Quatro AF-2000 Operation And Maintenance Manual

Filename: Quatro/FreshAir
Operations & Maintenance Manual
Fresh Air Purifiers
1.0 INTRODUCTION
You are now the owner of an advanced effective indoor air purifier. You may now expect a noticeable improvement in your air quality as the AF
Purifier begins the process of reducing microscopic airborne particulate as well as harmful gases, smoke, dust and pollen.
2.0 SAFETY PRECAUTION
Read all of the instructions contained within this manual before operating this unit. Keep this manual, as it contains information for proper operation
and maintenance. Keep all fastening hardware tight to ensure that the unit is in safe working condition. Familiarise yourself with the way in which
filters are removed, installed, and serviced. All filters must be in place whenever this machine is in operation. Use only on a grounded electrical
circuit; do not use any two-wire electrical prong adapters to defeat the three-pronged plug on the end of the cord. When servicing the motor, be
careful when touching the exterior of the motor as soon as it has been turned off; it may be hot enough to be painful or cause injury. they are built to
operate at higher temperatures. Do not substitute any other filters (particulate or chemical) for those supplied, as this will alter the unit
efficiency. DO NOT SERVICE MOTOR OR CONTROL PANEL UNLESS UNIT IS UNPLUGGED FROM RECEPTACLE (ITS POWER SUPPLY)!
3.0 PRINCIPLE OF OPERATION
The air is drawn in through an intake grille located at the bottom of unit. The air then passes through the particulate and odor filtraters. The clean air
is then released through the top discharge grille into the controlled space. The AF Unit features a threefold method of operation; a) captures general
particulate; b) HEPA filter removes microscopic particulate matter; c) Chemically adsorbs, reacts or scrubs toxic or nuisance gases (optional);
4.0 MAIN SYSTEM COMPONENTS
BLOWER ASSEMBLY: The blower is factory balanced and tested to ensure quiet, vibration-free operation.
CONTROL PANEL: Designed for easy monitoring, features include two position on/off switch, visual system pressure indicator, motor operation
indicator light and 120 volt fuse (AF600 is designed for single speed, pressure indicator is optional).
5.0 SYSTEM COMPONENTS
Description
Nominal Airflow (CFM/m3/hr)
Dimensions, Height:
Dimensions, Width: *
Dimensions Length:
Voltage
Current:
Approx. Weight:
* - add 2" for bend on power cord if req'd for width dimension
----------------------------------------------------------------
30 Hymus Blvd., Pointe-Claire, Quebec, Canada H9R 1C9
AF-2000
AF-1000
AF-600
AF2000
1000 / 1700
71" (1803mm) 52" (1321mm)
24" (610mm) 22" (559mm)
26" (660mm) 16" (406mm)
120/1/60 or 230/1/50 120/1/60 or 230/1/50
5.4 or 2.3 amps 1.6 or 0.8 amps
350lbs (159kgs) 200lbs (91kgs)
We Make Clean Air
Tel.: (514) 630-4444
AF1000 AF600
500 / 850 250 / 450
37" (940mm)
22" (559mm)
16" (406mm)
120/1/60 or 230/1/50
1.6 or 0.8 amps
135lbs (61kgs)
----------------------------------------------------------------
Fax: (514) 630-4454
01/31/05 – R7
