Summary of Contents for Perfectaire Air Conditioner
-
Page 2: Table Of Contents
7. TROUBLESHOOTING TIPS...............19 ead This Manual Inside you will find many helpful hints on how to use and maintain your air conditioner properly. Just a little preventive care on your part can save you a great deal of time and money over the life of your air conditioner. You'll find many answers to common problems in the chart of troubleshooting tips. -
Page 3: Safety Precautions
It may cause an explosion or fire. shock. Ventilate room before operating air Do not disassemble or modify, or drill holes into the air conditioner. conditioner if there is a gas leakage from another appliance. It may cause explosion, fire and, burns. - Page 4 Do not clean unit when This could injure the pet or Do not use this air conditioner to preserve precision devices, food, power is on as it may cause plant. pets, plants, and art objects.
-
Page 5: Important Safety Instructions
Your air conditioner must be used in a properly grounded wall receptacle. If the wall receptacle you intend to use is not adequately grounded or protected by a time delay fuse or circuit breaker, have a qualified electrician install the proper receptacle. -
Page 6: Normal Sounds
Gurgle/Hiss Gurgling or hissing noise may be heard due to refrigerant passing through evaporator during normal operation. NOTE:This air conditioner is designed to be operated under conditions as follows: Ambient temp.: 64 ~109 18~43 Cooling Operation Operation temp.: 62 ~90 17~32 If the unit operated beyond the conditions specified above, it may cause a failure of the unit. - Page 7 AIR CONDITIONER FEATURES(CONTINUED) NOTE: The following instructions represent the Unit Controls, the same instructions can be used for the Remote Control. TO TURN UNIT ON: Temp Timer Clean Check Filter High DO THIS: Press the On/Off button. On/Off Auto Follow...
- Page 8 DO THIS: To operate on Dry mode: Press the button Temp In this mode, the air conditioner will generally operate in the form of a dehumidifier. Since the Energy Sleep Timer Saver conditioned space is a closed or sealed area, some degree of cooling will continue.
- Page 9 Check Filter at its location. The remote control will send this High signal to the air conditioner every 3 minutes until press the Follow Me button again. If the unit does not receive the Follow Me signal during any 7...
- Page 10 3 seconds. Fresh Air Vent Control(on some models): The Fresh Air Vent allows the air conditioner to: 1. Recirculate inside air - Vent Closed (See Fig.1) 2. Draw fresh air into the room- Vent Open (see Fig.2) 3.
-
Page 11: Installation Instructions
Frame Assembly (Left) 1. Check window opening size-- the mounting parts furnished with this air conditioner are Side Retainer made to install in a wooden sill double-hung window. The standard parts are for window dimensions listed above. Open sash to a mini- Seal-bottom mum of 19 inches(483mm). - Page 12 Tools Required(not included) A large flat blade screwdriver Tape measure Adjustable wrench or pliers Pencil Level Socket wrenches Phillips screwdriver Hardware (Packed with the unit) Washer Head Locking Screw 2ea. For window panels 3 / 4 inch Long 3ea. Hex-head Screw Safety Lock 1ea.
- Page 13 Window Mounting 9. Your unit may come with internal packaging. Remove Chassis This packaging must be removed prior to installing the air conditioner back into the 1. Pull down front panel and remove filter. cabinet.(See Fig.5). (See Fig.1). 2. Lift front upwards and place to one side.
- Page 14 3. Shift cabinet left or right as needed to line up center of cabinet on center line marked on stool. Air Conditioner Plastic Cabinet 4. Fasten cabinet to window stool with 2 screws Frame into holes(You may wish to pre-drill pilot holes).
- Page 15 1 2 Long Screws and Locknuts Install Chassis into Cabinet and Install Front to Unit 1. Lift air conditioner and carefully slide into Extend Window Filler Panels cabinet leaving 6 inches protruding. 2. DO NOT push on controls or finned coils.
- Page 16 Select Wall Location WIDTH X = inside model width plus twice the thickness of framing material used. The air conditioner has a slide-out chassis, so HEIGHT Y =inside model height plus twice the that it can be installed through an outside wall thickness of framing material used.
- Page 17 NOTE: If wall thickness is 8-1/2 or more, add aluminum flashing over bottom of frame opening to assure no water can enter area between inner 1 Long Wood and outer wall. Screw Fig.2 Caulkas Required Refer to Step 4 of Window Mounting for assembly of support brackets.
- Page 18 OPTIONAL: Caulking and installation of trim on interior wall may be done. You can buy wood from your local lumber or hardware supply. On the outside, caulk openings around top and sides of cabinet, and all sides of wood sleeve to the opening. NOTE: See Step 7, Item 3 of Window Mounting Instructions for bottom rail seal location.
-
Page 19: Care And Cleaning
CARE AND CLEANING CAUTION Clean your air conditioner occasionally to keep it looking new. Be sure to unplug the unit before cleaning to prevent shock or fire hazards. Air Filter Cleaning The air filter should be cleaned every two weeks or as necessary. -
Page 20: Troubleshooting Tips
Noise when unit is cooling Window vibration - poor installation. Refer to installation instructions or check with installer. Improper installation. Tilt air conditioner slightly to the outside to allow water drainage. Water dripping Refer to installation instructions - check with installer. - Page 21 Problem Solution Unit removing large quantity of moisture from humid room. This is normal during Water dripping excessively humid days. OUTSIDE when unit is cooling. Remote control not located within range. Place remote control within 20 feet & 180 Remote Sensing radius of the front of the unit.
