Read this manual carefully before operating this vehicle.
OWNER'S MANUAL
XV17ASA(C)
XV17ATSA(C)
LIT-11626-24-27
1BH-28199-11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XV17ASA and is the answer not in the manual?

Questions and answers

Summary of Contents for Yamaha XV17ASA

  • Page 1 Read this manual carefully before operating this vehicle. OWNER’S MANUAL XV17ASA(C) XV17ATSA(C) LIT-11626-24-27 1BH-28199-11...
  • Page 2 EAU10042 Read this manual carefully before operating this vehicle. This manual should stay with this vehicle if it is sold.
  • Page 3 INTRODUCTION EAU10083 Congratulations on your purchase of the Yamaha Road Star™. This model is the result of Yamaha’s vast experience in the production of fine sporting, touring, and pacesetting racing machines. It represents the high degree of craftsmanship and reliability that have made Yamaha a leader in these fields.
  • Page 4: Important Manual Information

    IMPORTANT MANUAL INFORMATION EAU10132 Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.
  • Page 5 IMPORTANT MANUAL INFORMATION EAU10193 XV17ASA(C)/XV17ATSA(C) OWNER’S MANUAL ©2010 by Yamaha Motor Corporation, U.S.A. 1st edition, May 2010 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Corporation, U.S.A. is expressly prohibited. Printed in Japan.
  • Page 6: Table Of Contents

    TABLE OF CONTENTS LOCATION OF IMPORTANT Sidecases [XV17ATSA(C)] ... 4-15 Checking the throttle grip free LABELS ..........1-1 Adjusting the shock absorber play ........... 7-18 assembly ........4-16 Valve clearance ......7-18 SAFETY INFORMATION ....2-1 Sidestand ........4-17 Tires ..........7-19 Ignition circuit cut-off system ..
  • Page 7 TABLE OF CONTENTS Battery ..........7-30 YAMAHA EXTENDED SERVICE Replacing the fuses ......7-31 (Y.E.S.) ........10-9 Replacing the headlight bulb ..7-32 Tail/brake light ......7-34 Replacing a turn signal light bulb ...........7-34 Replacing a license plate light bulb ...........7-34 Supporting the motorcycle ....7-35 Troubleshooting ......7-36...
  • Page 8: Location Of Important Labels

    Read and understand all of the labels on your vehicle. They contain important information for safe and proper operation of your vehicle. Never remove any labels from your vehicle. If a label becomes difficult to read or comes off, a replacement label is available from your Yamaha dealer.
  • Page 9 LOCATION OF IMPORTANT LABELS 5 XV17ATSA(C) 2 California only NOTICE • • 2C5-F815K-00 3 California only 7 XV17ATSA(C)
  • Page 10: Safety Information

    SAFETY INFORMATION EAU10287 Safe Riding • Ride where other motorists can Perform the pre-operation checks each see you. Avoid riding in another time you use the vehicle to make sure it motorist’s blind spot. Be a Responsible Owner is in safe operating condition. Failure to Many accidents involve inexperi- As the vehicle’s owner, you are respon- inspect or maintain the vehicle properly...
  • Page 11 SAFETY INFORMATION due to excessive speed or under- This motorcycle is designed for on- A passenger should also observe cornering (insufficient lean angle road use only. It is not suitable for the above precautions. for the speed). off-road use. • Always obey the speed limit and Avoid Carbon Monoxide Poisoning never travel faster than warrant- Protective Apparel...
  • Page 12 Yamaha accessories, which are avail- to minimize imbalance or instabili- accessories to your motorcycle. Use able only from a Yamaha dealer, have extra care when riding a motorcycle been designed, tested, and approved Shifting weights can create a sud- that has added cargo or accessories.
  • Page 13 SAFETY INFORMATION modifications not specifically recom- clearance or cornering clearance, tor and may limit control ability, mended by Yamaha, even if sold and limit suspension travel, steering therefore, such accessories are installed by a Yamaha dealer. travel or control operation, or ob- not recommended.
  • Page 14 SAFETY INFORMATION Check that the fuel cock (if equipped) is in the “OFF” position and that there are no fuel leaks. Point the front wheel straight ahead on the trailer or in the truck bed, and choke it in a rail to pre- vent movement.
  • Page 15: Description

