Menu Operation

Flow of Menus

The menus displayed on the RM-HP790DU/RM-HP790DE are provided in the form shown below.
Category
1: GENLOCK
( Page 21)
1A: SD H PHASE
1B: HD H PHASE
1C: SC COARSE
1D: SC FINE
1Z: BACK
2: CABLE
( Page 21)
2A: LENGTH
2Z: BACK
*3
3: FILE ( Page 22)
3A: LOAD FILE
3B: STORE FILE
3C: RESET FILE
3Z: BACK
*3
4: PROCESS ( Page 23, 24)
4A: DETAIL
4B: DETAIL LEVEL
4C: DETAIL V/H
4D: DETAIL FRQ.
4E: SKIN DETAIL
4F: AUTO KNEE
4G: KNEE POINT
4H: COLOR MATRIX
4I: V.RESOLUTION
4J: GAMMA
4K: GAMMA LEVEL
4L: BLACK
4M: ASPECT RATIO
4N: DNR
4O: DNR LEVEL
4Z: BACK
*3
5: OPERATION
( Page 25)
5A: SHUTTER
5B: V. GAIN STEP
5C: V. GAIN MAX
5D: GAIN LOW
5E: GAIN MID
5F: GAIN HIGH
5G: SMOOTH TRANS
5H: FUNC1
5I: FUNC2
5J: FUNC3
5K: FUNC4
5Z: BACK
6: LCD MODE
( Page 26)
6A: CONTRAST
6B: BACKLIGHT
6Z: BACK
7: SYSTEM
( Page 26)
7A: SYSTEM RESET
7Z: BACK
8: EXIT
Item Variable Value
-128 to 0 to 127
-1024 to 0 to 1023
0 , 90 , 180 , 270
-128 to 0 to 127
5M, 20M, 50M, 100M
A, B, C, D, BACK
*1
A, B, C, D, BACK
*1
A, B, C, D, BACK
Netted items
OFF, ON
-10 to NORMAL to 10
-10 to NORMAL to 10
LOW, MIDDLE, HIGH, AUTO
OFF, ON
OFF, ON
-10 to NORMAL to 10
OFF, ON
NORMAL, V.MAX
OFF, ON
-10 to NORMAL to 10
NORMAL, STRETCH, COMPRESS
4:3, 16:9, LETTER
OFF, ON
LOW, MIDDLE, HIGH, AUTO
Netted items
STEP, VARIABLE
0.1 dB, 1.0 dB
9.0 dB, 12.0 dB, 18.0 dB
-3 dB, 0 dB, 3 dB, 6 dB, 9 dB, 12 dB, 15 dB, 18 dB
-3 dB, 0 dB, 3 dB, 6 dB, 9 dB, 12 dB, 15 dB, 18 dB
-3 dB, 0 dB, 3 dB, 6 dB, 9 dB, 12 dB, 15 dB, 18 dB
OFF, ON
*2
*2
*2
*2
-5 to NORMAL to 5
OFF, ON
*3
CANCEL, OK
Memo :
● The items and values that are not available with the
camera are not menus displayed.
are saved in the scene file.
are saved in the scene file.
*
1 Check screens are provided for items LOAD FILE
and STORE FILE.
* 2 The options for FUNC1 to FUNC4 are common:
BLACK STRETCH, BLACK COMPRESS,
ALC + EEI,
LOLUX,
AUTO KNEE,
COLOR MATRIX,
DNR,
*
3 This is not displayed when connected to the remote
control panel. Operation cannot be performed from the
main unit.
ALC,
FAW,
SKIN DETAIL,
DETAIL,
NONE
