Page 1: Ceiling And Floor Type
INSTALLATION MANUAL Ceiling And Floor Type KUIM 012 - 018 Thank you very much for purchasing our air conditioner, Before using your air conditioner, please read this manual carefully and keep it for future reference. - Page 2 If used as MULTI unit, please refer to the Installation & operation manuals packed with outdoor unit.
-
Page 3: Table Of Contents
Install according to this installation instructions strictly. If installation is defective, it will cause water leakage, electrical shock and fire. CONTENTS PAGE When installing the unit in a small room, take measures against to keep refrigerant concentration from exceeding allowable safety limits in the event of refrigerant leakage. PRECAUTIONS..................1 Contact the place of purchase for more information. -
Page 4: Installation Information
If the refrigerant leaks during installation, ventilate the An all-pole disconnection device which has at least 3mm area immediately. clearances in all poles , and have a leakage current that Toxic gas may be produced if the refrigerant comes into the may exceed 10mA, the residual current device (RCD) place contacting with fire. -
Page 5: Attached Fittings
4. ATTACHED FITTINGS Please check whether the following fittings are of full scope. If there are some spare fittings , please restore them carefully. NAME SHAPE QUANTITY 1.Hook Installation fittings 2.Hanging arm (on some models) 3. Remote controller (on some models) 4. - Page 6 5.2.2 Ceiling Installation 5.2 Install the main body(the unit with the water pump is not included) Installing Ø10 hanging screw bolts. (4 bolts) 5.2.1 Wall Mounting Installtion Please Refer to Fig.5-3 and Fig.5-4 for the hanging screw bolts distance Evaluate the ceiling construction and please install with Ø...
-
Page 7: Outdoor Unit Installation
For some of the models 60 please securely tighten the mounting Install the indoor unit. bolts on both sides.(Refer to Fig5-15). Hanging screw bolt Fig. 5-15 Hanging arm Fig.5-10 Remove the side board and the grille.(Refer to Fig. 5-10) (For models 48 and 60, do not remove the grille.) Fig. - Page 8 The piping length between the outdoor unit and the indoor 6.2 Figure of body size unit may not exceed the allowable piping length. In the case that the installation place is exposed to strong Split type outdoor unit wind such as a seaside, make sure the fan operating properly by putting the unit lengthwise along the wall or using a dust shield.(Refer to Fig.6-1) If possible, do not install the unit where it is exposed to...
- Page 9 3. Centrifugal fan type outdoor unit Table 6-1 unit：mm MODEL REMARK Fig.6-2 Fig.6-2 Fig.6-2 Fig.6-2 Fig.6-7 unit：mm Table 6-3 Fig.6-2 MODEL Fig.6-2 1174 1120 Fig.6-2 1174 1120 Fig.6-2 30-36 1381 1328 Fig.6-2 30-36 1394 1338 1245 Fig.6-3 1394 1338 Fig.6-2 1394 1338 783 1245...
- Page 10 3. Centrifugal fan type outdoor unit To change air outlet is necessary to interchange panels too. Fan outlet panel is attached to fan structure, which must be mounted as follow Fig.6-14 6.5 Moving and installation Fig.6-11 Since the gravity center of the unit is not at its physical center, so please be careful when lifting it with a sling.
-
Page 11: Install The Connecting Pipe
7. INSTALL THE CONNECTING PIPE Table 6-4 Description Check whether the height drop between the indoor unit and Outdoor Unit outdoor unit, the length of refrigerant pipe, and the number of the bends meet the following requirements: Vibration-proof rubber (The number of the bends less than 15) Anchor Bolt M10 Table 7-1 Drainage (Wide 100×Depth 150) - Page 12 Remove the protection cover of stop valve Bind the connecting pipe and the cables together tightly with binding tapes.Pass the bound connecting pipe through the wall conduct from outside. Be careful of the pipe allocation to do on damage to the tubing. Connect the pipes.
-
Page 13: Connect The Drain Pipe
Closing stop valve Manifold valve Remove the cap and turn the valve clockwise with the Multi-meter Pressure meter hexagon wrench. -76 cmHg Securely tighten the valve until the shaft contacts the Hi-lever Lo-lever main bodyseal. Charge hose Charge hose Make sure to tighten the cap securely. Vacuum pump For the tightening torque, refer to the table below. -
Page 14: Wiring
CAUTION The drain pipe of indoor unit must be heat insulated, or it will condense dew, as well as the connections of the indoor unit. Hard PVC binder must be used for pipe connection, and make sure there is no leakage. With the connection part to the indoor unit, please be noted not to impose pressure on the side of indoor unit pipes. -
Page 15: Test Operation
NOTE NOTE All the figures in this manual are for explanation Remark per EMC Directive 2004/108/EC. purpose only. They may be slightly different from the air For to prevent flicker impressions during the start of the conditioner you purchased.The actual unit shall prevail. compressor (technical process) - Page 16 The Specification of Power(indoor power supply) Table 9-1 MODEL 30~36 42~48 PHASE 1 P h a s e 1 P h a s e 1 P h a s e 1 P h a s e 1 P h a s e POWER FREQUENCY AND VOLT 208-240 V...
- Page 17 The Specification of Power(independence power supply) Table 9-5 MODEL 30~36 42~48 PHASE 1 P h a s e 1 P h a s e 1 P h a s e 1 P h a s e 1 P h a s e POWER (indoor) FREQUENCY AND VOLT...
-
Page 18: Indoor Unit
CAUTION The power supply is included in the power supply above mentioned can be applied to the table. Wiring figure Fig.9-5 Power supply Switch/Fuse (Available locally) Power wiring (indoor) Power linking wiring (Outdoor) Indoor Outdoor Unit Unit Ground wiring Strong elec-signal link wiring Ground wiring Weak elec-signal link wiring Ground the air conditioner properly in case to affect its anti-interference function... - Page 19 Fig.9-7 Power supply Power supply Switch/Fuse (Available locally) Power wiring (indoor) Power linking wiring (Outdoor) Unit Outdoor Unit Ground wiring ndoor Weak elec-signal link wiring Ground wiring Ground the air conditioner properly in case to affect its anti-interference function CAUTION A disconnection device having an air gap contact separation in all active conductors should be incorporated in the fixed wiring according to the National Wiring Regulation.
- Page 20 2190 NW 89 Place Doral, FL 33172 – USA Tel: (305)594-4972 - Fax (305) 499-4378 The design and specifications are subject to change without prior notice for product www.klimaire.com - sales@klimaire.com improvement.Consult with the sales agency or manufacturer for details...
