- Page 1 EN – User Guide...
-
Page 2: Table Of Contents
Contents 1. Important ......................3 2. Introduction ....................4 3. Safety precautions / Important information ..........5 4. Included in your cowCam-box ..............6 5. Explanation of the included products ............7 6. How cowCam works ..................9 7. Before you begin the installation ..............10 8. Setting up the camera in your barn ............10 9. Installing the transmitting A300-antenna ...........11 10. Installing the receiving A300-antenna ............12 11. Setting up the videoLink ................13 12. Permanent attachment and shrink tube heating ........13 13. The different ways to view ................14 14. Troubleshooting ..................15 15. Interference ....................17... -
Page 3: Important
1. Important! Max 2 cameras Number of cameras in package: 1 camera Maximum number of cameras in system: 2 cameras The reason why only 2 cameras can be used in the system is because of possible interference between the channels. A total of 4 channels are available. The cameras use one each and the videoLink uses one to retransmit on. One channel should be left for WLAN (wireless internet or other devices). Cable extension If there are obstacles between the stable and the home, add up to 10 m antenna cable on each side if necessary and place both the antennas on the roofs of the buildings for a free line of sight. Sending side: 25 m included (+ 10 m): 35 m maximum Receiving side: 5 m included (+ 10 m): 15 m maximum Free line of sight... -
Page 4: Introduction
2. Introduction Congratulations to your purchase of cowCam™ from LUDA Elektronik AB. The cowCam™-solution provides safe supervision your cattle and barn. We hope that the cowCam™-solution will satisfy your needs and exceed your expectations. Note that cowCam transmits on an open frequency and that the signal is not encrypted. This means that the signal can be captured by another 2,4GHz device within the camera range. The product is CE-certified meaning that it fulfils all established rules and demands for use within the EU. The CE-certification further implies that the radiation level is below the established radiation levels stated in the R&TTE directive (1999/5/EC). We thank you for purchasing the cowCam™-solution and we hope you’ll easily get trough the installation process. If questions arise during the installation, please read through the different troubleshooting chapters and the FAQ chapter. If further questions arise you are very welcome to contact our friendly customer support. Before you start reading about the installation of your cowCam™-solution we ask you to read through Chapter 3: Safety precautions / Important information. For news on our product range or accessories to your cowCam™-solution, please visit our website: www.cowcam-europe.com LUDA Elektronik AB - 4 -... -
Page 5: Safety Precautions / Important Information
Do not lift the camera or the videoLink with the antennas. If you use several cameras within the same area, place the cameras/antennas in a way allowing the signals to reach the receiver from different angles. Do not use several cameras with the same frequency within the same area since they will interfere with each other. LUDA Elektronik AB resigns all responsibility that might occur from abuse or incorrect use of the products. Always follow the instructions in this User Guide or in the included Quick Install Guide. - 5 -... -
Page 6: Included In Your Cowcam-Box
4. Included in your cowCam box BARN H O M E Your cowCam™-solution includes the following products: 1. 1 wireless video camera. (Art. no 905T) 2. 1 transmitting A300-antenna. (9dBi). (Art. no 307A00) 3. 1 receiving A300-antenna. (9dBi). (Art. no 307A00) 4. 1 videoLink for indoor range extension. (Art. no 870VL) 5. 1 wireless 2,5” LCD-monitor. (Art. no 711LCD) 6. 1 antenna cable (25 m) for mounting between camera and transmitting A300-antenna (Art. no 325K25) 7. 1 antenna cable (5 m) for mounting between videoLink and receiving A300-antenna (Art. no 305K05) Your cowCam™-solution further includes: 1 12V power adaptor for the camera. 1 5V power adaptor for the LCD-monitor. -
Page 7: Explanation Of The Included Products
5. Explanation of the included products To succeed with the installation process, it is important that you get familiar with the included products. Antenna (2dBi) Protective hood Lens Day / Night sensor Channel selector IR-LEDs Microphone Mounting foot Power connection (12V) Wireless video camera. (Art. no 905T) Volume On/Off-button LCD-display Channel selector Video out for TV... - Page 8 Antenna (2dBi) Antenna connection (for A300-antenna 9dBi) Channel indicators Manual channel selectors Dip switches* Power connection (5V) AV-out videoLink for indoor range extension. (Art. no 870VL) * Choosing and switching channels You can set the receiving side to either Manual or Looping mode. (Right dip switch set to either M or L.) In Looping mode the videoLink will automatically switch between the channels (1, 2, 3, 4) set to ON with the dip switches. In Manual mode you can switch between the chosen channels manually by pressing the manual channel selector button on the receiving side. If you only use one camera we recommend that you set the dip switch to the right to M and keep all channels off except for the one your camera is transmitting on. The videoLink will be locked to your camera channel and will not change channels if somebody for example by mistake presses the manual channel selector button on the receiving side. - 8 -...
