- Page 1 I N S T A L L A T I O N 10-5 Power Supply 10-5 Series Class 2 Power Limited Power Supply c/w Charging Installation and Specifications Manual...
-
Page 2: Installation Instructions
1. Mount the power supply in an accessible location using the mounting keyholes in the back of the box. Note: The RCI 10-5 Power Supply is for use in a controlled environment. Installation must be in accordance with the National and Local Building and Fire Codes. Check with the Authority Having Jurisdiction (AHJ) for details prior to installation. -
Page 3: Specifications
Fig. 2– 10-5 Power Supply Circuit Board Lead acid batteries are typically used for stand by power in security appli- cations, as they float charge well and have no usage memory. When float charged, they typically last 4-5 years. A precision power supply/charger will provide the proper voltage for any given temperature regardless of load. -
Page 4: Troubleshooting Guide
Supervision ► Form “C” AC fail relay output 2A @ 120VAC ► Form “C” battery trouble relay output 2A @ 120VAC ► Internal battery cut-off relay to protect batteries from deep discharge 9.8VDC & 19.6VDC ► Enclosure tamper switch for connection to a UL approved burglary panel when used in UL 603 applications Environmental ►...