    DESCRIPTION EAU32220 Left view XV17ASA(C) 1. Engine oil filler cap (page 7-12) 2. Battery (page 7-30) 3. Owner’s tool kit (page 7-2) 4. Fuse box (page 7-31) 5. Shift pedal (page 4-8)
  • Page 16 DESCRIPTION XV17ATSA(C) 1 2 3 1. Engine oil filler cap (page 7-12) 2. Battery (page 7-30) 3. Owner’s tool kit (page 7-2) 4. Fuse box (page 7-31) 5. Shift pedal (page 4-8)
  • Page 17: Right View

    DESCRIPTION EAU32230 Right view XV17ASA(C) 1. Main fuse and fuel injection system fuse (page 7-31) 8. Transfer case oil level check bolt (page 7-15) 2. Fuel tank (page 4-9) 9. Shock absorber assembly spring preload adjusting nut (page 4-16) 3. Fuel tank cap (page 4-9) 4.
  • Page 18 DESCRIPTION XV17ATSA(C) 1. Main fuse and fuel injection system fuse (page 7-31) 10.Shock absorber assembly spring preload adjusting nut (page 4-16) 2. Fuel tank (page 4-9) 3. Fuel tank cap (page 4-9) 4. Windshield (page 4-14) 5. Brake pedal (page 4-9) 6.
  • Page 19: Controls And Instruments

    DESCRIPTION EAU32240 Controls and instruments XV17ASA(C) 1. Clutch lever (page 4-8) 2. Left handlebar switches (page 4-6) 3. Multi-function meter unit (page 4-3) 4. Main switch/steering lock (page 4-1) 5. Right handlebar switches (page 4-6) 6. Throttle grip (page 7-18)
  • Page 20 DESCRIPTION XV17ATSA(C) 1. Clutch lever (page 4-8) 2. Left handlebar switches (page 4-6) 3. Multi-function meter unit (page 4-3) 4. Main switch/steering lock (page 4-1) 5. Right handlebar switches (page 4-6) 6. Throttle grip (page 7-18) 7. Brake lever (page 4-8)
  • Page 21: Instrument And Control Functions

    INSTRUMENT AND CONTROL FUNCTIONS EAU10460 EAU10661 To lock the steering Main switch/steering lock All electrical systems are off. The key can be removed. EWA10061 WARNING Never turn the key to “OFF” or “LOCK” while the vehicle is moving. Otherwise the electrical systems will be switched off, which may result in loss of control or an accident.
  • Page 22: Indicator Lights And Warning Lights

    ” initially when the key is turned to “ON”, 6. Fuel level warning light “ ” or if the warning light remains on, have a Yamaha dealer check the electrical EAU11030 circuit. Turn signal indicator lights “ ” and “...
  • Page 23: Multi-Function Meter Unit

    3.0 seconds. If this oc- EAU45683 two tripmeters (which show the Multi-function meter unit curs, have a Yamaha dealer check the distance traveled since they were vehicle. last set to zero) a fuel reserve tripmeter (which...
  • Page 24 INSTRUMENT AND CONTROL FUNCTIONS Speedometer Fuel gauge Odometer, tripmeters and fuel re- serve tripmeter 1. Speedometer 1. Fuel gauge 1. Odometer/tripmeter/fuel reserve tripmeter When the key is turned to “ON”, the The fuel gauge indicates the amount of speedometer needle will sweep once fuel in the fuel tank.
  • Page 25 If the display indicates any error codes, 4. Push the “RESET” switch, and the note the code number, and then have a minute digits will start flashing. Yamaha dealer check the vehicle. 5. Push the “ ” or “ ” side of the “SELECT”...
  • Page 26: Handlebar Switches

    INSTRUMENT AND CONTROL FUNCTIONS ECA11590 3. Turn the key to “ON”, and then re- EAU12348 Handlebar switches NOTICE lease the “SELECT” switch after five seconds or more. If the display indicates an error Left code, the vehicle should be checked 4.
  • Page 27 INSTRUMENT AND CONTROL FUNCTIONS Right has traveled both about 150 m (490 ft) EAU12711 Start switch “ ” and for approximately 15 seconds. Push this switch to crank the engine However, the turn signal lights can also with the starter. See page 6-1 for start- be canceled manually by pushing the ing instructions prior to starting the en- switch in after it has returned to the cen-...
  • Page 28: Clutch Lever

