- Page 1 STORAGE WATER HEATER PSG 10N/15N/ 25N MSG 6/10/15 /25 Instruction Manual...
- Page 2 Your INALSA Storage Water Heater has a lot of thoughtful features built in to make your working convenient. Please read these instructions carefully, so that you may get the best out of the power packed features in your INALSA Storage Water Heater.
-
Page 3: Parts Identification
Parts Identification Metal casing Plastic casing Part No. Parts Name Outer casing Inspection cover Water inlet (Blue) Water outlet (Red) Drain pipe Indicator lamps Pressure relief valve (PRV) Technical Specifications* Model No. PSG10N PSG 15N PSG 25N MSG6 MSG10 MSG 15 MSG 25 Capacity (in lt.) Wattage (in kW) Star rating... -
Page 4: Important Instructions
Indicator Red:- Heating Green:- Cut-out Water tank Stainless Steel Heating element - Two U, embedded type, copper sheathed, tubular with mineral filling. (All models except MSG 6). - Single element, embedded type, copper sheathed, tubular with mineral filling ( Model MSG 6). Thermostat Stem-type Pre-set at 60°C Thermal cutout... -
Page 5: How To Install
7. If the main cord of the heater is damaged, authorized service personnel must only replace it. Don'ts 1. Do not switch ON the heater till it is completely filled with water. 2. Do not install a pressure reducer valve at the inlet. 3. - Page 6 Mounting diagram Water supply 1. You can connect the water heater directly to the overhead water supply tank. Do not connect the water heater directly to water lifting pumps. 2. The water should not be too low. The minimum height between the heater and water supply should be at least 2M.
-
Page 7: How To Use
How to Use 1. Do not switch ON the power supply before filling the heater with water. 2. Leave the hot water outlet open and open the inlet valve to allow the heater unit to be filled with water. When the heater is full the water will start flowing out from the outlet. -
Page 8: Cleaning And Maintenance
Non- Return Device There is a siphon hole on the inlet pipe inside the inner tank of water heater. At low pressure, the siphon prevents back flow of the water. It acts as a non-return device upto a certain level of low pressure and prevents vacuum formation that can lead to tank collapse and thus leakage.
