To keep up to date with information about AIS compliance and

the current status on different regulations surrounding the

fitting of AIS transponders we recommend you visit

www.uais.org/CarriageRequirements.htm

Contents of this Box

Before proceeding with the installation of the SLR-200, please check

the content of the box, which should include:

The SLR-200 AIS receiver with trunnion mounting bracket.

Interface cable for connection to PC

Interface cable for NMEA connection

Power cable (12/ 24 volts)

Installation and quick Reference Guide.

Installing the SLR-200 Receiver

Installing the antenna

The SLR-200 Receiver is not supplied with a VHF antenna as the

type of antenna and cable requirements differ from vessel to vessel.

An antenna can be acquired from a marine electronics outlet.

Hint:

The antenna connector type is BNC, 50 ohms.

Antenna location

Hint:

The AIS VHF antenna should be separated as far as possible from

the voice VHF to avoid unnecessary interference.

Hint:

Best separation is achieved by installing the antennas over each

other or on separate sides of the mast.

Hint:

The VHF antenna should be mounted at least 3 metres away from

and out of the transmitting beam of high-power transmitters or other VHF

antenna installations.

Hint:

Mount the antenna with a relatively clear view of the horizon. Large

obstructions that might shade the antenna should be avoided.

Hint:

The higher the antenna is located, the longer the range.
