INTRODUCTION
Energy Sistem® thanks you for buying Xplosionn™ 5500 with SD/MMC slot.
We wish you enjoy using it.
With this Stereo headphone you can listen music from different memory cards
wherever you want. You can take your memory card from your mobile phone
and listen to the music with this powerfull headphones.
We recommend to read this user manual in order to enjoy the product in a safe
way and with the best features.
Page 1 of 18
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ENERGY SISTEM Xplosionn 5500
Summary of Contents for ENERGY SISTEM Xplosionn 5500
- Page 1 INTRODUCTION Energy Sistem® thanks you for buying Xplosionn™ 5500 with SD/MMC slot. We wish you enjoy using it. With this Stereo headphone you can listen music from different memory cards wherever you want. You can take your memory card from your mobile phone and listen to the music with this powerfull headphones.
-
Page 2: Care And Maintenance
- Keep the device clean and without dust with a soft and dry cloth. - Recharge the battery when the low battery icon appears on screen. - Do not disassemble the device. Any repair work must be performed by qualified Energy Sistem Soyntec’s personnel. Page 2 of 18... -
Page 3: Main Features
MAIN FEATURES - Play high quality MP3 from SD/MMC cards. - Rechargeable lithium battery. - Folding headphones. - LCD with tracks information. - Battery loader from USB included. - Frequency response: 15 - 20.000 Hz - Impedance: 32 Ohms - Size: 40 mm diameter - Charging power voltage by USB port: 5 V Page 3 of 18... -
Page 4: Product Content
PRODUCT CONTENT - Energy Sistem® Xplosionn™ 5500 Headphones/MP3 with SD/MMC slot. - Headphones with battery included. - USB cable. - Jack - jack cable. - User's manual. Page 4 of 18... - Page 5 INSERT/EXTRACT THE SD/MMC CARD Insert the card into the left headphone groove (L) as it appear on the picture at next page. When the card is been introduced correctly into the groove it listen “click”. In order to quit the card from the groove press down lightly the card. The card will extract in part for slide up and take out completely.
-
Page 6: General Overview
GENERAL OVERVIEW 1) POWER ON-OFF/PLAY/PAUSE. 2) VOLUME – (V-). 3) VOLUME + (V+). 4) Locking Buttons (HOLD). 5) PREVIOUS. 6) NEXT. 7) MENU. 8) LED charge. 9) In-line Jack. 10) USB input. Page 6 of 18... -
Page 7: Battery Power
BATTERY POWER - Your Xplosionn™ 5500 has an integrated rechargeable Li-Ion battery. It comes recharged from factory, but it is recommended to perform a full recharge before the first usage. - Recharge the battery connecting the headphones to a computer using the included USB 2.0 cable. - Page 8 BATTERY POWER - Charging time is between 3-5 hours, depending if the player is powered off or working and the battery status. To keep the battery in good conditions, we recommend the following: While charging not use the player. Don’t charge more than 8 hours. Recharge the battery when it’s empty at all.
-
Page 9: Switching On/Off
SWITCHING ON / OFF - To power on your Xplosionn™ 5500, press PLAY for 2 seconds. Note: When powering on, the device performs a memory check. The power on time depends on the amount of occupied memory. - Press PLAY for 3 seconds to power off the device. In that moment, the device will save your settings. -
Page 10: Mp3 Music Player
MP3 MUSIC PLAYER - Xplosionn™ 5500 allows you to enjoy MP3 codified music thanks to its high fidelity sound processor. - To enter into the mode for playing MP3 files, press the PLAY button. - To pause the play press the PLAY button briefly, and for increase or decrease de volume press respectively the V+ / V- buttons. - Page 11 MP3 MUSIC PLAYER You can select between different repeat modes selecting one of the following functions: (1) The song plays once. (2) Repeat the song. (3) When get the last song, repeat all from the beginning. (4) Random reproduction. (5) Play ten seconds for each song. NOTE: The reproduction modes appears on the screen as different icons.
- Page 12 MP3 MUSIC PLAYER Access to the Menu option by keep pressing the MENU button for 2 seconds. You can select the different reproducction modes commented in the previous page with the PREVIOUS and NEXT buttons. The reproduction order of the songs depends of the mode selected. The mode by default is the mode (3).
- Page 13 MP3 MUSIC PLAYER You can also configure the equalization mode depending the music style from one off this options: (1) Normal (2) Pop (3) Rock & Roll (4) Classic (5) Jazz For that, keep pressing the MENU button for 2 seconds and you will enter in the reproduction mode.
- Page 14 MP3 MUSIC PLAYER To select one of the different equalization modes press lightly the PREVIOUS and NEXT buttons. With this you will surf on the equalization Menu. When you have selected one of the equalization possibilities, press again the MENU button for exit from the Menu. NOTES: By default the reproduction mode is Normal.
-
Page 15: Troubleshooting
TROUBLESHOOTING 1- Why I cannot play some MP3 files? The MP3 file has to follow some standards like MPEG1/MPEG2/MPEG 2.5 layer 3. Otherwise, the file must be converted using a software application. 2.- My placer don’t recognize my card or the songs don’t listen correctly, Why? Be sure yourself that the function of the cards used is right and it fullfill the SD Card Association rule. - Page 16 SPECIAL GUARANTEE Energy Sistem guarantees that your product does not have any material, design or manufacture defect and provides 36 month guarantee. Guarantee procedure Direct to your vendor and present the purchase invoce or ticket. For more information visit www.energysistem.com.
- Page 17 Address: Pol. Ind. Finestrat C/ Calpe esq. C/ Alicante S/N, 03509 Finestrat Alicante Tel: 902 388 388 Fax: 902 119 034 NIF: A53107488 We declare under our own exclusive responsability the product agreement: Energy Sistem® Headphones/MP3 Xplosionn™ 5500 with SD/MMC slot Manufacturing country: China Page 17 of 18...
- Page 18 which concern this agreement, with the norm(s) or other(s) formative(s) document(s). Certificate CE ATE 20071143, Date 21th May 2007 In accord with the disposition of the Directive 93/68/CEE, from the European Parlament and the Counsel from 22th July 1993, transposed to the spanidh legislation through the Real Decree 1950/1995, from 1th December 1995.
