FW1170 User's Manual
Class A Digital Device (industrial & commercial environment)
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to CE and
FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
M4046-01
FW1170 User's Manual
(Product Guide)
Version 4.12(Rev.E)
September 30, 2011
1
Seyeon Tech Co., Ltd

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FW1170 and is the answer not in the manual?

Questions and answers

Related Manuals for Flexwatch FW1170

Summary of Contents for Flexwatch FW1170

  • Page 1 FW1170 User’s Manual FW1170 User’s Manual (Product Guide) Version 4.12(Rev.E) September 30, 2011 Class A Digital Device (industrial & commercial environment) This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to CE and FCC Rules.
  • Page 2 Revised: September 30, 2011 About This Document This document is prepared for users of FW1170 supplied by Seyeon Tech Co., Ltd. It is assumed that the users are familiar with Microsoft Windows operating systems and Web browsers such as Internet Explorer.

  • Page 3: Table Of Contents

    ACKING HARDWARE DESCRIPTION ........................ 9 2.1..................................9 RONT 2.1. & B ................................ 10 ASE VIEW 2.1.1. CTL Port Description ............................11 FW1170 INSTALLATION AND BASIC SETUP ................. 12 3.1..............................12 EFORE NSTALLATION 3.2............................12 ACTORY EFAULT ETTINGS 3.3.

  • Page 4: Product Overview

    IP(Internet Protocol) network. There is one type of FW1170 model: VO. It can transmit up to 30fps@VGA over the existing network. You can monitor video of FW1170 through web browser(ie. MS Internet Explorer), if FW1170 is connected to network. FW1170 supports video compression both Motion-JPEG and H.264 simultaneously so that user can choose appropriate video...

  • Page 5: Key Features

    FW1170 User’s Manual 1.2. Key Features Standalone device with a built-in web server 10M/100M Auto-Sensing Ethernet Configuring and controlling through Web browser Max 30 fps transmission speed on TCP/IP network Effective Bandwidth & Bit-rate Control (VBR/CBR) by H.264 Supports Dual Streaming in Motion JPEG and H.264...

  • Page 6: Technical Specification

    FW1170 User’s Manual 1.3. Technical Specification FW1170-VO 32bit Embedded CPU NAND Flash 128Mbytes/DDR2: 128Mbytes Hardware Linux version 2.6.xx operating system Battery backed up real-time clock 1/4” optical format CMOS Sensitivity : 1500 mV/lux.sec MAX Active pixel resolution: 652x488 Image sensor...
  • Page 7 Dimensions (HxWxD) and 64(W) x 113(D) x 47(H) (in mm) weight (1lbs = 454g) About 0.160kg without lens and power supply * All specifications are subject to change without prior notice. Table 1 : FW1170 Data Sheet M4046-01 Seyeon Tech Co., Ltd...

  • Page 8: Fw1170 Packing List

    Power Supply Unit (Power Cable & SMPS DC12V 1A Adapter) CD (User’s Manual, installation wizard and etc) Table 2 : FW1170 Packing List Note: Please check all the listed items are included in your package. For any missing items, please contact your local distributor.

  • Page 9: Hardware Description

    RED LED – LAN TX/RX(turned off when transmitting data) LAN(Tx/Rx) LED GREEN LED – LAN LINK(when LAN cables are linked) Lens Lens for board mount Lens Guide Helps to focus easily SPK Jack Audio Input Port (2.6pi) Table 3 : FW1170 Front View M4046-01 Seyeon Tech Co., Ltd...

  • Page 10: Top & Base View

    FW1170 User’s Manual 2.1. Top & Base view Picture 3 : FW1170 Top & Base View Name Description Upper Cap Can be removed for use of PIR Sensor (optional) USB Port for Wireless Connection CTL Conn. CTL Port LAN Connector Power Conn.

  • Page 11: Ctl Port Description

    FW1170 User’s Manual 2.1.1. CTL Port Description It’s RS-232 port for Serial input device, Modem or Console (Hyperterminal.connection). For RS-232 connection, RXD,TXD and GND are used. For connection to PC, RXD and TXD are used. RXD and TXD should be cross to communicate properly...

  • Page 12: Fw1170 Installation And Basic Setup

    Following steps are the physical installation process for FW1170. Fix the FW1170 in place Connect the FW1170 to the Internet cable through the LAN port. Connect the power supply of FW1170. After that, you need to follow the steps below.