-
Page 9: How Cowcam Works
6. How cowCam™ works BARN H O M E The camera monitors your cattle, the signal is transmitted through the cable to the A300-antenna outside the barn. The signal is sent from barn to home via the A300-antennas. The videoLink receives the signal through the A300-antenna and retransmits it in your home for better picture quality. -
Page 10: Before You Begin The Installation
7. Before you begin the installation Read the whole user guide before you start installing your cowCam-solution. Begin with charging your LCD-monitor. You will need to use it later on in the installation process. The battery is only partially charged at delivery. The LCD-monitor will only function for a short while if not charged. A fully charged battery will last for approximately 2 hours. 1. Insert one of the included batteries into the LCD-monitor. 2. Connect the power adaptor marked with 5V to the LCD monitor’s power socket (marked with DC 5V IN) and the other end to a wall socket (220V). 3. Make sure that the ring around the button on the LCD- monitor lights up. The light will turn off when the battery is fully charged. noTE! Only use the 5V adapter marked LCD Monitor to power the monitor! Use of any other power source may damage the receiver and is NOT covered by the warranty. 8. Setting up the camera in your barn 1. Connect the small camera antenna to the back of the... -
Page 11: Installing The Transmitting A300-Antenna
9. Installing the transmitting A300-antenna In order to send the picture from the camera wirelessly at the longest possible range, the A300-antennas must be placed on the outer walls of the buildings, pointing directly at each other. 1. Unplug the camera power supply. 2. Remove the small camera antenna. 90˚... -
Page 12: Installing The Receiving A300-Antenna
10. Installing the receiving A300-antenna Place the receiving A300-antenna on an outer wall of your home facing the barn, and point it towards the transmitting A300-antenna. Use the 5m antenna cable to connect the antenna to the videoLink. InfoRmATIon Place the antenna as illustrated above to obtain optimal picture quality. Make sure there are no other objects such as a roof gutter or a pipe close to the antenna, as it may decrease the image quality. -
Page 13: Setting Up The Videolink
11. Setting up the videoLink 1. Connect the 5m antenna cable to the receiving part of the videoLink. 2. Attach the square videoLink antenna to the transmitting part of the videoLink. 3. Connect the videoLink to a power source using the 5V power Channel 1 adaptor. 4. The camera is preset to send on channel 4. Set the videoLink to Channel 4 receive on the same channel as the camera is sending on. 5. We recommend to set the transmitting channel of the videoLink to 1. Choose the same channel on your LCD monitor. InfoRmATIon The videoLink receives the weakened signal and transmits it again with increased strength. This way you will receive a stable and interference free picture inside your home. 12. Permanent attachment and shrink tube heating 1. Check the picture quality in your home using the LCD- monitor. -
Page 14: The Different Ways To View
The standard way to view the picture from your camera is by using the LCD monitor as you have done in the installation, but you can also view in three other ways: Viewing online through cowCam online (mobile phone or computer) cowCam Online is free during the first 30 days, and you... -
Page 15: Troubleshooting
14. Troubleshooting In this Troubleshooting chapter we will presume that you have mounted and installed all parts of your cowCam system. Troubleshooting is also available online at http://ludaelektronik.com/support/en/ Please see chapter 21 for contact information to our support team. We will start troubleshooting using the portable LCD monitor. - Page 16 – If you see a red light the camera is supplied with power, proceed to step 5. – If not please check that the adapter is connected to a working socket, connected to the camera, marked 12V and that the cable isn’t damaged in any way. make sure that the camera is working by screwing the small black antenna back on and holding the LCD monitor nearby. – If you do not receive a picture using the small antenna, contact the support. – If you do receive a picture using the small antenna, please screw the A300 antenna cable back on and check that the antennas are mounted with the “spikes” horisontally, that the cable isn’t damaged and that the cables are connected properly. – If you can’t find any problem with the antennas, go to section 6. 6. Begin with making sure the channel switchers are set correctly. The switch to the right marked with M L sets the videoLink to Automatic Channel Looping (L) or Manual Channel (M).
