Page 1: Installation Guide
SWR • SWC • SWD INSTALLATION GUIDE ® OPERATOR SPECIALTY COMPANY, INC. CASNOVIA, MI 49318 • U.S.A. UL325 COMPLIANCE REQUIRES THE USE OF CONTACT EDGES OR PHOTOELECTRIC CONTROLS ON ALL AUTOMATIC OR REMOTELY-CONTROLLED GATE OPERATORS. Oct. 2005, Rev. 8... -
Page 2: Table Of Contents
Model SWC Mechanical Parts Exploded View ..........................26 Model SWC Mechanical Parts List ..............................27 Model SWR • SWC Control Box Exploded View and Parts List ....................28 Model SWD Mechanical Parts Exploded View ..........................29 Model SWD Mechanical Parts List ..............................30 Model SWD Control Box Exploded View and Parts List ........................ -
Page 3: Pre-Installation Information
Verify that the voltage to be used matches the voltage of the resistance and drag. operator. The following contact or non-contact obstruction detection devices have been approved for use with OSCO slide gate operators as part of a UL325 compliant installation: Contact Edges: Miller Models*: MG0-20, MGR-20, MGS-20, and ME-120 Photoeyes: 2520-441 MMTC Model IR-55 photoeye, 165’... -
Page 4: Wiring Specifications
8760 Twisted Pair Shielded Cable (or equivalent) only – 4. All control devices are now 24VDC, which can be run con- OSCO part number 2500-1982, per foot). See page 10 for siderable distances. details of this connection, as well as dip switch selection. -
Page 5: Pad Mounting Instructions
SWR • SWC • SWD OPERATOR INSTALLATION GUIDE PAD MOUNTING INSTRUCTIONS NOTE: Maximum gate opening angle is approximately 95 degrees, depending on gate width. If larger opening angle is required, non-standard positioning of the operator and modified articulat- ing arms will be required. Contact the factory for pricing and availability. -
Page 6: String Method For Nonstandard Installation Of Swing Gate Operators
SWR • SWC • SWD OPERATOR INSTALLATION GUIDE STRING METHOD FOR NONSTANDARD INSTALLATION OF SWING GATE OPERATORS Step A: Position the Operator 1. Connect the gate plate assembly onto the gate at the recommended location for a standard installation (Dimension “W”). -
Page 7: Articulating-Style Arm Assembly Instructions
SWR • SWC • SWD OPERATOR INSTALLATION GUIDE WELDED STYLE GATE ARM INSTALLATION INSTRUCTIONS The welded style gate arm has been pre-assembled at The gate plate supplied with the arm assembly can be the factory in right-hand configuration (the back of the welded to the gate as shown above. -
Page 8: Vent Plug Installation
VENT PLUG INSTALLATION Gear reducers used in OSCO gate operators will have solid plugs installed prior to shipment in order to keep the oil inside from spilling out during shipping. A vent plug has been provided to replace this plug during installation. This plug will look similar to the ones shown below. -
Page 9: Electrical Connection And Adjustments
CONTROL BOX ACCESS AND REMOVAL The control box in models SWR, SWC and SWD is hinged for flip-down access and can be removed without taking off the operator cover. Start by pulling down the plunger located on the left side of the control box. While holding the plunger down, slide the control box to the right until the hinges have come apart. -
Page 10: Control Board Adjustments
SWR • SWC • SWD OPERATOR INSTALLATION GUIDE CONTROL BOARD ADJUSTMENTS LIMIT SWITCH L.E.D.s LIMIT SWITCH CONNECTOR TERMINAL STRIP #1 CONNECTOR 3A Fuse 2A Fuse BRAKE TERMINAL STRIP #2 DIAGNOSTIC RESISTOR CONNECTOR L.E.D.s NOTE: DO NOT FORCE 270-DEGREE POTENTIOMETERS BEYOND THEIR NORMAL RANGE OF MOTION... -
Page 11: Terminal Connection Descriptions
(See page 10 for details.) You must follow all required safety precautions and instructions at all times. Review the safety brochure included with the operator. If any pages are missing or unreadable, contact OSCO at 1-800-333-1717 to request additional copies. -
