turn on your TV.
Are you installing the digital box
yourself?
Yes: I am installing the digital box
myself. Continue to Step 2.
No: A technician installed my digital box
for me. Go to Section C below.
Wait for the time to appear on the digital
box.
Confirm the digital box is authorized.
1. Turn on the digital box by pressing
Rogers remote.
2. Change the channel to 03 by pressing
on your Rogers remote.
Is Channel 03 being displayed?
Yes: Continue to Section C , below.
No: Channel 03 is "Not Authorized".
Call 1 866 894 9962 to have the digital box
authorized. You will be asked for the phone
number associated with your account.
PWR on the
0 - 0 - 3
