4.2.2 Show Port Configurations (1)
> 1
Port 1: RS232
Port 2: RS232
The command '1' in the Main Menu lists the current configuration of all serial ports in the USB-
COM PRO. This example is for a USB-2COM PRO with both ports in RS232 mode. The list is
followed by the Main Menu again.
4.2.3 Change Port Configuration (2)
> 2
0 - Back
---------------
1 - Port 1
2 - Port 2
---------------
3 - All Ports
>
Command '2' allows to change the configuration of some ports. The ports may be selected individ-
ually, or all at once for common configuration.
0 Selects the Main Menu again.
1 Selects the first serial port.
2 Selects the second serial port.
3 Selects all serial ports at once. This number changes depending on the number of available serial
ports.
For this example port 1 is selected for configuration. To get details about the available modes
please read section 2.2.
June 2009
Figure 20: Show all port configurations