    INSTRUMENT AND CONTROL FUNCTIONS EAU12820 EAU12881 EAU12890 Clutch lever Shift pedal Brake lever 1. Clutch lever 1. Shift pedal 1. Brake lever 2. Neutral position The clutch lever is located at the left The brake lever is located at the right The shift pedal is located on the left handlebar grip.
  • Page 29: Brake Pedal

    INSTRUMENT AND CONTROL FUNCTIONS EAU12941 EAU13121 2. Turn the key counterclockwise to Brake pedal Fuel tank cap the original position, remove it, and then close the lock cover. The fuel tank cap cannot be installed unless the key is in the lock. In addition, the key cannot be removed if the cap is not properly installed and locked.
  • Page 30: Fuel

    WARNING bottom of the filler tube. Because Gasoline is poisonous and can Your Yamaha engine has been de- fuel expands when it heats up, cause injury or death. Handle gaso- signed to use regular unleaded gaso- heat from the engine or the sun line with care.
  • Page 31: Fuel Tank Breather/Overflow Hose

    Do not park the vehicle near ohol containing methanol possible fire hazards such as recommended by Yamaha because it grass or other materials that can cause damage to the fuel system easily burn. or vehicle performance problems. 1. Fuel tank breather/overflow hose...
  • Page 32: Locking The Steering With A Padlock

    INSTRUMENT AND CONTROL FUNCTIONS ECA10701 EAU13780 EAU14152 Locking the steering with a Rider seat NOTICE padlock Use only unleaded gasoline. The use To remove the rider seat of leaded gasoline will cause unre- 1. Turn the key to “OFF”, and then pairable damage to the catalytic turn it to “OPEN”.
  • Page 33: Helmet Holder

    INSTRUMENT AND CONTROL FUNCTIONS EAU14322 To release the helmet from the hel- Helmet holder met holder Remove the rider seat, remove the hel- met from the helmet holder, and then install the seat. 1. Projection 2. Seat holder 1. Helmet holder 2.
  • Page 34: Windshield [Xv17Atsa(C)]

    INSTRUMENT AND CONTROL FUNCTIONS EAU14583 4. Loosen the screws holding the Tightening torque: Windshield [XV17ATSA(C)] windshield cover located above Windshield bolt: To suit the rider’s preference, the wind- the headlight, position the cover 16 Nm (1.6 m·kgf, 12 ft·lbf) shield angle can be adjusted and the close to the headlight without height can be changed to one of two touching it, and then tighten the...
  • Page 35: Sidecases [Xv17Atsa(C)]

    INSTRUMENT AND CONTROL FUNCTIONS Open the throttle and make sure EAU35890 To open a sidecase Sidecases [XV17ATSA(C)] that the throttle grip returns 1. Insert the key into the lock, turn it EWA12520 properly when released, other- counterclockwise, and then push it WARNING wise an accident or injury could Improper loading or overloading can...
  • Page 36: Adjusting The Shock Absorber Assembly

    INSTRUMENT AND CONTROL FUNCTIONS To close a sidecase EAU14816 load and thereby soften the sus- Adjusting the shock absorber 1. Fold the sidecase lid down. pension, turn the adjusting nut in assembly 2. Turn the key clockwise, and then direction (b). This shock absorber assembly is remove it.
  • Page 37: Sidestand

    Take the shock fore starting off. Therefore, check [ECA10121] absorber assembly to a Yamaha dealer for any service. 4-17...
  • Page 38: Ignition Circuit Cut-Off System

    INSTRUMENT AND CONTROL FUNCTIONS this system regularly and have a EAU44892 Ignition circuit cut-off system Yamaha dealer repair it if it does not The ignition circuit cut-off system (com- function properly. prising the sidestand switch, clutch switch and neutral switch) has the fol- lowing functions.
  • Page 39 INSTRUMENT AND CONTROL FUNCTIONS WARNING With the engine turned off: 1. Move the sidestand down. If a malfunction is noted, have a Yamaha 2. Make sure that the engine stop switch is set to “ ”. dealer check the system before riding.
  • Page 40: Auxiliary Dc Connector

    INSTRUMENT AND CONTROL FUNCTIONS EAU45693 A 12-V accessory connected to the Auxiliary DC connector auxiliary DC connector behind panel A ECA15311 (see page 7-9) can be used when the NOTICE key is in the “ON” position. The accessory connected to the auxiliary DC connector should not be used with the engine turned off, and the load must never exceed 36...
  • Page 41: For Your Safety - Pre-Operation Checks

