- Page 1 UltraVista SX VIDEO WALL CONTROLLER Installation and Operations Manual Part Number VWL-S122DV 10707 Stancliff Road Phone: (281) 933-7673 Houston, Texas 77099 WWW.ROSE.COM...
- Page 3 UltraVista™ SX to be in good working order for one year from the date of purchase from Rose Electronics or an authorized dealer. Should this product fail to be in good working order at any time during this one-year warranty period, Rose Electronics will, at its option, repair or replace the Unit as set forth below.
-
Page 4: Table Of Contents
Page # Disclaimer ...................... 1 System Introduction ..................1 Features ..................... 2 Package Contents ..................2 Rose Electronics web site ................2 Product Registration ................... 2 System Overview ................... 3 UltraVista SX MODEL ..................3 UltraVista SX Installation ................4 Operation ....................... -
Page 5: Disclaimer
Thank you for choosing the Rose Electronics UltraVista™ SX. The UltraVista SX is the result of Rose Electronics commitment to providing state-of-the-art solutions for today’s demanding workplace. The UltraVista SX has proven to be a valuable investment for any home, business or office that has a need to quickly and easily display a single video source on four monitors, each showing ¼... -
Page 6: Features
Rose Electronics web site Visit our web site at www.rose.com for additional information on the UltraVista SX and other products offered by Rose Electronics that are designed for data center applications, classroom environments, digital wall/signage displays, industrial / military systems, and many other access and switching applications. -
Page 7: System Overview
OVERVIEW System Overview The UltraVista SX is a versatile and dynamic video wall system that can be easily and quickly set up in almost any location. The UltraVista SX can take any DVI-D source (video or image) and display it on a 2x2 video array. Each display monitor shows ¼... -
Page 8: Ultravista Sx Installation
INSTALLATION UltraVista SX Installation Installation of the UltraVista SX consists of: 1. Connect your single-link DVI-D video source to the DVI-I input connector on the rear panel of the UltraVista SX using a DVI-D mm cable. (Optionally, connect to a 1x2 DVI video splitter as shown) (NOTE: The connectors on the UltraVista SX are DVI-I connectors but the input video must be single-link DVI-D) 2. -
Page 9: Operation
To set the UltraVista SX up to “Learn” the monitor specifications (DDC), press and hold both the SCROLL and ENTER buttons on the front panel until the set-up menu displays on the front panel LCD screen. Press the SCROLL button to cycle through the options. When the needed Learn mode is displayed (Learn PC, Learn Mac, Learn Screen, or Exit), press Enter to execute the learn function. -
Page 10: System Troubleshooting
TROUBLESHOOTING System Troubleshooting No Image on one or more monitors Check that the monitor is turned on Check that the power source for the monitor is turned on Make sure the LCD panel power cables are securely fastened to the monitor and to the power source ... -
Page 11: Safety
SAFETY Safety The UltraVista SX has been tested for conformance to safety regulations and requirements, and has been certified for international use. Like all electronic equipment, the UltraVista SX should be used with care. To protect yourself from possible injury and to minimize the risk of damage to the Unit, read and follow these safety instructions. -
Page 12: Service Information
This Unit does not contain any internal user-serviceable parts. In the event a Unit needs repair or maintenance, you must first obtain a Return Authorization (RA) number from Rose Electronics or an authorized repair center. This Return Authorization number must appear on the outside of the shipping container. -
Page 13: Appendix A- General Specifications
APPENDICES Appendix A- General Specifications Input 1 x DVI-D Single-Link Resolution 1920 x 1200 @ 60Hz (DVI-D or VGA) Outputs 4 x DVI or VGA (VGA requires a DVI to VGA adapter) Dimensions 17.0in 7.0in 1.75in 43.2cm 17.8cm 4.45cm Weight 2.3 lbs / 1.04 kg Power Adapter Input 90 VAC to 264 VAC / 47 Hz to 63 Hz... -
Page 14: Appendix B- Part Numbers
Appendix B- Part Numbers Part Number Description VWL-S122DV 2 x 2 Video wall CAB-DVIIMMxxx DVI-I male to male cable CAB-DVIDMMxxx DVI-D male to male cable (xxx = length of cable in feet) INSTALLATION and OPERATIONS MANUAL... - Page 16 10707 Stancliff Road Phone: (281) 933-7673 Houston, Texas 77099 WWW.ROSE.COM...
