- Page 1 I N S T A L L A T I O N 10-175UL Power Supply ® 10-175UL Access Control Power Supply/Charger Installation and Specifications Manual...
-
Page 2: Specifications
Overview The 10-175UL is a power limited power supply/charger that will convert 115VAC / 60Hz input, into two individually PTC protected 12VDC or 24VDC output, (see specifications). They are intended for use in applications requiring UL Listing for Access Control (UL294) and applications requiring an interface with Fire Alarm Control Panels. - Page 3 Keep power limited wiring separate from non-power limited wiring (115VAC/ 60Hz Input, Battery Wires). Minimum .25” (6.4mm) spacing must be provided. Set the 10-175UL to the desired DC output voltage by setting switch SW1 to the appro- priate position (power supply output specification table).
- Page 4 These input terminals are designed to connect to the normally closed outputs of an access control or fire alarm relay. These terminals control [LOCK+], and [STRIKE+], as well as 10-175UL output relay contacts [N.C., N.O., C] This terminal provides DC output voltage when [TRG1] and [TRG2] are shorted together and are typically used to power Mag Locks.
- Page 5 JUMPER TRG1 TRG2 10-175UL LOCK + STRIKE + COM - AUX + FACP AUX - + BAT -- Stand-by Battery (optional) Constant output (not affected by trigger) Switched DC output (trigger control) 115VAC input Reset AC Power Switch Black Lead...
- Page 6 Enclosure Dimensions 1.50" [38.1mm] 0.88" 4.50" [22.2mm] [114.3mm] 3.38" [85.7mm] 3.38" [85.7mm] 2.25" [57.2mm] 1.25" [31.8mm] 1.50" [38.1mm] FIG 1. Typical mag lock with fire alarm tie- in using aux output installation. 4.50" 4.50" [114.3mm] [114.3mm] 12.00" [304.8mm] 9.88" [250.8mm] 0.88"...
- Page 7 FIG 3. Typical Single Mag lock or door strike installation with fire alarm tie-in using trigger controlled output. FIG 4. Typical dual mag lock installation with fire alarm tie- in using trigger controlled outputs.
-
Page 8: Troubleshooting Guide
Troubleshooting Guide Problem No DC output from terminals. Output voltage is not correct for the con- nected equipment. Trouble output relay is de-energized. (Relay terminals are labeled shown in the Normal, energized, “no trouble” condition. Relays are energized when no trouble is detected. 1-800-265-6630 or 519-621-7651 www.rutherfordcontrols.com ©2007 RUTHERFORD CONTROLS INT’L CORP.