    Transfer case oil • Check vehicle for oil leakage. 7-15 • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check lever free play. • Adjust if necessary. Front brake • Check brake pads for wear.
  • Page 42 • Make sure that operation is smooth. • Check throttle grip free play. Throttle grip 7-18, 7-26 • If necessary, have Yamaha dealer adjust throttle grip free play and lubricate cable and grip housing. • Make sure that operation is smooth. Control cables 7-25 •...
  • Page 43 FOR YOUR SAFETY – PRE-OPERATION CHECKS ITEM CHECKS PAGE • Check operation of ignition circuit cut-off system. Sidestand switch 4-17 • If system is not working correctly, have Yamaha dealer check vehicle.
  • Page 44: Operation And Important Riding Points

    Yamaha dealer. The transmission is in the neutral gine in case of a turnover. In this position.
  • Page 45: Shifting

    NOTICE tral position. The neutral indicator light should come on. If not, ask a Even with the transmission in Yamaha dealer to check the elec- the neutral position, do not trical circuit. coast for long periods of time 3. Start the engine by pushing the with the engine off, and do not start switch.
  • Page 46: Engine Break-In

    OPERATION AND IMPORTANT RIDING POINTS 4. At the recommended shift points 3. Shift the transmission into the neu- EAU16841 Engine break-in shown in the following table, close tral position when the motorcycle There is never a more important period the throttle, and at the same time, is almost completely stopped.
  • Page 47: Parking

    If any engine trouble should occur ans or children are not likely to during the engine break-in period, touch them and be burned. immediately have a Yamaha dealer Do not park on a slope or on soft check the vehicle. ground, otherwise the vehicle may overturn, increasing the risk of a fuel leak and fire.
  • Page 48: Periodic Maintenance And Adjustment

    – possibly leading to pending on the weather, terrain, geo- that is certified (if applicable). Yamaha death. See page 2-1 for more in- graphical location, and individual use, dealers are trained and equipped to...
  • Page 49: Owner's Tool Kit

    If you do not have the tools or experi- ence required for a particular job, have a Yamaha dealer perform it for you.
  • Page 50: Periodic Maintenance Chart For The Emission Control System

    From 24000 mi (37000 km) or 36 months, repeat the maintenance intervals starting from 8000 mi (13000 km) or 12 months. Items marked with an asterisk require special tools, data and technical skills, have a Yamaha dealer perform the service. EAU17601...
  • Page 51 PERIODIC MAINTENANCE AND ADJUSTMENT INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months 24 months 30 months Evaporative emis-...
  • Page 52: General Maintenance And Lubrication Chart

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU32186 General maintenance and lubrication chart INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months...
  • Page 53 PERIODIC MAINTENANCE AND ADJUSTMENT INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months 24 months 30 months •...
  • Page 54 16000 mi (25000 km) or 24 months. Front and rear brake √ √ √ √ √ √ 25 * • Check operation. switches • Apply Yamaha chain and cable √ √ √ √ √ √ 26 * Control cables lube or engine oil thoroughly.
  • Page 55 PERIODIC MAINTENANCE AND ADJUSTMENT INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months 24 months 30 months •...
  • Page 56: Removing And Installing Panels

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU18771 2. Remove the bolts, and then take Removing and installing pan- the panel off as shown. The panels shown need to be removed to perform some of the maintenance jobs described in this chapter. Refer to this section each time a panel needs to be removed and installed.
  • Page 57: Checking The Spark Plugs

    Do not attempt to 1. Spark plug cap diagnose such problems yourself. In- 2. Remove the spark plug as shown, stead, have a Yamaha dealer check with the spark plug wrench includ- the vehicle. ed in the owner’s tool kit.
  • Page 58: Canister (For California Only)

    PERIODIC MAINTENANCE AND ADJUSTMENT 3. Check each spark plug for elec- To install a spark plug EAU19672 Canister (for California only) trode erosion and excessive car- 1. Clean the surface of the spark plug bon or other deposits, and replace gasket and its mating surface, and it if necessary.
  • Page 59: Engine Oil And Oil Filter Cartridge

