USER'S MANUAL
ALLINONE DISPLAY INC.
Web site : www.aodlcd.com
Tel :02-3283-7495 / Fax : 02-3283-7498
3F, B-Dong, Micro office B.D 554-2 GaSan-Dong, GumChun-Ku, Seoul , Korea
www.aodlcd.com
All In One
Specifications
Model
Display
Type
Color
Pixel
Screen Size
Resolution (Max)
Contrast Ratio
300:1
Brightness
Video
Frequency
Compatibility
Plug and Play
Compatibility
Power
Operation Environment
Power Consumption
Temperature
Humidity
User's Mode
OSD Key
6.4 inch XGA TFTLCD Monitor
6.4"Color Active Matrix TFT LCD
262,144 Color
0.204 x 0.204 mm
246 (H) x 184.5 (V) mm
640 x 480 at 60 to 75Hz
2
250 cd/m
Horizontal: 56 ~ 75KHz
Vertical: 31.5 ~ 80Hz
VESA DDC 1/2B
VESA / IBM / MAC
VESA Standard, DPMS
Operation Mode: 35 watt max.
Stand-by: 4 watt max.
Operation Mode : 0 ºC ~ 40 ºC
Stand-by: -20 ºC ~ 60 ºC
Operation Mode: 10% ~ 85% R.H.
Stand-by: 90% R.H. Max.
Auto / Menu / Down / Up / Enter / Power
All In One

Advertisement

loading
Need help?

Need help?

Do you have a question about the 64 and is the answer not in the manual?

Questions and answers

Related Manuals for AOD 64

Summary of Contents for AOD 64

  • Page 1 Specifications Model 6.4 inch XGA TFTLCD Monitor Display Type 6.4”Color Active Matrix TFT LCD Color 262,144 Color USER’S MANUAL Pixel 0.204 x 0.204 mm Screen Size 246 (H) x 184.5 (V) mm Resolution (Max) 640 x 480 at 60 to 75Hz Contrast Ratio 300:1 Brightness...
  • Page 2 OSD (On-Screen-Menu) OSD Controls menu select down power BRIGHTNESS : Adjust brightness CONTRAST : Adjust contrast Button Function Status COLOR CONTROL : Adjust color to user,9300K,6500K Adjust RED,GREEN,BLUE when selecting User MISCELLANEOUS - Initialize : Make all setting value as initialization. POWER Power ON or OFF ON/OFF...
  • Page 3 Contents Of the Retail Package Troubleshooting TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER. NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The monitor does not respond after you turn on the system. Make sure that the monitor is turned on. Turn off the power and check the monitor’s power cord, AC adapter, and signal cable for proper connection.
  • Page 4 Drawing (OPTION) Front view Side view Bottom view All In One All In One...
  • Page 5 All In One All In One...
  • Page 6 (OPTION) All In One All In One...
  • Page 7 All In One All In One...
