OWNER'S MANUAL

READ BEFORE USE!

WARNING
USE PROPANE GAS ONLY!
-Do not store or use gasoline or other flammable
vapors in the vicinity of this or any other
appliance.
-Service must be performed by a qualified
installer, service agency or the gas supplier.
WARNING
WARNING
For use with cylinders marked PROPANE only.
DO NOT connect to a remote gas supply.
If the firebowl is stored indoors,detach ans leave
propane cylinder outdoors.
Design certified under ANS Z21.97-2010 Standard for
Outdoor Decorative Gas Appliances & CGA CR97-003
Requirements for Outdoor Gas Fireplaces.
DANGER
Factory No.:
For Outdoor Use Only! Use Propane Gas Only !
Propane cylinders sold separately.
adjustment,alteration,service or maintenance can cause
injury or property damage. Read the owner's manual
thoroughly before installing or servicing this equipment.
If the information in this manual is not followed exactly,
a fire or explosion may result causing property damage,
personal injury or loss of life.
The propane cylinder must be disconnected
when this firebowl is not use.
If you smell gas:
1.Shut off gas to the appliance.
2.Extinguish any open flame.
3.If odor continues, keep away from the appliance and
immediately call your gas supplier or fire department.
This firebowl must be attended at all times!
An LP-cylinder not connected for use shall not be stored
in the vicinity of this or any other appliance.
CARBON MONOXIDE HAZARD
This appliance can produce carbon monoxide
which has no odor.
Using it in an enclosed space can kill you.
Never use this appliance in an enclose space
such as a camper, tent, car or home.
1
Style No.: 67229
WARNING
WARNING
Improper installation,
WARNING
DANGER
DANGER
WARNING
WARNING

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the firebowl and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for BOND MANUFACTURING firebowl

  • Page 1 1.Shut off gas to the appliance. DO NOT connect to a remote gas supply. 2.Extinguish any open flame. If the firebowl is stored indoors,detach ans leave 3.If odor continues, keep away from the appliance and propane cylinder outdoors. immediately call your gas supplier or fire department.
  • Page 2 *Do not store a spare or disconnected propane cylinder under or near this firebowl. *After a period of storage, and/or non use, the propane firebowl should be checked for gas leaks and burner obstructions before use. *Do not operate the propane firebowl if there is a gas leak present.
  • Page 3 *The gas pressure regulator provide with the propane fire bowl must be used. *Do not attempt to disconnect the gas regulator or any gas fitting while your firebowl is in operation. *A dented or rusty propane cylinder may be hazardous and should be checked by your gas supplier prior to use.
  • Page 4 *Do not light or use gas unit if lava rocks are wet. Ensure lava rocks are completely dry before igniting as intense heat could cause the rock to crack. *Lava Rocks could hit somebody's face or eyes during initial start of this unit, so please keep away from the firebowl for the first 20 minutes after it has been ignited.
  • Page 5 ITEM ITEM SPECIFICATION SPECIFICATION Guard M4*10 screws Ignition Pin M5*120 Screws M6*10 Screws ¢7 Washer Fire Bowl Plate Thermocouple M4 Nut Grounding Wire Venturi Tube ¢6 Washer Control Knob M5 Nut Gas Valve Heat Insulation Board Pulse Ignition Ripple Pipe Regulator M8*30 Wing Screw Control Panel...
  • Page 6 OFF before assembling. See Figure I. (II) Open the storing door on the firebowl for the gas tank. See Figure I. (III) Put the gas tank in the metal stand. Make sure the gas tank sits on the metal stand completely.
  • Page 7 Before each use, inspect all hose. Replace hose if there are any signs of cutting, wear or abrasion. (1) Turn the cylinder valve on the gas tank counter-clockwise to open the gas supply. (2) Close the storing door on the firebowl for the gas tank. (3) Light the firebowl as below steps:...
  • Page 8 ※The propane cylinder must be disconnected and removed from the firebowl before the appliance can be stored indoors. ※Make sure both the gas and the firebowl are turned off before changing battery. Please refer to the process of assembling battery.
