- Page 1 Wireless Powerlink II Receiver Set Active Installation Guide...
-
Page 2: Table Of Contents
WirelessPowerlink for your Sub-woofer Technical Data General Page 10 Connections Housing © 2011 BOSSCOM DENMARK All names, logos, etc. are registered trademarks of the companies listed in this brochure. The information in this manual is subject to change without notice. All rights Reserved. -
Page 3: Package Contents
General Dear Customer, ® Thank you for choosing this wireless Bang & Olufsen compatible Powerlink radio transmission system. This installation guide will help you to properly integrate the unit into your audio system. With years of expertise, we want to bring the benefits of the latest technology into your living room. -
Page 4: Safety Instructions
General Safety Instructions To ensure best performance, please read these instructions carefully. Keep them in a safe place for future reference. Install the equipment in a well-ventilated, cool, dry, clean environment - away from direct sunlight, heat sources, vibration, dust, moisture and/or cold. Place the unit away from other electrical devices, motors, or transformers to avoid humming sounds. - Page 5 In case of malfunction, carry out the pairing function again (see page 5). Should the malfunction persist, contact your local specialty retailer, or submit an email to support@bosscom.com. Before moving this device, unplug the power cord from the wall outlet.
- Page 6 Installation Pairing Function The receiver must be registered with the transmitter on location. The following steps are necessary for the registration: 1. Both units must be connected to a power source - the yellow Status LED (left hole) lights up and the green LED (middle hole) blinks every second. CAUTION: Receiver Do NOT connect the...
-
Page 7: Installation
Installation Connecting the Devices 4. Connect the transmitter on the PL IN socket to the Powerlink output of your Bang ® & Olufsen device, with the supplied Powerlink cable. Then connect it to the power supply (power cord also included). Transmitter to the Powerlink source... - Page 8 Installation Assembly Instructions / Placement The logo on the side of the receiver and the transmitter should always be visible, to achieve the best possible transmission quality. Also make sure that the devices are not placed in the immediate vicinity of antenna cables - this can cause static noise.
-
Page 9: System Description
System Description ® Compatibility with Bang & Olufsen Devices The WirelessPowelink System is compatible with ALL active Bang & ® ® Olufsen speakers other than BeoLab 5 WirelessPowerlink in the Surround-System Here, the front speakers remain connected to your system via wires. Wherever a wired connection to the rear speakers is not possible or simply too expensive, you can expand your wired stereo system to a full surround system with Wireless Powerlink. - Page 10 System Description WirelessPowerlink in Stereo Mode Wherever a wired connection to the rear speakers is not possible or simply too expensive, you can extend your wired stereo system to a full surround system with WirelessPowerlink. And if you have an outdoor party, you can simply place the speakers on the patio and connect them to an outlet - the music will accompany you outside.
-
Page 11: Technical Data
Technical Data General Transmission Mode: Digital Radio Link Range Approx. 15m within the room / 50m in open field Frequency Change: Automatically on 34 channels Radio Frequency: 2.4 GHz ISM band (transmitting / receiving freq.) Modulation: GFSK Audio Format: 16 bit, 48 KHz Sampling Rate Channel Separation: >... - Page 12 BOSSCOM, Oldenvej 21, 3490 Kvistgård, CVR: 25307755 Support: support@bosscom.com , Salg: sales@bosscom.com www.bosscom.com Tlf. (+45) 70 20 00 45 , Fax (+45) 45 94 06...