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU34089 ing light will come on, but this is not Engine oil and oil filter car- a malfunction. Simply turn the tridge main switch to “OFF”, and then The engine oil level should be checked back to “ON” to restart the engine before each ride.
  • Page 60 An oil filter wrench is available at a Yamaha dealer. 8. Apply a thin coat of clean engine oil to the O-ring of the new oil filter cartridge.
  • Page 61 PERIODIC MAINTENANCE AND ADJUSTMENT through the filler hole, insert the dipstick, and then tighten the oil fill- er cap. 12. Start the engine, rev it several times, and then turn it off. 13. Remove the engine oil filler cap, and then gradually fill the oil tank with the remaining oil quantity while regularly checking the oil lev- el on the dipstick.
  • Page 62: Transfer Case Oil

    If any er quality than specified. In mended type to raise it to the cor- leakage is found, have a Yamaha deal- addition, do not use oils labeled rect level, and then install the oil er check and repair the vehicle.
  • Page 63: Cleaning The Air Filter Element

    PERIODIC MAINTENANCE AND ADJUSTMENT 4. Check the oil check bolt gasket for EAU45701 Tightening torque: Cleaning the air filter element damage, and replace it if neces- Transfer case oil check bolt: The air filter element should be cleaned sary. 8 Nm (0.8 m·kgf, 5.8 ft·lbf) or replaced at the intervals specified in 5.
  • Page 64 PERIODIC MAINTENANCE AND ADJUSTMENT 5. Remove the air filter element by removing the screws, and then dis- connect the hose shown. 1. Bolt 7. Install the air filter element by in- 2. Air filter case serting it into the air filter case, 3.
  • Page 65: Checking The Throttle Grip Free Play

    The valve clearance changes with use, resulting in improper air-fuel mixture and/or engine noise. To prevent this from occurring, the valve clearance must be adjusted by a Yamaha dealer at the intervals specified in the periodic maintenance and lubrication chart. 1. Hose 10.
  • Page 66: Tires

    250 kPa (2.50 kgf/cm², 36 psi) Rear: 250 kPa (2.50 kgf/cm², 36 psi) Tire air pressure XV17ASA 90–191 kg (198–421 lb) Always check and adjust the tire pres- XV17ASAC 90–191 kg (198–421 sure before operating the motorcycle. EWA14651 XV17ATSA 90–177 kg (198–390 lb)
  • Page 67: Cast Wheels

    If any damage is and brake-related parts, includ- ed below have been approved for this found, have a Yamaha dealer re- ing the tires, should be left to a model by Yamaha Motor Co., Ltd. place the wheel. Do not attempt...
  • Page 68: Adjusting The Clutch Lever Free Play

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU22034 decrease the clutch lever free play, decrease the clutch lever free play, Adjusting the clutch lever free turn the adjusting bolt in direction turn the adjusting nut in direction play (b). (b). 7. Tighten the locknut at the clutch cable.
  • Page 69: Adjusting The Brake Lever Free Play

    If there is air in the hy- draulic system, have a Yamaha 1. Rear brake light switch dealer bleed the system before 2. Rear brake light switch adjusting nut 1.
  • Page 70: Checking The Front And Rear Brake Pads

    EAU22580 Checking the front and rear Checking the brake fluid level touches the brake disc, have a Yamaha brake pads dealer replace the brake pads as a set. Front brake The front and rear brake pads must be...
  • Page 71: Changing The Brake Fluid

    Changing the brake fluid is above the minimum level mark and ter the brake fluid reservoir when Have a Yamaha dealer change the replenish if necessary. A low brake fluid refilling. Water will significantly brake fluid at the intervals specified in...
  • Page 72: Drive Belt Slack

    To check the drive belt slack or does not move smoothly, have a 1. Place the vehicle on the sidestand. Yamaha dealer check or replace it. 2. Note the current position of the WARNING! Damage to the outer drive belt using the marks near the housing of cables may result in in- drive belt check hole.
  • Page 73: Checking And Lubricating The Throttle Grip And Cable

    The operation of the throttle grip should Brake pedal be checked before each ride. In addi- tion, the cable should be lubricated by a Yamaha dealer at the intervals speci- fied in the periodic maintenance chart. Shift pedal The operation of the brake and shift...
  • Page 74: Checking And Lubricating The Brake And Clutch Levers

    EWA10731 WARNING If the sidestand does not move up and down smoothly, have a Yamaha dealer check or repair it. Otherwise, the sidestand could contact the ground and distract the operator, re- The operation of the brake and clutch sulting in a possible loss of control.
  • Page 75: Lubricating The Swingarm Pivots

