INSTALLATION & OPERATION
MANUAL
SP717 REV. A
Modulated Carrier Amplifier
DOC#: MN-717-A
SPONSLER CO.,
.
INC
Precision Industrial Flow Measuring Devices and Controls
2363 Sandifer Boulevard, Westminster, South Carolina 29693 USA
Voice: (864) 647-2065 FAX: (864) 647-1255
1-800-258-1165 www.sponsler.com
Advertisement
Table of Contents
Related Manuals for Sponsler MN-717-A
Summary of Contents for Sponsler MN-717-A
- Page 1 INSTALLATION & OPERATION MANUAL SP717 REV. A Modulated Carrier Amplifier DOC#: MN-717-A SPONSLER CO., Precision Industrial Flow Measuring Devices and Controls 2363 Sandifer Boulevard, Westminster, South Carolina 29693 USA Voice: (864) 647-2065 FAX: (864) 647-1255 1-800-258-1165 www.sponsler.com...
-
Page 2: Specifications
SPECIFICATIONS Temperature: Operating -40 to 85°C Storage -65 to 125°C Input Voltage: 6-28 VDC; 100mA max. Protected against polarity reversal Frequency 0-3500 Hz with 50 KHz carrier Signal Input: (requires Pickup Coil 1-1.3 mh) 6-28 VDC squarewave proportional to input voltage Signal Output: Minimum load 1K Short circuit protection... - Page 3 SP717 Modulated Carrier Amplifier pg 3 Sponsler Co., Inc. DOC#” MN-717-A BENCH TEST CALIBRATION PROCEDURE Required Equipment: Power Supply 6-28 VDC, Frequency Generator, Frequency Counter, Oscilloscope Test Procedure: Connect RF pickup coil to J1-1,2 Connect power supply positive & negative leads to J1-3,5 respectively Connect oscilloscope positive &...
- Page 4 SP717 Modulated Carrier Amplifier pg 4 Sponsler Co., Inc. DOC#” MN-717-A DATE REVISION RECORD AUTH TERMINAL LOCATION SIGNAL IN + 3.00 DIA. SIGNAL IN - DC INPUT + SIGNAL OUT + DC INPUT - Q1-4 POWER INDICATOR Q5-8 R1-6 OUTPUT SIGNAL INDICATOR LED 5.60...
