SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY. THIS MANUAL IS PRINTED ON RECYCLED PAPER.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
PELLET STOVE
VF 100A
Freestanding & Fireplace Insert
OWNER'S MANUAL
Contact your building or fire officials about restrictions and
installation inspection requirements in your area.
PLEASE READ THIS ENTIRE MANUAL BEFORE INSTALLATION AND
USE OF THIS PELLET BURNING ROOM HEATER. FAILURE TO FOLLOW
THESE INSTRUCTIONS COULD RESULT IN PROPERTY DAMAGE, BODILY
INJURY, OR EVEN DEATH.
VF-50279
Advertisement
Table of Contents
Related Manuals for Vistaflame VF 100A
Summary of Contents for Vistaflame VF 100A
- Page 1 SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY. THIS MANUAL IS PRINTED ON RECYCLED PAPER. PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE PELLET STOVE VF 100A Freestanding & Fireplace Insert OWNER’S MANUAL Contact your building or fire officials about restrictions and installation inspection requirements in your area.
-
Page 2: Table Of Contents
Table of Contents Introduction..........................3 Rating Label Location......................3 Pellet Quality........................3 Important Safety Data....................4 Safety Warnings And Recommendations................4 Specifications...........................6 Dimensions - Freestanding....................6 Dimensions - Insert......................6 Operating Instructions.......................7 Control Board Functions....................7 Operating Your Pellet Stove.....................7 Turning Your Pellet Stove Off...................8 Slider/Damper Set-Up.....................8 Guidelines For Fine-Tuning For Fuel Quality...............9 Routine Cleaning and Maintenance...................10 Installation..........................13 Deciding Where to Locate your Pellet Appliance..............13... -
Page 3: Introduction
Introduction ATING ABEL OCATION Freestanding: The rating label is located on the inside of the hopper lid. Insert: The rating label is located on the hopper cover. ELLET UALITY Pellet quality is important, please read the following: Your Vista Flame pellet stove has been designed to burn wood pellets only. Do not use any other type of fuel, as this will void any warranties stated in this manual. -
Page 4: Important Safety Data
Introduction MPORTANT AFETY Please read this entire Owner’s Manual before installing or operating your Vista Flame Pellet Stove. Failure to follow these instructions may result in property damage, bodily injury or even death. Contact your local building or fire official to obtain a permit and any information on installation restrictions and inspection requirements for your area. - Page 5 Introduction ELECTRICAL: The use of a surge protected power bar is recommended. The unit must be grounded. The grounded electrical cord should be connected to a standard 115 volts (4.5 Amps), 60 hertz electrical outlet. Ensure the polarity to the outlet, the unit will be plugged into, is correct as incorrect polarity can affect the unit’s operation.
-
Page 6: Specifications
Specifications IMENSIONS REESTANDING " 22" (603mm) (559mm) " (867mm) " " (621mm) (620mm) Figure 1: Dimensions of VF100 Freestanding. IMENSIONS NSERT Regular Panel 40" (1016mm) Oversized Panel 46" (1158mm) 22" " (559mm) (601mm) " Regular Panel (322mm) " (766mm) Oversized Panel "... -
Page 7: Operating Instructions
Operating Instructions ONTROL OARD UNCTIONS 1. AUGER LIGHT: This green light will flash in conjunction with the auger pulse. 2. MODE LIGHT: Responsible for signaling the state of the control board. When the light is flashing the stove is in an automatic start mode or the thermostat has control of the unit. When the light is solid, the Heat Level Setting can be altered. -
Page 8: Turning Your Pellet Stove Off
Operating Instructions If this is the first time the unit has been started or the unit has run out of fuel, the auger will need to be primed. This can be done by restarting the unit five (5) minutes into its start-up or by putting a small hand full of pellets into the burnpot. -
Page 9: Guidelines For Fine-Tuning For Fuel Quality
Operating Instructions The easiest way to make sure that an efficient flame is achieved is to understand the characteristics of the fire. • A tall, lazy flame with dark orange tips requires more air – Open slider (pull out) slightly. •... -
Page 10: Routine Cleaning And Maintenance
Routine Cleaning and Maintenance NOTE: Do not use abrasive cleaners to clean the surface or any part of the stove. The following should be inspected periodically to ensure that the appliance is operating at its optimum and giving you excellent heat value: TOOLS REQUIRED TO CLEAN UNIT •... - Page 11 Routine Cleaning and Maintenance ASH PAN (2-3 days) Monitor the ash level every week. Remember that different pellet fuels will have different ash contents. Ash content is a good indication of fuel efficiency and quality. Refer to “Warnings and Recommendations” for disposal of ashes.
- Page 12 Routine Cleaning and Maintenance Installation of firebox backing: • Install the side panels in place. Insert center panel, hold the panels in place • Install the top rod by sliding it into one side panel then across into the other panel. Screw rod in place.
