- Page 1 T-100-R Operation Guide...
-
Page 2: Table Of Contents
Table of Contents Page 2 Overview Main Thermostat Screen 3 Setting the Heating or Cooling Temperature Setpoint 4 Setting the System Mode: Off, Heat, Cool, Auto 5 Setting the Fan Mode and System Status Indicators 6 Menu Selection Main Menu Items 7 Menu Options 8 User Settings Menu Items 9-10 Away Setpoints, Z-Wave Install &... -
Page 3: Main Thermostat Screen
Operation Guide Page 3 Main Thermostat Screen Room Temperature Setpoints Backlight Display Temperature Setting 4:30 PM Warmer SYS OFF 72 H ECON HOLD 75 C NO MSG Cooler COOL AUTO MENU MODE HOLD Run/Hold Menu Mode Selection Selection Fan Mode Heating/Cooling Selection Mode Selection... -
Page 4: Setting The Heating Or Cooling Temperature Setpoint
Operation Guide Page 4 Setting the Heating or Cooling Temperature Setpoint 4:30 Press a button to Sys Off go to the setpoint change screen HEAT AUTO MENU MODE HOLD Press the up or down arrow buttons to set the desired temperature setpoint Setpoint change screen HEATING SETPOINT Raise Temperature... -
Page 5: Setting The System Mode: Off, Heat, Cool, Auto
Operation Guide Page 5 Setting the System Mode: Off, Heat, Cool, Auto 4:30 PM Sys Off HEAT AUTO MENU MODE HOLD Press Mode button to change system mode System Mode change screen Press the UP or SYSTEM MODE DOWN buttons HEATING COOLING AUTO... -
Page 6: Setting The Fan Mode And System Status Indicators
Operation Guide Page 6 Setting Fan Mode and System Status Indicators 4:30 PM System Sys Off Status Indicators Filter HEAT AUTO MENU MODE HOLD Press the Fan button to change the Fan mode. • AUTO FAN: Fan automatically operated by the HVAC system. -
Page 7: Main Menu Items
Operation Guide Page 7 Menu Selection 4:30 PM Sys Off HEAT AUTO MENU MODE HOLD Press Menu button to go to the main menu screen Menu Selection Use the Energy Usage UP/DOWN Utility Setup Messages Schedules buttons to select Done Select the desired menu item... -
Page 8: Menu Options
Operation Guide Page 8 ...as per that days schedule stored in the thermostat. “Hold” mode stops schedule operation and holds the current setpoints until changed manually or by network commands. The Schedules Screen gives you the option of setting a custom setback schedule or to load one of two preset schedules. -
Page 9: User Settings Menu Items
Operation Guide Page 9 User Settings Menu Items • Set Clock go to the clock setting screen • Filter Service go to the filter timer setup screen • Maint Service go to the maintenance timer setup screen Select Schedule •... - Page 10 Operation Guide Page 10 Screen Timeout Minimized Screen. Set the display timeout time in seconds. Options are 0 or 15 to 120 (default set to 0 seconds). This is the time before the main thermostat screen reverts to the minimized temperature only display screen, after the last button press.
-
Page 11: Away Setpoints, Z-Wave Install & Thermostat Info
Operation Guide Page 11 Away Setpoints Away setpoints are used when the thermostat is set to the setback or away mode. Away Setpoints Use up/down buttons to select Away – Heat Away – Cool setpoint to change Done Press DONE to store Use +/- buttons to increase or the setting and exit back to the decrease the temperature... -
Page 12: Thermostat Operation
Operation Guide Page 12 Thermostat Operation Minimum Run Time (MRT) The thermostat has a Minimum Run Time after the start of any heating or cooling call. This minimum run time assures even heating and cooling cycles. The MRT delay will keep the system on even if reaches setpoint or you change the setpoint to a temperature that would satisfy the call, until the MRT expires. -
Page 13: General Programming Procedure & Setback Mode Operation
Operation Guide Page 13 Z-Wave Installation Z-Wave controllers from various manufacturers may support the Z-Wave Thermostat General V2 Device class used by the Z-WAVE Thermostat. The following procedure will allow the thermostat to be added to a Z-Wave network. General Programming Procedure (for controllers supporting the thermostat device class): 1. -
Page 14: Information To User
Operation Guide Page 14 FCC/IC INFORMATION TO USER This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. - Page 15 www.evolvecontrols.com...
