Summary of Contents for Wicked lasers S3 Arctic Series

  • Page 2 User’s Manual and Laser Safety Guide www.wickedlasers.com...
  • Page 3 F O R E W O R D First and foremost, we are laser enthusiasts. We desire nothing more than to achieve perfection in our craft. For us, pushing the limits of technology is part of our daily routine. It’s only impossible if we don’t try. As we continue to advance in our search for perfection, we’ve set benchmarks for others to follow and new limits for us to test.

  • Page 4: Table Of Contents

    Table of Contents S3 Arctic Series Technical Specifications We wanted to create the world’s most powerful handheld laser - we succeeded and inadvertently set a world record in doing so. We are S3 Arctic Series Diagram extremely proud to be included in the Guinness Book of World Records Using Your Laser: How to Power On for 2007.
  • Page 5 WWW.WI CKEDL ASER S. COM S3 Arctic Series Technical Specifications Model Name: S3 Arctic Series Laser Product Class: Wavelength: 445nm nominal center λ Lasing Medium: Laser Type: Direct Diode Laser Power: 0.7 Watt 1 Watt 1.4 Watt 2 Watt Beam Shape:...
  • Page 6 WWW.W I CK E D L A S E R S. C OM Laser Diagram Using Your Laser : How To Power On REMOVABLE FRONT LENS EMISSION / BATTERY INDICATOR BATTERY COMPARTMENT INTERLOCK PIN TAIL CAP SMARTSWITCH At the back of the laser, rotate endcap Insert one Li-Ion Type 18650 IMR Push the button located on the tail cap to counter clockwise to open.
  • Page 7 WWW.W I CK E D L A S E R S. C OM Using Your Laser : The SmartSwitch Using Your Laser : The SmartSwitch The S3 Series are the world’s first and only hand held lasers equipped with SmartSwitch™ technology. It combines both safety and intelligence by requiring the user to follow a protocol of simple clicks and click/holds to operate the device.

  • Page 8: Smartswitch Codes Recap

    WWW.W I CK E D L A S E R S. C OM Using Your Laser : The SmartSwitch Using Your Laser : The SmartSwitch SmartSwitch™ Codes Recap: ▪ Unlocking code - 3 quick clicks + 2 short holds will turn on the laser. ▪...

  • Page 9: Fda Compliant Endcap Diagram

    WWW.W I CK E D L A S E R S. C OM Color Perception Chart FDA Compliant Endcap Diagram Screw Safety Interlock How Intensely the Human Eye Perceives Different Colors Contact Guard Based on the human eye’s perception: Screw equal powers of green 532nm light is 20 times brighter than blue 445nm light, 8 times brighter than red 650nm...

  • Page 10: Using Your Fda Compliant Endcap

    WWW.W I CK E D L A S E R S. C OM Using Your FDA Compliant Endcap Safety and Maintenance CAUTION - Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. No scheduled maintenance necessary to keep the Do not take apart, modify or dismantle the laser or product in compliance.

  • Page 11: Lens Cleaning Procedure And Troubleshooting

    WWW.W I CK E D L A S E R S. C OM Lens Cleaning Procedure and Troubleshooting Types of Common Lens Problems What you need : Procedure : Dirty Lens Scratched Lens - The most common problem with your laser - A scratched lens may occur if you unit is a dirty lens.
  • Page 12 You will not be able to clean this as water has condensed inside the lens and/or crystal set. This condition can be repaired by Wicked Lasers, however, will not be covered in your warranty. A repair cost will apply.

  • Page 13: Class 4 Laser Safety Instructions

    WWW.W I CK E D L A S E R S. C OM Class 4 Laser Safety Instructions Class 4 Laser Safety Instructions DANGER CLASS 4 LASER : All visible lasers with beams over 500 milliwatts (1/2 watt) are classified as Class 4. EXTREME DANGER, MUST BE USED CAREFULLY ●...
  • Page 14 WWW.W I CK E D L A S E R S. C OM Class 4 Laser Safety Instructions Class 4 Laser Safety Instructions OTHER IMPORTANT SAFETY AND USE CAUTIONS: AVOID EXPOSURE TO BLUE LIGHT Blue laser light can cause photochemical eye damage. Avoid prolonged exposure to blue light (light from 530nm green to 380 ultraviolet can be DO NOT USE AS A LASER POINTER.

  • Page 15: Limitation Of Liability

    All S3 Arctic Series lasers come with a standard 12 Month Manufacturer’s Warranty. In no event shall Wicked Lasers or any of its subsidiaries or affiliates be liable for any indirect, special, incidental or Our warranty guarantees your laser to be free from defects in manufacture and consequential injury to persons or damage to property caused by the use of any of our products.
  • Page 16 Manufacturer’s Warranty This warranty does not include defects or damages attributable to misuse, normal surface weathering, or damages caused by accidents or fire or other casualty or force majeure or any other causes or occurrences beyond the manufacturer’s control. To claim your warranty, please send this form or email support@wickedlasers.com with the following information: Full Name: Address:...
  • Page 17 1-877-952-7377 Unit 1010, Miramar Tower, 132 Nathan Road, Tsim Sha Tsui Kowloon, Hong Kong www.wickedlasers.com | support@wickedlasers.com...
