Apply silicon paste to the instrument connection pins at the back of the instrument.
Press the jack plug onto the instrument pins. Press the cable in to the cable leads.
•
Mount the connection back cover with the screw.
3

First start

3.1

Initialising the instrument

You will be asked to press SET (PrESkey) on the instruments
the very first time after installation. This will give the instrument
a logical ID number that belongs to your specific Nexus
Network.
Press SET, on each installed instrument, one at the time.
Always wait for the text 'Init OK' to be displayed,
before you press SET on the next instrument!
The first unit ID number is 16, then 17 and so on in the order
which you press SET.
The example shows that the Sea Data instrument version
number is 1.0 and that the instrument was given the logical ID
number 16.
The bottom row in the Sea Data shows the software version
(4.8) and ID number (0) of the network master (WSI-box or
Server).
When the NX WSI-box is network master, the ID number is 2
When the NX2 Server is network master, the ID number is 0