Page 12: Current Sensing Adjustments
Because gates vary in construction and may have different force requirements in the open and close directions to move, the OSCO control board has separate Multi-turn potentiometers for adjusting in both directions independently. The adjustment should be set light enough to maintain minimal force (40 lbs.) should an obstruction occur, but high enough to keep the gate moving under normal conditions without interruption. -
Page 13: Onboard L.e.d. Indicator Descriptions
SWR • SWC • SWD OPERATOR INSTALLATION GUIDE ONBOARD L.E.D. INDICATOR DESCRIPTIONS Control Board L.E.D. Indicators: OPEN This indicator is lit when an open signal is present. This signal can come from such devices as button stations, radio receivers, keypads and telephone entry systems. -
Page 14: Charger Board Sleep Mode
SWR • SWC • SWD OPERATOR INSTALLATION GUIDE CHARGER BOARD SLEEP MODE When primary AC power is not available, the operator will continue to JUMPER CAP WAKE operate in battery only mode if the charger board is set in its RUN mode... -
Page 15: Important Notes For Installation Of Master/Slave Applications
SWR • SWC • SWD OPERATOR INSTALLATION GUIDE IMPORTANT NOTES FOR INSTALLATION OF MASTER/SLAVE APPLICATIONS When setting up Master/Slave gate operators, it is best to make adjustments and run each operator individually. To do this, simply: a. Set Dip Switch #4 to proper hand of operation (right-hand or left-hand) b. -
Page 16: Control And Accessory Connection Illustrations
SWR • SWC • SWD OPERATOR INSTALLATION GUIDE CONTROL and ACCESSORY CONNECTION ILLUSTRATIONS - 16 -... - Page 17 SWR • SWC • SWD OPERATOR INSTALLATION GUIDE CONTROL and ACCESSORY CONNECTION ILLUSTRATIONS - 17 -...
- Page 18 SWR • SWC • SWD OPERATOR INSTALLATION GUIDE CONTROL and ACCESSORY CONNECTION ILLUSTRATIONS - 18 -...
- Page 19 SWR • SWC • SWD OPERATOR INSTALLATION GUIDE CONTROL and ACCESSORY CONNECTION ILLUSTRATIONS AC MODELS ONLY - 19 -...
-
Page 20: Loop Layout Illustration
SWR • SWC • SWD OPERATOR INSTALLATION GUIDE LOOP LAYOUT ILLUSTRATION Refer to Connection Descriptions on page 11 and Loop Accessory Connections on page 19 for additional details. - 20 -... -
Page 21: Edge Layout Illustration
SWR • SWC • SWD OPERATOR INSTALLATION GUIDE EDGE LAYOUT ILLUSTRATION Refer to Connection Descriptions on page 11 and Contact Edge Connections on page 18 for additional details. - 21 -... -
Page 22: Photoeye Illustration
SWR • SWC • SWD OPERATOR INSTALLATION GUIDE PHOTOEYE ILLUSTRATION Refer to Connection Descriptions on page 11 and Photoeye Accessory Connections on page 18 for additional details. - 22 -... -
Page 23: Troubleshooting
Replace if necessary. HOW TO ORDER REPLACEMENT PARTS Use the part numbers listed on the following pages. Contact your local OSCO dealer or distributor to order parts. 1. Supply the model number and serial number of your operator. -
Page 24: Model Swr Mechanical Parts Exploded View
SWR • SWC • SWD OPERATOR INSTALLATION GUIDE MODEL MECHANICAL PARTS EXPLODED VIEW - 24 - 3-05-6... -
Page 25: Model Swr Mechanical Parts List
SWR • SWC • SWD OPERATOR INSTALLATION GUIDE MODEL MECHANICAL PARTS LIST REF. REF. PART NO. DESCRIPTION PART NO. DESCRIPTION 2300-925-BEIGE Operator Cover, tan 2500-2347 Limit Switch 2300-925-BLACK Operator Cover, black 2300-925-GRANIT Operator Cover, granite 2510-350-A Power On/Off Switch Assembly, 115V... -
Page 26: Model Swc Mechanical Parts Exploded View
SWR • SWC • SWD OPERATOR INSTALLATION GUIDE MODEL MECHANICAL PARTS EXPLODED VIEW - 26 - 3-05-6... -
Page 27: Model Swc Mechanical Parts List
