- Page 1 T-100-R Installation Guide...
-
Page 2: Table Of Contents
Table of Contents Page 2 Overview T-100-R Z-Wave Thermostat 3-4 Installation HVAC System Setup 6 Installer Settings Menu Items 7-9 Installer Settings Summary 10-11 Wiring Standard Gas/Elec HVAC System Wiring 13 Heat Pump HVAC System Wiring 14... - Page 3 Model T-100-R Thermostat Overview This thermostat is compatible with most HVAC systems, including the following: • 24VAC systems (requires both the 24R and 24C [common] wires) • Standard gas/oil/electric heating systems - 1 stage heating and cooling - 2 stage heating and cooling •...
- Page 4 Overview Page 4 Standard HVAC System Wiring Record the old thermostat wire Terminal Marking Meaning Typical Wire Color connections and terminal marking here 24VAC Common Blue 24VAC Return Green W or W1 Heat stage 1 White Y or Y1 Cool stage 1 Yellow Heat stage 2 Orange...
- Page 5 installation...
-
Page 6: Hvac System Setup
Installation Page 6 HVAC System Setup Overview The thermostat requires that you setup the type and configuration of your HVAC system for proper operation. This is done in the Thermostat Info screen Setup button or the Installer Settings screen on the thermostat. The Installer Settings is a hidden screen. -
Page 7: Installer Settings Menu Items
Installation Page 7 Installer Settings Menu Items Display Lock Range: Y or N Default: N Y = Display LOCKED N = Display UNLOCKED Allows you to lock or unlock the thermostat buttons. When the buttons are locked, you can still access the main menu, but you will not be allowed to select any menu options. - Page 8 Installation Page 8 Aux Heat (HP) 2nd Stage Cool Range: Y or N Range: Y or N Default: Y Default: N Enables the Auxiliary Heat operation. Typically the Enables the 2nd Stage Cool operation Aux Heat will be heat-strips in a Heat Pump system Recovery Enable Schedule Enable Range: Y or N...
- Page 9 Installation Page 9 Cooling Delta Stage 1 ON Cooling Delta Stage 1 OFF Range: 1 - 8 degrees Range: 0 - 8 degrees Default: 1 Default: 0 Sets the delta from setpoint that stage 1 cooling Sets the delta from setpoint that stage 1 Cooling starts.
-
Page 10: Installer Settings Summary
Installation Page 10 Restore Defaults Relay Status Range: Yes, No / Default: No Display the status (on/off) of the thermostat output relays Restores all settings to factory defaults. Press Yes to restore defaults. Press No to exit and not restore defaults. Installer Settings Summary Setting Range... - Page 11 Installation Page 11 USER SETTINGS Range Default Filter Service Submenu Service Interval Disabled, 100-4000 hrs Maint Service Submenu Maint Interval Disabled, 100-4000 hrs 3000 Screen Timeout (to minimized screen) 0, 20-120 sec 0 = off , will not timeout F/C Mode F or C Sensor Calibration Submenu Internal -7 to +7...
- Page 12 wiring...
-
Page 13: Standard Gas/Elec Hvac System Wiring
Wiring Page 13 Standard Gas/Electric HVAC System Wiring Thermostat Back Default Setup: Optional 24R Connection for single transformer HVAC Systems • Gas/Elec RC and RH are jumpered together on thermostat board. Cut RC/RH jumper JP1 for separate heating & cooling transformers •... -
Page 14: Heat Pump Hvac System Wiring
Wiring Page 14 Heat Pump HVAC System Wiring Thermostat Back Note! For Heat Pump systems, connect the 24R connection If you get heating when you to either the 24RC or 24RH expected cooling, change the C/O type to the opposite setting. Cooling 24V 24RC 24VAC Com... - Page 15 CORPORATE 16 South Maryland Ave. Port Washington, NY 11050 855.750.9090 info@eguestcontrols.com...
- Page 16 www.evolvecontrols.com...
