- Page 1 I.D. AL - MultiPlayer - Audio and Vidéo player - Manual MultiPlayer Audio vidéo player MANUAL ® Waves System V 1.0 - 2008...
-
Page 2: Table Of Contents
Information in this manual is subject to change without notice and do not represent any commitment from Waves System. The equipment described in this manual is supplied under condition of the terms of license specifying the legal use conditions. This manual can’t be reproduced or used, in whole or in part, in any form and by any mean, for other use than private, without the written permission from Waves System. -
Page 3: A - Safety Instructions
• The MultiPlayer complies with the applicable technical safety standards at the date of print. All rights reserved for electrical diagrams, procedures, mentioned names and equipments. • No reproduction, in whole or in part, without the written permission from Waves System. A.4 General safety instructions This equipment left our facilities in perfect conditions of operation. - Page 4 Only the original packing guarantees optimal safety of the appliance during transport. Should it be necessary to ship the product during the guarantee period, Waves System will not accept claims for damage arising during the transport from using incorrect packing material! •...
- Page 5 Do not install the player too close to a wall. To avoid overheating, the ventilation holes must be kept clear and an air circulation gap must be left above the unit. B.6 ELECTRICAL CONNECTION Before use, compare mains voltage with that specified on model plate. ® Waves System V 1.0 - 2008 - 3 -...
-
Page 6: Product Presentation
Yellow Video in Memory storage: USB stick or external HDD... maximum capacity 32Go Note: there is no power switch on the MultiPlayer. The player is powered as soon as connected. ® Waves System V 1.0 - 2008 - 4 -... -
Page 7: Operation Mode And Naming Of Files
Photo + music: to display slide shows and listen to music at the same time (under development) Movie: to watch video files Select the type of file to be broadcast using the arrow keys on the remote control and confirm the choice with the «play» key. ® Waves System V 1.0 - 2008 - 7 -... - Page 8 I.D. AL - MultiPlayer - Audio and Vidéo player - Manual Example: When «Music» is selected, the list of audio files is displayed. ® Waves System V 1.0 - 2008...
- Page 9 A setting menu of 5 icons is displayed on the left side of the screen ; each icon opens up a list of options . To move inside menus, use the «Arrow» keys on the remote control. To confirm a choice, press the «Play» key. ® Waves System V 1.0 - 2008...
- Page 10 The first setting concerns the display parameters of still images/photos. Interval time: defines the display time of each photo. Just select the number of seconds. Transition effect : defines the way photos follow up from each other. ® Waves System V 1.0 - 2008...
- Page 11 This menu defines which type of file will be played automatically on powering on the player. Select Photo, Music or Movie, only one option must be «ON». The 2 other modes must be «OFF». ® Waves System V 1.0 - 2008...
- Page 12 This menu presents options to set the TV norm output, brightness and contrast. Select the parameter to be adjusted and set the desired value. Custom configuration menu: Set the paramaters for user interface language, encoding mode, interface style, repeat mode and default settings selection. ® Waves System V 1.0 - 2008...
- Page 13 - Depending on the type of file, zoom, rotation of still images, fast forward and reverse... - Setting of parameters If the pressed key is not operational, a «hand» symbol is displayed on the screen. ® Waves System V 1.0 - 2008 - 8 -...
- Page 14 • Infrared sensor -Play, Stop, Next, Previous, Zoom, Rotate, Forward, Reverse ... • External power supply connector DC 2.1/5.5 • Output Video/Stereo on mini-jack 3.5 - 4 points • USB 2.0 High speed - Host connector ® Waves System V 1.0 - 2008 - 19 -...
- Page 15 I.D. AL - MultiPlayer - Audio and Vidéo player - Manual Note : ® Waves System V 1.0 - 2008...
- Page 16 I.D. AL - MultiPlayer - Audio and Vidéo player - Manual http://www.id-al.com http://www.wsystem.com ® Waves System V 1.0 - 2008...