-
Page 17: Interference
15. Interference Interference caused by WLAn, microwave ovens and wireless telephones. Other wireless equipment around the camera or receiver may cause interference in the picture. WLAN, microwave ovens and wireless telephones may cause horizontal lines across the display and a clicking sound. Microwave ovens only cause interference when in use. This can be resolved by changing the frequency of the WLAN or the camera, as described in the next chapter. Interference caused by one or more units are sending on the same channel Make sure that the cameras are sending on separate channels. Also make sure that the videoLink isn’t sending on a channel that a camera is already sending on, and not receiving on the channel the videoLink is sending on. Very high contrast A picture where the contrast is very high is often caused by metal objects, for example drainpipes, within one meter of the antenna. Move the interfering objects or the antenna. videoLink interference If you are using the videoLink and experiencing interference that goes away when you place your hand on the videoLink or remove the sending antenna, please contact our support for further assistance. -
Page 18: Changing The Frequency Of The Camera
If you believe that interferences in the picture are not a result of unnecessary obstacles between the antennas, we advise you to change the camera frequency. The cowCam camera can be changed to any of the four radio frequencies to avoid possible interferences. -
Page 19: Frequently Asked Questions (Faq)
Is the camera water resistant? The camera in your cowCam™-solution is IP66 classed. This means that the camera is well protected from both dust and humidity. It can be put outside in rain or in damp environments such as barns. Is it possible to add extra cameras to my cowCam™ solution? It is possible to add cameras to your cowCam™-solution. Please contact your retailer or visit http://cowcam-europe.com Can I see my cattle on my TV/computer/mobile phone? Yes! More information is available in Chapter 13: The different ways to view How do I obtain a wider camera viewing angle? The camera covers up to 60-80 m2 depending on placement. Try to move the camera... -
Page 20: Warranty
18. Warranty The warranty is due, if no other terms agreed, 12 months from the date the product is purchased from the authorised LUDA Elektronik AB dealer. During the warranty time LUDA Elektronik AB is obliged to repair, alternately, replace the broken product to a similar product or a product with better functions. When LUDA Elektronik AB replaces the product, the new product will be covered by the original warranty during the remaining warranty time. If your product is replaced, previously used, completely functioning parts might be used. Replaced parts are owned and controlled by LUDA Elektronik AB. The warranty does not cover damage that have arisen due to physical damage, accidents, natural disasters, the usage of incorrect power adaptors or usage of the products in deviant behaviours from what is recommended by LUDA Elektronik AB and in this users guide. The end consumer will be responsible for all shipping costs that occur from transportation to the LUDA Elektronik AB repair shop. The warranty will only be valid if the original receipt, issued by the authorised LUDA dealer, can be presented. The original receipt needs to contain information regarding place of purchase, issue date and product description. LUDA Elektronik AB reserve the right to refuse to perform the warranty service if above mentioned receipt information has been removed, changed or is missing. 19. Information regarding recycling The crossed-out wheeled-bin symbol on your product, battery, literature, or packaging reminds you that all electrical and electronic products, batteries, and accumulators must be taken to separate collection at the end of their working life. This requirement applies in the European Union. Do not dispose of these products as unsorted municipal waste. Always return your used electronic products, batteries, and packaging materials to a dedicated collection point. This way you help prevent uncontrolled waste disposal and promote the recycling of materials. Batteries can contain mercury, lead or cadmium - substances that are harmful to our health and our environment. More detailed information is available from the product retailer, local waste authorities or your national producer responsibility organization. - 20 -... -
Page 21: Technical Specifications
20. Technical specifications Wireless video camera (Art. no 905T) Transmitting frequency ISM 2400~2483 MHz Transmission power < 10mW/CE Channels 2414MHz (CH1); 2432MHz (CH2); 2450MHz (CH3); 2468MHz (CH4) Transmitting antenna 50 ohm SMA Imaging sensor CCD Resolution PAL: 512×582 Horizontal resolution 420TV Lines Angle PAL: 90° Minimum Illumination 0Lux IR night range 10m Power supply DC +12V Power consumption 120mA (IR OFF) & 270mA (IR ON) Operating temperature -20 ~ +50 (Celsius) Size (W×D×H) 50*50*75 mm Weight 200g Wireless 2,5”... -
Page 22: Contact Us, Accessories & Support
21. Contact us, accessories and support LUDA Elektronik, founded in 2003, is a leading distributor of wireless video equipment. We have in-depth expertise of wireless video technology and its usage areas. Thanks to this we can offer our customers the latest products and high quality sales support, service and customer support. Accessories and support Visit www.ludaelektronik.com/support/en/ for support and accessories for your cowCam. Contact: LUDA Elektronik AB, Aschebergsgatan 46, SE41133 Göteborg, Sweden Tel: +46 (0)31 3130290 Fax: +46 (0)31 3130299 E-mail: service@cowcam-europe.com - 22 -... -
Page 23: Declaration Of Conformity
22. Declaration of conformity R&TTE Declaration of Conformity (DoC) R&TTE Declaration of Conformity (DoC) Unique identification of this DoC: 621COW-2010-2-CE Unik identifiering av denna DoC: 621COW-2010-2-CE We, LUDA Elektronik AB, Vi, LUDA Elektronik AB, Aschebergsgatan 46 Aschebergsgatan 46 411 33 Göteborg 411 33 Göteborg... - Page 24 © Copyright LUDA Elektronik AB 2011 This guide is published by LUDA Elektronik AB. All rights reserved. Any rights not expressly granted herein are reserved. - 24 -...
