FW1176 User's Manual
Class A Digital Device (industrial & commercial environment)
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to CE and
FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
M4062-00
FW1176 User's Manual
(Product Guide)
Version 4.14(Rev.E)
April 13, 2012
1
Seyeon Tech Co., Ltd

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FW1176 and is the answer not in the manual?

Questions and answers

Related Manuals for Flexwatch FW1176

Summary of Contents for Flexwatch FW1176

  • Page 1 FW1176 User’s Manual FW1176 User’s Manual (Product Guide) Version 4.14(Rev.E) April 13, 2012 Class A Digital Device (industrial & commercial environment) This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to CE and FCC Rules.
  • Page 2 Revised: April 13, 2012 About This Document This document is prepared for users of FW1176 supplied by Seyeon Tech Co., Ltd. It is assumed that the users are familiar with Microsoft Windows operating systems and Web browsers such as Internet Explorer.

  • Page 3: Table Of Contents

    2.1..........................11 IEW UNDER OVER 2.1.1. CTL Port Description ............................12 2.1.2. Speaker V-out Jack Description ........................12 2.1.3. MIC Jack Description ............................12 FW1176 INSTALLATION AND BASIC SETUP ................. 13 3.1..............................13 EFORE NSTALLATION 3.2............................13...

  • Page 4: Product Overview

    FW1176 through web browser(ie. MS Internet Explorer), if FW1176 is connected to network. FW1176 supports video compression both MJPEG and H.264 simultaneously so that user can choose appropriate video compression for the purpose. For both MJPEG and H.264, FW1176 provides 6 levels of video quality. FW1176 also supports both ONVIF and PSIA.

  • Page 5: Key Features

    FW1176 User’s Manual 1.2. Key Features Standalone device with a built-in web server 10M/100M Auto-Sensing Ethernet Configuring and controlling through Web browser Max 30 fps transmission speed on TCP/IP network Effective Bandwidth & Bit-rate Control (VBR/CBR) by H.264 Supports Dual Streaming in MJPEG and H.264...

  • Page 6: Technical Specification

    FW1176 User’s Manual 1.3. Technical Specification FW1176-DS FW1176-MS FW1176-FS 32bit Embedded CPU NAND Flash 128Mbytes/DDR2: 128Mbytes Hardware Linux version 2.6.xx operating system Battery backed up real-time clock 1/2.8” progressive scan 1/3” progressive scan MOS CMOS 1/3” CCD (ICX638,ICX639) Active pixels 1280H x...
  • Page 7 FW1176 User’s Manual Frame rate Up to 30/25 fps @4CIF Up to 30 fps @ 1024p Up to 30 fps @ 1080p (each channel) (Other Stream at QCIF) (Other Stream at QCIF) (Other Stream at QCIF) MJPEG and H.264 Dual Streaming (Simultaneously)
  • Page 8 Windows XP Pro or later Internet Explorer 6.x or later Powerful API for software integration available at http://www.flexwatch.com, including Simple Viewer API, FlexWATCH Control SDK, event trigger data in video stream, System integration support embedded scripting and access to serial port peripherals over HTTP/TCP User can be installed user program daemon for event notification or sending image Embedded operating system: Linux 2.6...

  • Page 9: Fw1176 Packing List

    Power Supply Unit (Power Cable & SMPS DC12V 1.0A Adapter) CD (User’s Manual, IP Installer and etc) Table 2 : FW1176 Packing List Note: Please check all the listed items are included in your package. For any missing items, please contact your local distributor.

  • Page 10: Hardware Description

    Camera module to input Video Bolt for positioning module Move the position of Module right and left (Fix the position when install) (Right and Left) Main Body Mainboard and Camera Module Table 3 : FW1176 Front View M4062-00 Seyeon Tech Co., Ltd...

  • Page 11: Rear View Under Dome Cover

    CTL Conn. CTL Port (RS-485, RS-232, DI, DO) Cable Hole Hole for cable out SPEAKER ,V-OUT Conn. Speaker Port ,Video Output Port MIC Conn. MIC Port Power Conn. Power Connector. Table 4 : FW1176 Rear View M4062-00 Seyeon Tech Co., Ltd...

  • Page 12: Ctl Port Description

    FW1176 User’s Manual 2.1.1. CTL Port Description It’s RS-232 port for Serial input device, Modem or Console (Hyperterminal.connection). For RS-232 connection, RXD,TXD and GND are used. For connection to PC, RXD and TXD are used. RXD and TXD should be cross to communicate properly Picture 4 : CTL Port Description 2.1.2.

  • Page 13: Fw1176 Installation And Basic Setup

    Following steps are the physical installation process for FW1176. Fix the FW1176 in place Connect the FW1176 to the Internet cable through the LAN port. Connect the power supply of FW1176. After that, you need to follow the steps below.
