In the interests of user-safety (Required by safety regulations in some countries) the set should be restored
to its original condition and only parts identical to those specified should be used.
This model is based on the LC-32/37GD4U and is equipped with a redesigned speaker. This Service Manual
covers the modifications alone. For the other points, refer to the LC-32/37GD4U Service Manual.
» LIST OF CHANGED PARTS ...........................................................................................................................2
» IMPORTANT SERVICE SAFETY PRECAUTION ........................................................................................ 4
» SPECIFICATIONS........................................................................................................................................7
» OPERATION MANUAL ................................................................................................................................8
» DIMENSIONS ............................................................................................................................................14
» REMOVING OF MAJOR PARTS ................................................................................................................15
» DESCRIPTION OF SCHEMATIC DIAGRAM .............................................................................................21
» SCHEMATIC DIAGRAM .............................................................................................................................22
» PARTS LIST ...............................................................................................................................................23
» PACKING OF THE SET .............................................................................................................................33

SHARP CORPORATION

SERVICE MANUAL

LCD COLOR TELEVISION
LC-32GD6U
LC-37GD6U
MODELS
OUTLINE
CONTENTS
This document has been published to be used for
after sales service only.
The contents are subject to change without notice.
LC-32GD6U
LC-37GD6U
S84Z2LC37GD6U
Page

Advertisement

Table of Contents
loading

Summary of Contents for Sharp LC-32GD6U

  • Page 1: Table Of Contents

    LC-32GD6U LC-37GD6U SERVICE MANUAL S84Z2LC37GD6U LCD COLOR TELEVISION LC-32GD6U LC-37GD6U MODELS In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its original condition and only parts identical to those specified should be used.
