Summary of Contents for IDT SM113A
-
Page 3: Table Of Contents
Specifications ...................................16 Declaration of Conformity ...............................17 Default Values ...................................18 Warranty ....................................18 Proof of Purchase..................................19 is a product of WIRELESS MONITORS AUSTRALIA PTY LTD - ACN 098 657 231 Manufactured under license in China... - Page 4 User Manual 2.qxd 8/19/05 11:34 AM Page 4 INTRODUCTION Thank you for selecting the electrisave household electricity monitor. This product was developed to educate people about the need to use energy in a sustainable manner and to not waste our scarce resources. By providing you with instant feedback about the cost of electricity consumption, university research and field trails have shown that it is possible to reduce your electricity cost by up to 25% by careful selection and operation if energy efficient appliances.
- Page 5 User Manual 2.qxd 8/19/05 11:34 AM Page 5 Front Back A. Transmit Signal Light D. Reset Hole B. Check Button Battery Compartment (weather proof) Used to check reception with main unit Requires screwdriver to open C. Phase Connecter Cable Outlets Current Sensor A.
- Page 6 LCD Display Symbols Maximum receiving Information is received from the Transmitter every 6 seconds instead of speed every 1-minute. (Use with MAX set off to save battery life). Alarm limit activated The electricity cost-per-hour peak load limit is activated. The alarm will sound if it is exceeded.
- Page 7 SAFETY AND CARE INSTRUCTIONS WARNING To ensure you use your product correctly and safely, read these warnings and the User Manual before using the product. These warnings provide important safety information and should be observed at all times WARNINGS When fitting sensors if in any doubt always consult a qualified electrician •...
- Page 8 QUICK INSTALL GUIDE Step 1: Remove all items from packaging Main Unit Receiver Remote Transmitter Batteries x 6 User manual & Current Sensor (With Wall Bracket) AA Alkaline Quick Install Guide Step 2: Locate Remote Transmitter and Current Sensor Step 3: Clip Current sensor(s) around the live powercable (not the neutral) which comes out of your meter box WARNING: If in doubt always consult an qualified electrician Step 4:...
- Page 9 HOW THE PRODUCT WORKS Overview This product uses ‘phase’ current transformer sensing technology to detect and monitor a magnetic field around your household electricity power cable. It measures the amps being used and, by reference to the system voltage, calculates the amount of power being used, the cost, and the amount of greenhouse gas emissions.
-
Page 10: Getting Started
GETTING STARTED You will need As you unpack and begin to set up your new electrisave ™ you will need the following equipment: • User manual – for instructions on how to set up and use the product. • A hammer and 2x 2mm head nails – to fix the mounting bracket/unit to the wall. Alternatively you may screw the bracket to the wall or simply place the transmitter carefully inside the meterbox. - Page 11 Mounting the electrisave™ The Main Unit Receiver can either be placed on a flat surface with the back stand pulled out or mounted as shown below: Diagram Instructions 1. Mount by using nails or screws. 2. Hammer in nail or screw halfway. 3.
- Page 12 Plugging the Current Sensor into the Remote Transmitter Once the Current Sensor is attached to the household power line you may plug it into any of the three outlets in the Remote Electricity Monitor by following the steps below: Diagram Instructions 1.
- Page 13 Setting the cost-per-hour currency unit NOTE As the default value is $, the currency unit will need to be changed for a product used in the UK Diagram Instructions 1. Press mode and alarm simultaneously. 2. The currency value blinks. Use the arrow key to change the flashing value (in $, £, or #) 3.
- Page 14 Diagram Instructions 1. When ‘MAX’ icon is displayed, press and hold the arrow key for 2 seconds. 2. The ‘MAX’ icon disappears. Repeat these steps to re-enable “MAX’ receiving speed. NOTE Use the standard 6 second update cycle until you have become familiar with the cost of operating electrical appliances around your home.
- Page 15 Diagram Instructions 1. Press alarm once. 2. Use the arrow key to change a value. 3. Press alarm again and continue until all values are set. Activating the alarm To activate the alarm follow the instructions below: Diagram Instructions 1. On the back of the unit locate the grey alarm on/off button (furthest to the right). 2.
- Page 16 Resetting the Main Unit Receiver and the Remote Transmitter To reset both units to default factory settings follow the instructions below: Diagram Instructions 1. Locate the reset point on the back of the Portable Main Unit. 2. Push a blunt stylus (pen) gently into the reset point. 3.
-
Page 17: Troubleshooting Guide
TROUBLESHOOTING GUIDE This section includes a list of frequently asked questions for problems you may encounter with your electrisave™. If your electrisave™ is not operating as you think it should, check here before arranging for servicing. Problem Symptom Check this Remedy No power or no Power will not turn on or no... -
Page 18: Declaration Of Conformity
CM113A Product Name: electrisave Manufacturer: IDT Technology Limited Address: Block C. 9/F Kaiser Estate, Phase1, 41 Man Yue St, Hung Hom, Kowloon, Hong Kong Is in conformity with R&RTTE Rules This device is intended for use in the UK. This equipment complies with the essential requirements for the Radio... -
Page 19: Default Values
DEFAULT VALUES FUNCTION DEFAULT VALUES CUSTOMISED SETTINGS A C Voltage 240 volt Greenhouse gas emission rate kW Greenhouse gas unit kg/hour Tariff charge (cost per kWh) 12 cents per kWh Currency $ and cent Hi alarm $2.00 / hour, HI on Battery save (receiver) MAX off WARRANTY... -
Page 20: Proof Of Purchase
Return Policy Your electrisave is guaranteed for a period of 12 months from the date of purchase, subject to the conditions listed above. All defective units should be sent to the address shown below using a registered form of post. Repaired and or replacement units will be supplied with 30 days of receipt of the unit(s) from the customer, with the customers being advised of any delay beyond this timeframe To ensure returns for defective unit(s) are processed quickly, customers are required to send with returned unit(s)
