YOYOMOTION Mobile Travel Router EE1 Quick Start Manual

Mobile travel router ee1
Hide thumbs Also See for Mobile Travel Router EE1:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
Mobile Travel Router EE1
Quick Start Guide
www.yoyomotion.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mobile Travel Router EE1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for YOYOMOTION Mobile Travel Router EE1

Summary of Contents for YOYOMOTION Mobile Travel Router EE1

  • Page 1 Mobile Travel Router EE1 Quick Start Guide www.yoyomotion.com...

  • Page 2: Operating Modes

    Operating Modes YOYORouter EE1 has four operating modes to keep you connected via cabled Ethernet WAN (Wide Area Network), Wireless WAN (Mobile Broadband) or Wi-Fi hotspot sharing: Wireless WAN (Mobile Broadband) Mode Make a Mobile Broadband connection using LTE/HSPA/HSDPA /UMTS/EDGE/GPRS via a USB modem (USB dongle) plugged in to YOYORouter EE1.

  • Page 3: Preparing Yoyorouter Ee1

    Preparing YOYORouter EE1 1. Open the battery compartment • Slide the cover in the direction shown until it clicks open. • Lift the cover away from YOYORouter. 2. Insert the battery • WARNING: Always be sure to disconnect the power before inserting or removing the battery. •...

  • Page 4: Connecting To Yoyorouter Ee1

    Connecting to YOYORouter EE1 Select YOYORouter’s Wi-Fi network which has a network name (SSID) like YOYORouter-07-76. The network name and network password are printed on a label in the battery compartment and on the box. For example, in Windows 7 •...

  • Page 5: Setting Up Yoyorouter Ee1 In Wireless Wan Mode

    Setting up YOYORouter EE1 in Wireless WAN Mode Note: A full list of supported USB modems is available from the Supported Cards List link in the status page, or from www.yoyomotion.com. 1. Make sure your SIM card is installed in the USB modem. Consult the USB Modem’s documentation for further information.

  • Page 6: Setting Up Yoyorouter Ee1 In Ethernet Wan Mode

    Setting up YOYORouter EE1 in Ethernet WAN Mode 1. Plug in the Ethernet cable and switch on YOYORouter EE1. Typical WAN sources include ADSL modems, cable modems and hotel/office cabled Internet connections. 2. Connect to YOYORouter via Wi-Fi, access the status page at http://192.168.1.1 and log in. 3.
  • Page 7 Setting up YOYORouter EE1 in Ethernet WAN Mode with Failover First configure YOYORouter EE1 in Wireless WAN Mode and test the connection. Next, configure YOYORouter EE1 in Cable and test the connection. To enable WAN Mode with Failover, ensure that the USB Modem and Ethernet WAN are both connected and follow these steps: 1.

  • Page 8: Setting Up Yoyorouter Ee1 In Share Mode

    Setting up YOYORouter EE1 in Share Mode 1. Switch on YOYORouter EE1. 2. Connect to YOYORouter via Wi-Fi or Ethernet, access the status page at http://192.168.1.1 and log in. 3. Select Wizard. Click through the Wizard making any changes to the default settings if necessary. 4.

  • Page 9: Indicator Lights

    Wi-Fi Configuration Tips YOYORouter is pre-configured with a default Wi-Fi network name (SSID) and password. The network name and password are printed on the label on the underside of the device and on the label affixed to the carton in which it was packaged. Security is set to WPA-PSK(TKIP) and WPA2-PSK(AES) – devices may connect using either of these.
  • Page 10 Important Information Please read this information before using your YOYORouter. REMEMBER THAT YOYOROUTER CONTAINS A WI-FI TRANSMITTER AND AN ATTACHED USB MODEM CONTAINS A MOBILE PHONE TRANSMITTER. YOU MUST AT ALL TIMES OBEY ALL RESTRICTIONS FOR BOTH OF THESE TRANSMITTER TYPES. Safety and Usage Guidelines •...
