- Page 1 ASD-24 ORDERCODE D1960...
- Page 2 Congratulations! You have bought a great, innovative product from DAP Audio. The DAP Audio ASD-24 brings excitement to any venue. Whether you want simple plug-&-play action or a sophisticated show, this product provides the effect you need. You can rely on DAP Audio, for more excellent audio products.
-
Page 3: Table Of Contents
DAP Audio DAP Audio ASD-24 Product Guide Warning..…...................………………………………………….. Safety-instructions………………………………………………………………………………………….…. Operating Determinations……………………………………………………………………………………. Description..…................……….………………………………… Features………………………………………………………………………………….………………….…. Overview Front side..…………………………………………………………………………………..…… Overview Back side..…………………………………………………………………………………….…… Installation..............……………………………..………………………… Set Up and Operation..............……..…………………………….…… Connection Cables………..………………………………………………………………………..….……… Maintenance………......…........………..………….…….………….….. Troubleshooting………......…........………..………….…….………….….. Product Specifications..............……………….…….…………………. -
Page 4: Warning
WARNING CAUTION! Keep this system away from rain and moisture! FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY BEFORE YOUR INITIAL START-UP! SAFETY INSTRUCTIONS Every person involved with the installation, operation and maintenance of this system has to: be qualified follow the instructions of this manual CAUTION! Be careful with your operations. -
Page 5: Operating Determinations
For replacement use fuses of same type and rating only. • Prevent distortion! Make sure that all components connected to the ASD-24 have sufficient power ratings. Otherwise distortion will be generated because the components are operated at their limits. •... -
Page 6: Description
This indicator lights when the ASD-24 is switched on. 3. Mode Indication This indicator shows the current mode of the ASD-24. Left light on, means it is working at 2-4 modes; Right light on means it is working at 1-8 modes. -
Page 7: Installation
9. Remote Power Supply Input Socket This is the remote AC power supply input socket for the ASD-24. It is a special three cores socket. The model for this power supply adapter is “YH-18A-1000”. In order to make your ASD-24 work in a stable and safe condition, please use this special power supply adapter we provide. -
Page 8: Connection Cables
constant output level 6. Special POWER ON / OFF No Hum function, protects your expensive amplifier and speakers in case of an error operation Connection Cables In this chapter you’ll find the wiring diagrams for the connectors to be used with your Signal Distributor. Take care of the connector cables, always holding them by the connectors and avoiding knots and twists when coiling them: This gives the advantage of increasing their life and reliability, which is always to your advantage. -
Page 9: Maintenance
Maintenance The ASD-24 Signal Distributor requires almost no maintenance. However, you should keep the unit clean. Disconnect the mains power supply, and then wipe the cover with a damp cloth. Do not immerse in liquid. Keep connections clean. Disconnect electric power, and then wipe the audio connections with a damp cloth. -
Page 10: Product Specifications
Product Specifications Model: DAP Audio ASD-24 Power: AC2x 18V 500mA S / N Rate: > 103dB Frequency response: 20Hz – 20KHz (+/- 0.3dB) THD %: <0.03% Dynamic range: 118dB Input Mode: 1 pair In/ 4 pairs Out; 1 Mono In / 8 Mono Out Maximum Output Gain: -∞... - Page 11 2004 Dap Audio.