    The swingarm pivots must be lubricat- intervals specified in the periodic main- ed by a Yamaha dealer at the intervals tenance and lubrication chart. specified in the periodic maintenance and lubrication chart.
  • Page 76: Checking The Steering

    Yamaha dealer check or re- [EWA10751] tion chart. If there is play in the wheel 2. Hold the lower ends of the front pair it.
  • Page 77: Battery

    To charge the battery once a month and fully charge it if Electrolyte is poisonous and Have a Yamaha dealer charge the bat- necessary. dangerous since it contains sul- tery as soon as possible if it seems to 3.
  • Page 78: Replacing The Fuses

    PERIODIC MAINTENANCE AND ADJUSTMENT is turned to “OFF”, then con- EAU45661 Replacing the fuses nect the positive lead before The main fuse and fuel injection system connecting the negative lead. fuse are located in the starter relay [ECA16840] case behind panel B. (See page 7-9.) 4.
  • Page 79: Replacing The Headlight Bulb

    4. If a fuse immediately blows again, cohol or thinner. 2. Remove the blown fuse, and then have a Yamaha dealer check the Headlight lens install a new fuse of the specified electrical system. Do not affix any type of tinted amperage.
  • Page 80 5. Install the headlight bulb cover, and then connect the coupler. 6. Install the headlight unit by install- ing the screws. 7. Have a Yamaha dealer adjust the headlight beam if necessary. 1. Do not touch the glass part of the bulb. 1. Headlight coupler 2.
  • Page 81: Tail/Brake Light

    1. Remove the license plate light unit If the tail/brake light does not come on, moving the screws. by removing the bolts. have a Yamaha dealer check it. 1. Screw 1. Bolt 2. Remove the burnt-out bulb by 2. Remove the license plate light...
  • Page 82: Supporting The Motorcycle

    PERIODIC MAINTENANCE AND ADJUSTMENT 6. Install the license plate light unit by EAU24350 Supporting the motorcycle installing the bolts. Since this model is not equipped with a centerstand, follow these precautions when removing the front and rear wheel or performing other maintenance requiring the motorcycle to stand up- right.
  • Page 83: Troubleshooting

    However, should your motorcycle require any repair, take it to a Yamaha dealer, whose skilled technicians have the necessary tools, experience, and know-how to service the motorcycle properly.
  • Page 84: Troubleshooting Chart

    Remove the spark plugs and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the battery. 4. Battery The engine turns over The battery is good.
  • Page 85: Motorcycle Care And Storage

    Be ble. Rust and corrosion can develop Cleaning even if high-quality components are sure to consult a Yamaha dealer for ECA10772 used. A rusty exhaust pipe may go un- advice on what products to use be- NOTICE fore cleaning the vehicle.
  • Page 86 For For motorcycles equipped with combination with water, carry out the additional cleaning, use Yamaha Wind- a windshield: Do not use strong following steps after each ride in the cleaners or hard sponges as shield Cleaner or other quality cleaner.
  • Page 87 Avoid combination Never apply oil or wax to any with Yamaha Mink Oil or another high- cleaner waxes, many of which rubber and plastic parts, but quality leather protectant for increased...
  • Page 88: Storage

    MOTORCYCLE CARE AND STORAGE EAU44452 2. Fill up the fuel tank and add fuel 4. Lubricate all control cables and the Storage stabilizer (if available) to prevent pivoting points of all levers and the fuel tank from rusting and the pedals as well as of the side- Short-term fuel from deteriorating.
  • Page 89: Specifications

    Lubrication system: 980 mm (38.6 in) Dry element Dry sump Overall height: Fuel: Engine oil: XV17ASA 1140 mm (44.9 in) Recommended fuel: XV17ASAC 1140 mm (44.9 in) Recommended brand: Unleaded gasoline only XV17ATSA 1500 mm (59.1 in) YAMALUBE Fuel tank capacity: XV17ATSAC 1500 mm (59.1 in)
  • Page 90 Wheel type: Left foot operation Loading: Cast wheel Gear ratio: Maximum load: Rim size: 1st: XV17ASA 191 kg (421 lb) 16M/C x MT3.50 38/16 (2.375) XV17ASAC 191 kg (421 lb) Front brake: 2nd: XV17ATSA 177 kg (390 lb) Type: 30/19 (1.579)
  • Page 91 SPECIFICATIONS Spring/shock absorber type: Turn signal indicator light: Coil spring/gas-oil damper Wheel travel: Fuel level warning light: 110.0 mm (4.33 in) Electrical system: Engine trouble warning light: Ignition system: Fuses: Charging system: Main fuse: AC magneto 50.0 A Battery: Headlight fuse: 20.0 A Model: Signaling system fuse:...
  • Page 92: Consumer Information

