Detroit Radiant Products LS-10-25 Installation Manual

Ls series single stage radiant heater system

Advertisement

LS Series
Installation Manual
The LS Series Infra-Red Tube Heater is a positive pressure, single stage radiant heater system. This
manual provides specific information related to the LS Series model. All persons involved with the
installation, operation and maintenance of the heater system must read and understand the information
in this manual.
Improper installation, adjustment, alteration, service or maintenance can cause
property damage, injury or death. Read the installation, operation and maintenance
instructions thoroughly before installing or servicing this equipment.
This heater must be installed and serviced by trained gas installation and service
personnel only. Failure to comply could result in personal injury, asphyxiation, death,
fire or property damage.
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of
this or any other appliance.
In locations used for the storage of combustible materials, signs must be posted to
specify the maximum permissible stacking height to maintain the required clearances
from the heater to the combustibles. Signs must either be posted adjacent to the
heater thermostats or in the absence of such thermostats, in a conspicuous location.
Do not use this heater in indoor living or sleeping quarters, ect.! Installation of
a tube heater system in residential indoor living spaces may result in property damage,
serious injury, asphyxiation or death.
For Your Safety
If you smell gas:
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your building. • If you cannot reach your gas supplier, call the fire department.
!
WARNING
!
• Immediately call your gas supplier from a neighbor's phone.
• Follow the gas supplier's instructions.
Keep these instructions for future reference.
F/N: LIOLS-1M-4/08 (CDS)
Replaces F/N: LIOLS-3/05