-
Page 13: Installation
Installation ECIDING HERE TO OCATE YOUR ELLET PPLIANCE 1. Do not install the stove in a bedroom or room where people sleep in. 2. Locate the stove in a large and open room that is centrally located in the house. This will optimize heat circulation. 3. -
Page 14: Installation Of Pedestal - Insert
Installation Remove the two (2) screws from the backside of the pedestal. Remove the two (2) screws from inside the pedestal. Figure 11: Screws to take out to remove insert unit from pallet. Figure 10: Screws to take out to remove freestanding unit from pallet. NSTALLATION EDESTAL NSERT... -
Page 15: Clearances To Combustibles - Freestanding
Installation LEARANCES TO OMBUSTIBLES REESTANDING When installing this unit on a combustible floor (for Back Wall example linoleum, hardwood flooring) a non-combustible hearth pad must be under the unit. The pad must extend 1" (25mm) at least the width of the appliance [22” (558 mm)] and at 1"... -
Page 16: Outside Fresh-Air Connection
Installation UTSIDE RESH ONNECTION Outside fresh air is mandatory when installing this unit in airtight homes and mobile homes. ������� ���� When connecting to an outside fresh air source, do not use plastic or combustible pipe. A 15⁄8” minimum (42 mm) ID (inside diameter) steel, aluminum or copper pipe should be used. -
Page 17: Vent Termination Requirements
Installation ERMINATION EQUIREMENTS IT IS RECOMMENDED THAT YOUR PELLET STOVE BE INSTALLED BY AN AUTHORIZED DEALER/INSTALLER. Table 1: Use in conjunction with Figure 19 for allowable exterior vent termination locations. Letter Minimum Clearance Description 24 in (61 cm) Above grass, top of plants, wood, or any other combustible materials. 48 in (122 cm) Beside/below any door or window that may be opened. -
Page 18: Mobile Home Installation - Freestanding
Installation OBILE NSTALLATION REESTANDING ● Secure the heater to the floor using the two holes in the pedestal. ● Ensure the unit is electrically grounded to the chassis of your home (permanently). ● Do not install in a room people sleep in. ●... -
Page 19: Horizontal Exhaust Through Wall Installation - Freestanding
Installation ORIZONTAL XHAUST HROUGH NSTALLATION REESTANDING Vent installation: install vent at clearances specified by the vent manufacturer. A chimney connector shall not pass through an attic or roof space, closet or similar concealed spaces, or a floor, or ceiling. Where passage through a wall or partition of combustible construction is desired, the installation shall conform to CAN/CSA-B365 Installation Code for Solid-Fuel-Burning Appliances and Equipment. -
Page 20: Through Wall With Vertical Rise And Horizontal Termination Installation - Freestanding
Installation 10. The pipe must extend at least 12” (30 cm) away from the building. If necessary, bring another length of pipe (PL type) to the outside of the home to connect to the first section. Do not forget to place high temperature silicone around the pipe that passes through the thimble. -
Page 21: Inside Vertical Installations - Freestanding
Installation NSIDE ERTICAL NSTALLATIONS REESTANDING 1. Choose a stove location that is ideal. See the section “D .” ECIDING HERE TO OCATE YOUR ELLET PPLIANCE 2. Place a non-combustible hearth pad where necessary. Rain cap 3. Place the unit on the hearth pad (if Flashing installed on a carpeted surface) and space the unit in a manner so when... -
Page 22: Hearth Mount Installation - Freestanding
Installation Rain cap Flashing 24" (61 cm) 3" (7.5 cm) Clearance 2" (5 cm) Support bracket Tee with cleanout 6" ���� ��� Type "L" ��������� ������ (15 cm) vent ����� ����� �� �������� Fresh air intake �������� �� ����� �� ���������... -
Page 23: Masonry Fireplace Installation - Fireplace Insert
Installation Rain cap Storm collar Seal plate (cover plate) Existing masonry flue Vent pipe (single wall stainless flex pipe or solid PL vent) Flexible vent connector (use this 5 foot [152cm] section of pipe to vent past fireplace damper or small shelf) Fireplace damper location Clean out tee... - Page 24 Installation Rain Cap Fresh-air intake Steel Plate or Flashing Flexible or Rigid 6" Stainless Steel Liner 4. Connect a tee or 90° degree elbow to the exhaust pipe. 5. This fireplace insert must installed with continuous chimney liner of 3” or 4”...