SWR • SWC • SWD OPERATOR INSTALLATION GUIDE MODEL MECHANICAL PARTS LIST REF. REF. PART NO. DESCRIPTION PART NO. DESCRIPTION 2300-925-BEIGE Operator Cover, tan 2100-2020-PLT Drive Shaft 2200-015 Shaft Collar, 1” diameter, 9/16 LTB 2300-925-BLACK Operator Cover, black 2100-519-PLT Sleeve Spacer... -
Page 28: Model Swr • Swc Control Box Exploded View And Parts List
SWR • SWC • SWD OPERATOR INSTALLATION GUIDE • MODELS CONTROL BOX PARTS LIST PART NO. DESCRIPTION PART NO. DESCRIPTION 2100-1778-PLT Control Box Wrapper 2300-696 Clear Control Box Cover 2100-1762 Terminal Strip Bracket, output side 2200-940 Pull Pin Disconnect 2100-1761... -
Page 29: Model Swd Mechanical Parts Exploded View
SWR • SWC • SWD OPERATOR INSTALLATION GUIDE MODEL MECHANICAL PARTS EXPLODED VIEW - 29 - 3-05-6... -
Page 30: Model Swd Mechanical Parts List
SWR • SWC • SWD OPERATOR INSTALLATION GUIDE MODEL MECHANICAL PARTS LIST REF. REF. PART NO. DESCRIPTION PART NO. DESCRIPTION 2500-2347 Limit Switch 2300-925-BEIGE Operator Cover, tan 2300-925-BLACK Operator Cover, black 2510-266-D Power On/Off Switch Assembly 2300-925-GRANIT Operator Cover, granite... -
Page 31: Model Swd Control Box Exploded View And Parts List
SWR • SWC • SWD OPERATOR INSTALLATION GUIDE MODEL CONTROL BOX PARTS LIST PART NO. DESCRIPTION PART NO. DESCRIPTION 2100-1778-PLT Control Box Wrapper 2200-940 Pull Pin Disconnect 2100-1762 Terminal Strip Bracket, output side 2500-867 Alarm, 24VDC (not shown) 2100-1761 Terminal Strip Bracket, input side 2200-122 Heyco Bushing, .87 diameter... -
Page 32: Model Swr • Swc • Swd Gate Arm Assembly Parts List
SWR • SWC • SWD OPERATOR INSTALLATION GUIDE • • GATE ARM ASSEMBLY PARTS LIST PART NO. DESCRIPTION 2120-493 Complete Arm Assembly 2100-2068-PLT Threaded Crank Block 2100-2069-PLT V-Block for Crank Block 2100-2067 Crank Extension Solid Bar 2110-810 Crank Extension and Spacer Assembly... -
Page 33: Model Swd Battery Maintenance And Brush Replacement
SWR • SWC • SWD OPERATOR INSTALLATION GUIDE MODEL SWD BATTERY MAINTENANCE The gel-cell batteries in this operator require no routine maintenance. For assured continued performance, they should be replaced every year. If power is to be removed for one week or more, disconnect the negative wire from the batteries as this will prevent deep discharging. - Page 34 MATERIAL SAFETY DATA SHEET MOBIL SHC 634 1. PRODUCT AND COMPANY IDENTIFICATION PRODUCT NAME: MOBIL SHC 634 SUPPLIER: EXXONMOBIL CORPORATION 3225 GALLOWS RD. FAIRFAX, VA 22037 24 - Hour Health and Safety Emergency (call collect): 609-737-4411 24 - Hour Transportation Emergency (Primary) CHEMTREC: 800-424-9300 Product and MSDS Information: 800-662-4525 703-846-6691...
- Page 35 Imperial Oil MATERIAL SAFETY DATA SHEET HANDLING, STORAGE AND SHIPPING: Keep containers closed. Handle and open Date Prepared: February 02, 1996 containers with care. Store in a cool, well ventilated place away from incompatible Supersedes: January 07, 1995 materials. Do not handle or store near an open flame, sources of heat, or sources of MSDS Number: 225570 ignition.
- Page 36 SWR • SWC • SWD OPERATOR INSTALLATION GUIDE - 36 -...
-
Page 37: Preventative Maintenance
• Keep clear of gate during operation. GENERAL: OSCO gate operators are designed for many years of trouble-free operation and, under recommended operating conditions, will require only minimal maintenance. To ensure that your unit is ready for operation at all times--and to preclude serious damage or failure--inspect the unit systematically. -
Page 38: Gate Operator Installation Checklist
SWR • SWC • SWD OPERATOR INSTALLATION GUIDE GATE OPERATOR INSTALLATION CHECKLIST CUSTOMER INSTALLER ________ ________ 1. The gate has been checked to make sure it is level and moves freely in both directions. ________ ________ 2. Potential pinch areas have been guarded so as to be inaccessible OR have contact and/or non-contact obstruction sensing devices installed.