    Record the key identification number, vehicle identification number and mod- el label information in the spaces pro- vided below for assistance when ordering spare parts from a Yamaha dealer or for reference in case the vehi- cle is stolen. KEY IDENTIFICATION NUMBER: 1.
  • Page 93 This information illustration. This label shows specifica- will be needed when ordering spare tions related to exhaust emissions as parts from a Yamaha dealer. required by federal law, state law and Environment Canada. 10-2...
  • Page 94: Reporting Safety Defects

    If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Yamaha Motor Corporation, U.S.A. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
  • Page 95: Motorcycle Noise Regulation

    CONSUMER INFORMATION EAU26560 Motorcycle noise regulation TAMPERING WITH NOISE CONTROL SYSTEM PROHIBITED: Federal law prohibits the following acts or the causing thereof: (1) The removal or rendering inoperative by any person other than for purposes of maintenance, repair, or replacement of any device or element of design incorporated into any new ve- hicle for the purpose of noise control prior to its sale or delivery to the ultimate purchaser or while it is in use or (2) the use of the vehicle after such device or element of design has been removed or rendered inoperative by any person.
  • Page 96: Maintenance Record

    CONSUMER INFORMATION EAU26632 Maintenance record Copies of work orders and/or receipts for parts purchased and installed on your vehicle will be required to document that maintenance has been completed in accordance with the emissions warranty. The chart below is printed only as a reminder that maintenance work is required.
  • Page 97 CONSUMER INFORMATION Maintenance Date of Servicing dealer Mileage Remarks interval service name and address 36000 mi (55000 km) or 54 months 40000 mi (61000 km) or 60 months 10-6...
  • Page 98: Warranty

    CONSUMER INFORMATION EAU26663 YAMAHA MOTOR CORPORATION, U.S.A. STREET AND ENDURO MOTORCYCLE LIMITED WARRANTY Yamaha Motor Corporation, U.S.A. hereby warrants that CUSTOMER’S RESPONSIBILITY under this Engine new Yamaha motorcycles will be free from defects in warranty shall be to: Displacement Period...
  • Page 99 CUSTOMER SERVICE What costs are my responsibility during the warranty period? If your machine requires warranty service, you must take it to any authorized Yamaha The customer’s responsibility includes all costs of normal maintenance services, motorcycle dealer within the continental United States. Be sure to bring your warranty non-warranty repairs, accident and collision damages, and oil, oil filters, air filters, registration card or other valid proof of the original date of purchase.
  • Page 100 This excellent Y.E.S. plan coverage is only available to dealer to see how comforting uninterrupted factory- Yamaha owners like you, and only while your Yamaha is still backed protection can be. within the Yamaha Limited Warranty period. So visit your authorized Yamaha dealer to get all the facts.
  • Page 101 Yamaha Limited Warranty expires. A special note: If visiting your dealer isn’t convenient, contact Yamaha with your Primary ID number (your frame number). We’ll be happy to help you get the Y.E.S. coverage you need.
  • Page 102 INDEX Fuel level warning light ......4-2 Fuel tank breather/overflow hose ..4-11 Air filter element, cleaning..... 7-16 Rear suspension, lubricating....7-28 Fuel tank cap .......... 4-9 Auxiliary DC connector ......4-20 RESET switch ......... 4-7 Fuses, replacing ........7-31 Rider seat..........4-12 Battery...........
  • Page 103 INDEX Turn signal light bulb, replacing.... 7-34 Turn signal switch........4-7 Valve clearance ........7-18 Vehicle Emission Control Information label............ 10-2 Vehicle identification number....10-1 Warranty, extended ......10-9 Warranty, limited........10-7 Wheel bearings, checking ....7-29 Wheels..........7-20 Windshield [XV17ATSA(C)] ....4-14...
  • Page 106 YAMAHA MOTOR CO., LTD. PRINTED ON RECYCLED PAPER PRINTED IN JAPAN 2010.06-0.3×1 CR...
