11.0 - Wired Communication via USB Downloader Mode

1

12.0 - Reader Feedback

Scenario
Successfully Powers Up
Successfully Connects with Host
Unsuccessfully Connects with Host
Successful Decode and Data Transfer
Unsuccessful Decode and Data Transfer
Configuration Code Successfully
Decoded and Processed
Configuration Code Unsuccessfully
Decoded and Processed
Batch Mode Enabled and No Data is Stored
Batch Mode Enabled and Data Stored
Memory Space for Batching is Full
Batch Mode Enabled, Data Stored, and Reader is
in Sleep Mode
C007964_05_CR2600_User_Manual
Open
CortexTools™
2
Scan USB Downloader (HID) Mode
configuration barcode:
3
LEDs on Reader
All LEDs Flash
Wireless Icon Flashes
-
Good Read Indicator will
Flash
-
Good Read Indicator will
Flash
-
Batch Icon Off
Batch Icon Remains Solid
Batch Icon Flashes 5
Times a Second
Batch Icon Flashes Once
Every 10 Seconds
4
Sound Vibrate
1X
1X
-
3X
1X
-
3X
2X
-
4X
- -
- -
- -
- -
