Stove Guard Guardian COOKTOP Installation & Operating Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Thank you for your purchase. STOVE GUARD is an electronic safety device for use with electric stoves. It turns the stove
OFF when you forget by using the advanced technology found in security monitoring devices and a specially
programmed micro controller.
STOVE GUARD controls the stove's electrical system to help prevent food and pots from burning, as well as reducing the
risk of fire caused by unattended cooking.
STOVE GUARD is preset at the factory at the highest fire safety setting.
This is the recommended setting for use by anyone with Alzheimer's or similar medical condition.
  When properly installed, adjusted, and set in AUTO mode, STOVE GUARD will automatically shut the
electric stove OFF if no one is present in the monitored cooking area for a preset period of time.
  Upon returning to the cooking area, STOVE GUARD will detect their presence and automatically turn the
stove ON again. The preset time will reset to the last setting.
  STOVE GUARD also can be used in a TIMER mode to set a maximum cooking time, after which the
stove will be automatically turned OFF.
Installation of the STOVE GUARD COOKTOP Model requires a licensed Electrician to be wired properly according to
local electrical codes.
Do not disassemble any of the components. There are no user serviceable parts inside. Refer servicing to a qualified person
only.
DO NOT INSTALL
the EMU (Electronic Monitoring Unit):
Directly above a heat source or where hot/cold air or steam will blow onto it.
On or above a microwave or toaster oven,
directly, on or above the stove.
Do not allow grease to build up on the sensing unit. This will reduce STOVE GUARD's sensing range and possibly turn the
stove OFF even when someone is at the stove.
Clean the outer surface of the EMU with a clean, damp cloth only. Do not use soaps or cleaning liquids.
STOVE GUARD must be tested with the individual who requires this device and adjusted to their personal needs, as
well as adjusted to the home environment of use to ensure proper functioning. Additional fire safety devices; such as
smokedetectors & fire extinguishers must also be used to ensure complete cooking fire safety.
Please Keep This Manual for Future Reference
Guardian COOKTOP Model
IMPORTANT WARNING
IMPORTANT TECHNICAL SAFEGUARDS
Page 1 of 10
INSTALLATION & OPERATING MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the Guardian COOKTOP and is the answer not in the manual?

Questions and answers

Related Manuals for Stove Guard Guardian COOKTOP

Summary of Contents for Stove Guard Guardian COOKTOP

  • Page 1 On or above a microwave or toaster oven, directly, on or above the stove. Do not allow grease to build up on the sensing unit. This will reduce STOVE GUARD's sensing range and possibly turn the stove OFF even when someone is at the stove.

  • Page 2: Power Box

    3. Rocker Switch to Control 120V Power (Must be set during installation) 4. EMU Cord Opening Front 5. Mounting Brackets View 6. Control Cord to EMU Sensor/Timer EMU - ELECTRONIC MONITORING UNIT STOVE GUARD AUTO SG OFF STOVE OFF GUARDIAN TIME SENSOR TIMER 8.

  • Page 3: Mounting To The Wall

    (the stove doesn’t draw current). Turn on a burner. Stove Guard should detect current, display will show 01. Test the Stove Guard by standing out of the EMU's sensor detection area. After 1 minute, power to the stove burner should shut off.
  • Page 4 The green AUTO indicator lights. Green movement indicator lights every time when movement is detected and resets clock to the preset time. Display will show number of minutes left before Stove Guard turn off the stove if no movement is detected.
  • Page 5 For the safety reason, after a power failure, if power goes off and return back, the Stove Guard will "wake-up" in AUTO mode with stove shut off. Display shows PO. The infrared sensor will not reset clock to preset time until user press any button.
  • Page 6 Turn off counter: The Stove Guard has added a counter cycle that will record each time the unit turns the stove off. This feature is important for managed-care type situations to monitor the users use, to determine how many times they forgot about their electric stove.

  • Page 7: Troubleshooting

      To RAISE the detection field when the EMU cannot be located higher, slowly turn the screw to the LEFT . 2. STOVE GUARD is not detecting the movements of the user because its location is set very high up; the user is very short, or seated in a wheelchair.
  • Page 8 When there was a loss of power (Electrical Outage) the STOVE GUARD keeps the stove turned off until user press any button. The Stove Guard keeps user settings. There is no need to be adjusted to your own personal needs again.
  • Page 9 CABLE_TO_MONITOR SWITCH_DPDT 12V DC 10A - 250V AC Save on Security Title: POWER BOX Fail-Safe Project: Stove Guard File: POWBOXFS.PDF Page: Number: Date: September 2006. Rev. : NOTE: User has to add wires drawn in blue. Page 9 of 10...
  • Page 10 User has to add wires drawn in this picture. Phase 1 drawn in red; Phase 2 black; Ground green ;Neutral yellow (white wires in real) Transformer Current transformer through House’s Power To the Stove Page 10 of 10...
