- Page 1 3.5" eSATA + USB 2.0 External Enclosure XE-311EX/SU...
-
Page 3: Table Of Contents
Tabele of Contents 1. Introduction 1.1 Features 1.2 Specifications 1.3 System Requirements 1.4 Package Contents 2. Installation 2.1 Installing the Hard Disk Drive 2.2 Installing the Driver 3. Operation 3.1 Device Controls 3.2 LED Indicators 3.3 Connecting to a PC with an eSATA Cable 3.4 Connecting to a PC with an USB Cable 3.5 Backing up Files 4. -
Page 5: Introduction
1. Introduction 1.1 Features - Supporting 3.5" SATA hard disk drives - Silent operation with fanless air-cooled aluminum housing and tray - Dual interface: eSATA and USB 2.0 - Maximum transfer rate up to 3Gbits/s (eSATA) or 480 Mbits/s (USB 2.0) - Plug and play;... -
Page 6: Specifications
1.2 Specifications - Interface: SATA HDD to eSATA + USB 2.0 - Power Supply: External 12V/2A AC adapter - Chipset: Oxford OXU921DS or J Micron JM20336 - Platforms: Windows XP/2000/Me/98SE/ Mac OS X or above - Display: LED display (power, HDD access) - Case material: Aluminum - Dimensions: 9.2"... -
Page 7: System Requirements
1.3 System Requirements - Windows XP/2000/Me/98SE - Mac OS X or above - SATA/eSATA or USB 1.1/2.0 Enabled System 1.4 Package Contents eSATA + USB 2.0 External Enclosure - eSATA to eSATA Cable - USB 2.0 (eSATA + USB 2.0 model only) Cable External AC adapter USB 2.0 driver CD... -
Page 8: Installation
2. Installation 2.1 Installing the Hard Disk Drive 1. Push the latch on the left hand side and hold it. 2. Draw the Control Board Tray outward from the Aluminum housing. - Page 9 3. Place a 3.5" SATA hard disk drive into the aluminum tray.
- Page 10 4. Slide the hard disk drive to the eSATA connnector on the Control Board.
- Page 11 5. Secure the hard disk drive with the four screws found in the screw bag as shown in the illustration.
- Page 12 6. Slide the Control Board Tray back into the Aluminum body.
- Page 13 7. The installation is completed.
-
Page 14: Installing The Driver
2.2 Installing the Driver (for USB 2.0 only) - Windows 98SE 1. Insert the driver CD into your CD-ROM. Run Setup.exe from the root directory of the CD. 2. Follow the on-screen instructions to copy the necessary files to your computer. 3. - Page 15 - Windows ME/2000/XP No drivers are required. - Mac OS 9.0 or above No drivers are required.
-
Page 16: Operation
3. Operation 3.1 Device Controls Power Switch Backup Button... - Page 17 3.1 Device Controls (eSATA Model) DC Jack eSATA Port...
- Page 18 3.1 Device Controls (eSATA + USB 2.0 Model) DC Jack eSATA Port USB Port...
-
Page 19: Led Indicators
3.2 LED Indicators Green: Hard Drive Access Blue: Power On... -
Page 20: Connecting To A Pc With An Esata Cable
3.3 Connecting to a PC with an eSATA Cable 1 . Slide the power switch to the "on" position. 2. Plug either end of the eSATA cable found in the package to the eSATA port of the enclosure. 3. Plug the other end of the eSATA cable to the eSATA port of the computer. 4. -
Page 21: Connecting To A Pc With An Usb Cable
3.4 Connecting to a PC with an USB Cable 1. Slide the power switch to the "on" position. 2. Plug the USB B Type connector of the USB cable found in the package to the USB port of the enclosure. 3. -
Page 22: Important Notices
4. Important Notices 1. Do NOT operate this product, if your hands are wet. 2. We recommend you to discharge static electricity by touching a metal object before operating this product. 3. To prevent data loss, do NOT disconnect power or restart this product when performing backup. - Page 24 VERSION 1.0...