-
Page 25: Installation Into Factory Built Fireplaces
Installation NSTALLATION ACTORY UILT IREPLACES When installing the fireplace insert into a zero clearance fireplace, DO NOT cut or modify any factory firebox parts. If the fireplace insert does not fit into a zero clearance fireplace, we recommend you use a freestanding model and install as a hearth mounted unit. -
Page 26: Installation And Removal Of The Surround Panels - Insert
Installation NSTALLATION AND EMOVAL OF URROUND ANELS NSERT 1. Attach one side trim to the top trim, using a corner bracket (see Figure 33) to secure pieces together. There are two (2) main pieces to each corner bracket (see Figure 34). When installing the corner pieces into the trim, the “B FACE”... -
Page 27: Thermostat Installation
Installation HERMOSTAT NSTALLATION 1. Install the wall thermostat (12 or 24 Volt rated) in a location that is not to close too the unit but will effectively heat the desired area. 2. Connect the Thermostat or Timer using a 2 x 18 gauge wire from the unit to the thermostat. -
Page 28: Troubleshooting
Troubleshooting DO NOT: ● Hold the ON / OFF BUTTON down for circuit board model or hold the start-up switch down for timer control. This is a momentary contact switch and can be damaged if held down too long. ● Service the stove with wet hands. The stove is an electrical appliance, which may pose a shock hazard if handled improperly. - Page 29 Troubleshooting « Exhaust Temperature Sensor failure – Bypass sensor located on Exhaust Blower. If stove now operates properly, the unit may require cleaning or a new sensor. Contact your local dealer for service. « Check the Heat Level Indicator if a fire is not detected, or if the fire has gone out the #3 light will flash because the Exhaust Temperature Sensor’s contacts have opened.
- Page 30 Troubleshooting 9. The stove will not shut off. ü If the unit will not shut off, ensure that the thermostat (if equipped) is turned down below the room temperature (thermostat mode in the ON / OFF position). ü If the unit is in the HI/LOW mode the unit will not shut off but will go to an idle setting (LOW). Press the ON/OFF button to turn the unit off.
-
Page 31: Wiring Diagram
Wiring Diagram Armor Cable Supplied Grey Optional Exterior Vacuum Exhaust Blower Grey Switch Black White White Combustion Blue Brown Blower Exhaust Temperature Sensor Power Cord Brown Ground Black 115V 115V White Black Black White 220V 220V Brown Blue Thermostat Common 5 Amp Ignitor Fuse... -
Page 32: Parts List
Parts List Reference Description Part Number Number Exhaust Temperature Sensor 120°F (60°C) EC-001 Power Cord - 115V EC-042 Auger Motor - 115V EF-001 Convection Blower - 115V EF-002 Convection Blower Impeller EF-004 Convection Blower Insulator (Gasket) EF-006 Combustion Main Impeller EF-008 Combustion Cooling Impeller EF-009... - Page 33 Parts List Reference Description Part Number Number Auger Brass Bushings (Set of 2) EF-065 Firebox Liner Top Plate EF-066 3⁄4” ID Auger Collar with Set Screw EF-069 Knob 1 Inch Round EF-070 Freestanding Back Grill EF-097 Freestanding Hopper Lid With Handle EF-104 Fireplace Insert Ash Pan Drawer With Latch EF-105...
- Page 34 Parts List Reference Description Part Number Number Door Complete (Pre Jan 08) VF-50278 Door Complete (Post Jan 08) V100-100 Insert Regular Trim Only - Brass VF100-006 Insert Regular Trim Only - Nickel VF100-007 Insert Oversized Trim Only - Brass VF100-008 Insert Oversized Trim Only - Nickel VF100-009 Freestanding Pedestal Complete...
-
Page 35: Parts Diagram - Components
Parts Diagram - Components... -
Page 36: Parts Diagram - Steel
Parts Diagram - Steel... -
Page 37: Warranty
Industries, our commitment to the highest level of quality and customer service is the most important thing we do. Each VistaFlame stove is built on a tradition of using only the finest materials and is backed by our Exclusive Lifetime Limited Warranty to the original purchaser. With VistaFlame, you’re not just buying a stove, you’re buying a company with years of unequalled performance and quality. - Page 38 Limited Warranty on this stove. If unsure as to the extent of this Limited Warranty, contact your authorized VistaFlame dealer before installation. 10. Sherwood Industries Ltd. will not be responsible for inadequate performance caused by environmental conditions.
-
Page 39: Installation Data Sheet
21. The Limited Warranty does not cover any loss or damage incurred by the use or removal of any component or apparatus to or from the VistaFlame fireplace or stove without the express written permission of Sherwood Industries Ltd. and bearing a Sherwood Industries Ltd. label of approval. -
Page 40: Installation Data Sheet
Installation Data Sheet The following information must be recorded by the installer for warranty purposes and future reference. NAME OF OWNER: NAME OF DEALER: _________________________________________ _________________________________________ ADDRESS: ADDRESS: _________________________________________ _________________________________________ _________________________________________ _________________________________________ _________________________________________ _________________________________________ PHONE:___________________________________ PHONE:___________________________________ MODEL:___________________________________ NAME OF INSTALLER: SERIAL NUMBER:___________________________ _________________________________________ DATE OF PURCHASE: _____________...
