K a r i z m a
Introduction
The purpose of this user guide is to describe how to operate Karizma plus system. Some of the features
described in this guide may not be applicable to your installation and should be ignored. The engineer from the
alarm company will have completed the System Information Sheet (SIS) in this guide which gives information
specific to your installation. You will need to refer to this as you read this guide in order to check if certain
features have been used. If in any doubt consult your alarm company.
Alarm company (Installer) name: __________________________________________
Telephone number: _____________________________________________________
Account number: _______________________________________________________
Installation date: _______________________________________________________
TM
Plus
Intruder alarm system
Operating instructions
1
Advertisement
Table of Contents
Related Manuals for Novar ED&S Karizma Plus
Summary of Contents for Novar ED&S Karizma Plus
-
Page 1: Operating Instructions
K a r i z m a Plus Intruder alarm system Operating instructions Introduction The purpose of this user guide is to describe how to operate Karizma plus system. Some of the features described in this guide may not be applicable to your installation and should be ignored. The engineer from the alarm company will have completed the System Information Sheet (SIS) in this guide which gives information specific to your installation. - Page 2 Operating instructions Entry Codes Keypad and Entry Before you can do anything with Karizma+ you will codes need to key in a code using one of the keypads. There are several types of entry code, which permit different levels of control over the system. Check the Keypads System Information sheet to see which codes have Plus...
-
Page 3: Setting The System
Karizma Plus Part-Set the System Setting the A part-set allows detection points in part of the system protected premises to be set (turned on), while those in other areas are not set. In a domestic installation it is usual for a part-set to be programmed for use at Fully Setting the system night time. -
Page 4: Front Door
Operating instructions Performing a Quick-Set Omitting points during setting It is possible to override the programmed exit time by It is possible to omit one or more detection points use of the Quick Set function. This always gives you when you set the system. The omitted points will not 3 seconds to vacate the protected area. -
Page 5: Unsetting The System
Karizma Plus Unsetting the System Unsetting the Entering the premises by the designated entry route system will cause the entry period to start. The inside sounder will emit a slow beep-beep-beep sound. You must now key in your code and press the ENTER key at the Cancelling the Exit procedure nearest available keypad to cancel the entry period. -
Page 6: Engineer Reset
Operating instructions Resetting after an Alarm Silence Alarm and After an alarm the system will need to be reset by Reset system entering a suitable reset code. The display will alternate between the alarm cause and a prompt to enter a reset code. Silencing an Alarm Enter Your If an alarm occurs whilst you are in or near to the... -
Page 7: Remote Reset
Karizma Plus Fault Lockout Remote Reset If the system needs to be reset by an engineer code System Unset by you may need to call out the engineer. Before you do STEVE this, check the SIS to see if either the Remote Reset or Anti-code Reset options have been enabled. - Page 8 Operating instructions Cleaner Access Group Shunt Karizma+ has a code which permits selected areas of The Group shunt facility allows part of the protected the protected premises to be unset for the purpose of premises to be unset without unsetting the whole cleaning or maintenance.
-
Page 9: User Reset
Karizma Plus MENU 1 - Set System Manager Facilities Menu 1 allows the manager to set the system. Go to this menu and press the ENTER key. The manager code is normally used to carry out 1) Set System? system management functions. It is used to allocate and delete other user codes, test the system, view the event memory, etc. - Page 10 Operating instructions MENU 4 - Change User Type MENU 5 - Change User Code and Name Each user has a 2 to 6 digit code. Menu 5 allows this code to be changed. Use the ç and è keys to Menu 4 allows you to add, change or delete users select the code to be changed and press the ENTER from the system.
-
Page 11: Time And Date
Karizma Plus MENU 7 - Omit 24 hour points MENU 8 - Set Time and Date A 24H point is armed all of the time, whether the Select menu 8. The keypad displays the current time system is set or not. Violating that point will always in 24 hour format, so 1am is 13:00. - Page 12 Operating instructions MENU 9 - Walktest MENU 10 - Test OUTPUTS The walktest allows you to check the operation of all Menu 10 allows you to test any of the outputs from the of the security points in your system in order to prove system.
- Page 13 Karizma Plus System Information Sheet (SIS) Detection Points...
- Page 14 Operating instructions Programmes Programme Enabled Exit Entry time Exit Local Entry/exit Mode time alarm route ü Level Normal Manager, User number Code Cleaner and Duress Signalling Device fitted Engineer Reset Permit Entry Deviate Remote Reset Anti-code Reset Bell time minutes Bell delay minutes...
- Page 15 Karizma Plus Notes...
-
Page 16: For Technical Support
Operating instructions For Technical Support ¤ : 0906 302 0999 This is a premium rate line, calls are charged at 50 pence per minute Novar ED&S The panel conforms to the The Arnold Centre requirements of the European EMC Paycocke Road and Low Voltage directives, and Basildon carries the CE mark.
